Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 87L-47541-00-00 | Housing, Chain | ||
| 1 | 93306-20552-00 | Bearing | 1 |
| 1 | 93102-30083-00 | Oil Seal | 1 |
| 93320-21805-00 | Bearing, Cylinder.#20 | ||
| 1 | 93306-20310-00 | Bearing | 1 |
| 93306-90702-00 | Bearing | ||
| 90387-35363-00 | Collar | ||
| 93102-40080-00 | Oil Seal, Sd-Type | ||
| 8X2-47543-00-00 | Cap, Housing | ||
| 2 | 93306-20310-00 | Bearing | 2 |
| 1 | 93102-22087-00 | Oil Seal | 1 |
| 90387-17134-00 | Collar | ||
| 93210-17674-00 | O-Ring | ||
| 1 | 90201-251G8-00 | Washer, Plate | 1 |
| 8X2-17121-00-00 | Gear, 2Nd Pinion | ||
| 1 | 93315-32516-00 | Bearing | 1 |
| 1 | 90201-252A4-00 | Washer, Plate | 1 |
| 2 | 93410-25017-00 | Circlip | 2 |
| 8X2-17131-00-00 | Gear, 3Rd Pinion | ||
| 1 | 93315-11720-00 | Bearing | 1 |
| 1 | 90201-17713-00 | Washer, Plate | 1 |
| 8V2-17492-00-00 | Dog, Trans Shiftshift | ||
| 8X2-17431-00-00 | Axle, Counter | ||
| 8X2-17432-00-00 | Axle, Idle | ||
| 8X2-18531-00-00 | Bar, Shif Frk Gde 1Guide 1 | ||
| 1 | 90101-08344-00 | Bolt | 1 |
| 1 | 90201-08085-00 | Washer, Plate | 1 |
| 90430-08023-00 | Gasket | ||
| 1 | 90501-10060-00 | Spring, Compression | 1 |
| 1 | 90249-07215-00 | Pin | 1 |
| 87L-18511-00-00 | Fork, Shift 1 | ||
| 1 | 91609-40020-00 | Pin, Spring | 1 |
| 8V2-18173-00-00 | Pin, Shift | ||
| 8X2-18121-00-00 | Lever, Shift 1 | ||
| 8X2-18191-00-00 | Lever | ||
| 1 | 97011-06020-00 | Bolt | 1 |
| 1 | 93210-09350-00 | O-Ring | 1 |
| 85W-47592-00-00 | Gasket | ||
| 8X5-17682-40-00 | Sprkt, Chain Drdrive (14T) | ||
| 8X2-17682-50-00 | Sprkt, Chain Drdrive (15T) ALT. PART | ||
| 90387-171H7-00 | Collar | ||
| 868-47571-00-00 | Journal 1 | ||
| 1 | 93210-25070-00 | O-Ring | 1 |
| 90387-35364-00 | Collar | ||
| 8X5-47548-30-00 | Sprocket, Chn Drvndriven (33T) | ||
| 8V2-47548-10-00 | Sprocket, Chn Drvndriven (31T) ALT. PART | ||
| 8X2-47548-20-00 | Sprocket, Chn Drvndriven (32T) ALT. PART | ||
| 90215-30217-00 | Washer, Lock | ||
| 90109-241A2-00 | Bolt | ||
| 8V2-47613-00-00 | Holder | ||
| 8X5-47612-00-00 | Wheel | ||
| 1 | 93315-21227-00 | Bearing | 1 |
| 93612-47207-00 | Pin, Dowel | ||
| 1 | 90387-121E8-00 | Collar | 1 |
| 90249-12163-00 | Pin, Spec''l Shape | ||
| 1 | 90201-12631-00 | Washer, Plate | 1 |
| 1 | 99009-12400-00 | Circlip | 1 |
| 1 | 90210-10004-00 | Washer, Seal | 1 |
| 95303-10700-00 | Nut | ||
| 1 | 90101-10357-00 | Bolt | 1 |
| 1 | 98580-06010-00 | Screw, Pan Head (92503-06010-00 | 1 |
| 1 | 90430-06016-00 | Gasket | 1 |
| 8G8-47591-00-00 | Plate | ||
| 85T-47592-00-00 | Gasket | ||
| 4 | 98903-06012-00 | Screw, Blind | 4 |
| 1 | 90340-22047-00 | Plug, Straight Screw | 1 |
| 1 | 90430-22144-00 | Gasket | 1 |
| 1 | 583-15371-00-00 | Breather | 1 |
| 90445-09055-00 | Hose | ||
| 94890-07080-00 | Chain 84G Et400trn | ||
| 2 | 99530-10014-00 | Pin, Dowel | 2 |
| 91316-06035-00 | Bolt | ||
| 2 | 91316-06045-00 | Bolt | 2 |
| 14 | 92906-06600-00 | Washer | 14 |
| 97022-06045-00 | Bolt (83L) | ||
| 2 | 92995-06100-00 | Washer, Spring | 2 |
| 4 | 95333-08600-00 | Nut | 4 |
| 92990-08200-00 | Washer, Plain | ||
| 4 | 92990-08100-00 | Washer, Spring | 4 |
| 8X2-18112-00-00 | Arm, Shift | ||
| 8V2-18199-00-00 | Knob, Change | ||
| 1 | 90109-06797-00 | Bolt | 1 |
| 8X2-18137-00-00 | Washer 1 | ||
| 1 | 90201-06778-00 | Washer, Plate | 1 |
| 1 | 95701-06300-00 | Nut, Nylon | 1 |
| 1 | 95380-06700-00 | Nut | 1 |
| 1 | 98903-06008-00 | Screw, Bind | 1 |
| 1 | 90430-06166-00 | Gasket | 1 |
| 8X2-18129-00-00 | Cover, Shift Shaft | ||
| 90386-08128-00 | Bush, Spec''l Nylon | ||
| 2 | 97313-05010-00 | Bolt, Hexagon | 2 |
| 2 | 92990-05100-00 | .Washer, Spring | 2 |
