Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8BU-14100-00-00 | Carburetor Assembly | ||
| 8BU-14901-00-00 | . Carburetor Assembly 1 | ||
| 8BU-14902-00-00 | . Carburetor Assembly 2 | ||
| 8BU-14903-00-00 | . Carburetor Assembly 3 | ||
| 8BU-14904-00-00 | . Carburetor Assembly 4 | ||
| 1 | 89A-14292-00-00 | . . ..Lever A | 1 |
| 1 | 89A-14243-00-00 | . . ..Plate | 1 |
| 1 | 89A-14137-00-00 | . . ..Clip | 1 |
| 1 | 89A-14199-00-00 | . . ..Gasket | 1 |
| 2 | 91317-03012-00 | . . Bolt (91316-03012-00 ) | 2 |
| 1 | 89A-14188-00-00 | . . ..Connector | 1 |
| 2 | 3GF-14126-00-00 | . . ..Gasket | 2 |
| 1 | 620-14198-00-00 | . . ..Gasket | 1 |
| 1 | 3MA-14937-00-00 | . . ..Clip | 1 |
| 1 | 164-14137-00-00 | . . Clip | 1 |
| 2H0-14235-00-00 | . . Washer, Needle | ||
| 89A-14112-10-00 | . . Valve, Throttle 1 | ||
| 1 | 3H1-14147-00-00 | . . O-Ring | 1 |
| 1 | 3H1-14962-00-00 | . . Washer | 1 |
| 1 | 5K7-14134-00-00 | . . Spring, Air Adjusting | 1 |
| 1 | 89A-14565-00-00 | . . ..Screw, Pilot Adjusting | 1 |
| 1 | 3H1-14142-55-00 | . . Jet, Pilot (#55) UR | 1 |
| 1 | 3H1-14142-47-00 | . . Jet, Pilot (#47.5) UR STD | 1 |
| 1 | 89A-14996-00-00 | . . ..Pipe | 1 |
| 8BU-14116-20-00 | . . Needle | ||
| 89A-14141-54-00 | . . Nozzle, Main | ||
| 1 | 1LX-14153-00-00 | . . ..Washer, Main Jet | 1 |
| 1 | 89A-14194-00-00 | . . ..Ring | 1 |
| 1 | 3G2-1423E-57-00 | . . ..Jet, Main (#143.8) UR STD | 1 |
| 1 | 3G2-1423E-55-00 | . . ..Jet, Main (#138.8) UR | 1 |
| 3G2-1423E-54-00 | . . Jet, Main (#136.3) UR | ||
| 1 | 3G2-1423E-53-00 | . . Jet, Main (#133.8) UR | 1 |
| 1 | 3G2-1423E-52-00 | . . Jet, Main (#131.3) UR | 1 |
| 1 | 3G2-1423E-59-00 | . . ..Jet, Main (#148.8) UR | 1 |
| 1 | 3G2-1423E-58-00 | . . ..Jet, Main (#146.3) UR | 1 |
| 1 | 3G2-1423E-56-00 | . . ..Jet, Main (#141.3) UR | 1 |
| 1 | 500-14115-00-00 | . . ..Plug, Screw | 1 |
| 1 | 558-14147-00-00 | . . O-Ring | 1 |
| 1 | 2LN-14565-00-00 | . . ..Screw | 1 |
| 1 | 1UY-14185-00-00 | . . Float | 1 |
| 1 | 537-14186-00-00 | . . Pin, Float | 1 |
| 1 | 1AE-14190-13-00 | . . ..Needle Valve Assy | 1 |
| 1 | 89A-14147-00-00 | . . ..O-Ring | 1 |
| 1 | 8F2-14147-00-00 | . . O-Ring | 1 |
| 1 | 1J7-14994-00-00 | . . Net, Filter | 1 |
| 239-14172-00-00 | . . Pilot Jet, Air | ||
| 98701-05008-00 | . . Screw, Flat Head | ||
| 302-14173-00-00 | . . ..Cover, Plunger Cap | ||
| 4G0-14171-00-00 | . . ..Plunger, Starter | ||
| 2N3-14135-00-00 | . . Spring, Plunger | ||
| 1FN-14174-00-00 | . . ..Cap, Plunger | ||
| 1 | 1AE-14147-00-00 | . . O-Ring | 1 |
| 1 | 89A-14216-00-00 | . . Screw | 1 |
| 1 | 95311-05700-00 | . . Nut | 1 |
| 89A-14276-00-00 | . . Lever | ||
| 1 | 89A-14286-00-00 | . . Spring | 1 |
| 89A-14905-00-00 | . . Lever, Starter | ||
| 4 | 98503-04014-00 | . . Screw, Pan Head | 4 |
| 1 | 12R-14191-00-00 | . . .Plug, Drain | 1 |
| 1 | 89A-14987-00-00 | . . Hose | 1 |
| 8AX-14987-00-00 | . . Hose | ||
| 1 | 98580-04010-00 | . . Screw, Pan Head | 1 |
| 2 | 3MA-14918-00-00 | . . ..Ring | 2 |
| 1 | 239-14172-10-00 | . . ..Pilot Jet, Air (1.0) | 1 |
| 1 | 89A-14125-00-00 | . . Screw | 1 |
| 1 | 2J2-14133-00-00 | . . ..Spring, Throttle Stop | 1 |
| 1 | 89A-14265-00-00 | . . ..Collar | 1 |
| 1 | 22F-14117-00-00 | . . Washer, Plug Screw | 1 |
| 1UF-14952-00-00 | . . ..Washer | ||
| 1 | 89A-14594-00-00 | . . ..Nut | 1 |
| 1 | 89A-24529-00-00 | . . ..Spring | 1 |
| 1 | 87S-8259A-00-00 | . . .Switch, Carburetor | 1 |
| 4 | 89A-14198-00-00 | . .Gasket | 4 |
| 8 | 98506-04010-00 | . Screw, Pan Head | 8 |
| 1 | 98701-04014-00 | . Screw, Flat Head | 1 |
| 89A-14208-00-00 | . .Lever Comp. 1 | ||
| 4 | 11H-14991-00-00 | . Screw | 4 |
| 89A-14264-00-00 | . .Collar | ||
| 89A-14589-00-00 | . Spring | ||
| 3H1-14227-00-00 | . .Washer | ||
| 3LD-14919-00-00 | . Clip | ||
| 89A-14275-00-00 | . Spring | ||
| 3 | 98517-04016-00 | . Screw, Pan Head | 3 |
| 16 | 98507-05012-00 | . .Screw, Pan Head | 16 |
| 89A-14978-00-00 | . Shaft, Starter Lever | ||
| 3 | 35H-14139-00-00 | . Clip, Pipe | 3 |
| 1 | 98507-05010-00 | . .Screw, Pan Head | 1 |
| 22F-14115-00-00 | . .Plug, Screw | ||
| 1 | 22F-14117-00-00 | . Washer, Plug Screw | 1 |
| 3FV-14962-00-00 | . .Washer | ||
| 1AE-14135-00-00 | . .Spring, Plunger | ||
| 89A-14118-00-00 | . .Cap |
