Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 17920-HC3-305 | CABLE SET, THROTTLE | ||
| 22880-HC3-000 | CABLE, REVERSE ASSIST | ||
| 2 | 32161-404-000 | BAND B1, CABLE | 2 |
| 35200-HC3-003 | SWITCH ASSY., LIGHTING ENGINE STARTER | ||
| 35200-HC3-013 | SWITCH ASSY., LIGHTING ENGINE STARTER | ||
| 1 | 35201-HB7-671 | COVER, SWITCH | 1 |
| 1 | 43459-HB2-000 | NUT, BRAKE ADJUSTING | 1 |
| 43460-HC3-000 | CABLE, HANDLE BRAKE | ||
| 1 | 43468-VM6-680 | SPRING B, BRAKE ROD | 1 |
| 45450-HC3-000 | CABLE, FR. FIRST BRAKE | ||
| 45460-HC3-000 | CABLE, FR. SECOND BRAKE | ||
| 47600-HC3-000 | EQUALIZER ASSY., RR. BRAKE | ||
| 1 | 47610-HB2-000 | PLATE, EQUALIZER | 1 |
| 47620-HC3-000 | BODY, EQUALIZER | ||
| 53140-HC3-000 | COVER ASSY., THROTTLE CASE | ||
| 53142-HC3-000 | CASE, THROTTLE LEVER | ||
| 1 | 53144-HA0-010 | ARM, THROTTLE | 1 |
| 1 | 53145-HA0-000 | LEVER, THROTTLE | 1 |
| 1 | 53145-HA0-770 | LEVER, THROTTLE | 1 |
| 1 | 53146-HA0-000 | SPRING, THROTTLE RETURN | 1 |
| 1 | 53147-HC3-000 | HOLDER, THROTTLE CASE | 1 |
| 2 | 53148-HA0-000 | BUSH, THROTTLE PIVOT | 2 |
| 53155-VM6-680 | MARK, THROTTLE CAUTION | ||
| 2 | 53165-958-010 | GRIP, HANDLE | 2 |
| 2 | 53167-958-680 | GUARD, HANDLEBAR END | 2 |
| 53171-VM6-680 | BRACKET, R. CONTROL LEVER | ||
| 53172-HC3-000 | BRACKET, BRAKE LEVER | ||
| 53172-HC3-010 | BRACKET, BRAKE LEVER | ||
| 2 | 53173-958-000 | HOLDER, LEVER BRACKET | 2 |
| 1 | 53175-HC3-000 | LEVER, R. HANDLEBAR | 1 |
| 53176-VM6-000 | COVER, R. HANDLE LEVER | ||
| 1 | 53177-HA0-680 | COVER, L. HANDLEBAR | 1 |
| 53179-VM6-000 | ARM, REVERSE ASSIST | ||
| 53180-HC3-000 | LEVER, RR. BRAKE | ||
| 1 | 53187-VM6-000 | CAP, REVERSE PIN | 1 |
| 1 | 53191-961-010 | SPRING, PARKING BRAKE LEVER | 1 |
| 53192-HA0-770 | LEVER, PARKING LOCK | ||
| 1 | 53193-HA0-770 | CAP, PARKING LEVER | 1 |
| 2 | 84906-118-000 | COLLAR, NUMBER BRACKET SETTING | 2 |
| 1 | 90113-HA0-770 | BOLT, HANDLE LEVER PIVOT | 1 |
| 1 | 90114-HA0-770 | BOLT, HANDLE LEVER PIVOT | 1 |
| 1 | 90115-961-000 | SCREW, PARKING BRAKE LEVER PIVOT | 1 |
| 1 | 90501-HA0-000 | WASHER, LOCK (6MM) | 1 |
| 1 | 90504-HA0-000 | WASHER (9X20) | 1 |
| 1 | 91210-HA0-003 | DUST SEAL (9X16X5) (ARAI) | 1 |
| 1 | 91210-HA0-004 | DUST SEAL (9X16X5) (NOK) | 1 |
| 1 | 91532-HA0-020 | GASKET, THROTTLE CASE | 1 |
| 3 | 93500-04016-0G | SCREW, PAN (4X16) | 3 |
| 2 | 93500-05014-0G | SCREW, PAN (5X14) | 2 |
| 4 | 93500-05018-0A | SCREW, PAN (5X18) | 4 |
| 2 | 93500-05025-0G | SCREW, PAN (5X25) | 2 |
| 1 | 93500-06032-0A | SCREW, PAN (6X32) | 1 |
| 2 | 94001-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94001-06200-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94002-06000-0S | NUT, HEX. (6MM) | 2 |
| 2 | 94050-06080 | NUT, FLANGE (6MM) | 2 |
| 1 | 95015-32001 | JOINT, BRAKE ARM | 1 |
| 2 | 95700-06025-07 | BOLT, FLANGE (6X25) | 2 |
| 2 | 95701-06025-07 | BOLT, FLANGE (6X25) | 2 |
