Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8CR-47541-01-00 | HOUSING, CHAIN | 1 |
| 2 | 90179-10679-00 | NUT | 2 |
| 2 | 93306-20592-00 | BEARING | 2 |
| 1 | 93102-35473-00 | OIL SEAL | 1 |
| 1 | 93102-35318-00 | OIL SEAL | 1 |
| 2 | 99009-52500-00 | CIRCLIP | 2 |
| 8CR-47558-01-00 | RING, HOUSING | ||
| 8CW-47543-02-00 | CAP, HOUSING | ||
| 2 | 93606-20044-00 | PIN, DOWEL | 2 |
| 1 | 93306-20402-00 | BEARING | 1 |
| 4 | 95827-08030-00 | BOLT, FLANGE | 4 |
| 3 | 95827-10060-00 | BOLT, FLANGE | 3 |
| 1 | 90101-10357-00 | BOLT | 1 |
| 1 | 95307-10600-00 | NUT | 1 |
| 1 | 8CR-47613-00-00 | HOLDER | 1 |
| 8CR-47612-00-00 | WHEEL | ||
| 1 | 93315-21227-00 | BEARING | 1 |
| 2 | 90201-127E1-00 | WASHER, PLATE | 2 |
| 1 | 90249-12227-00 | PIN | 1 |
| 2 | 99009-12400-00 | CIRCLIP | 2 |
| 8CR-47546-00-00 | LEVEL, OIL | ||
| 90387-2508D-00 | COLLAR | ||
| 1 | 82M-17699-00-00 | PLUG, OIL | 1 |
| 1 | 89J-17682-20-00 | SPROCKET, CHAIN DRIVE (22T) | 1 |
| 89J-17682-00-00 | SPROCKET, CHAIN DRIVE (20T) | ||
| 1 | 90208-22001-00 | WASHER, CONICAL SPRING | 1 |
| 1 | 90170-22094-00 | NUT | 1 |
| 94860-02068-00 | CHAIN (68L) | ||
| 94860-02070-00 | CHAIN (70L) | ||
| 8CW-47587-90-00 | SPROCKET, CHAIN DRIVEN (39T) | ||
| 1 | 93317-33179-00 | BEARING | 1 |
| 1 | 90387-2008G-00 | COLLAR | 1 |
| 1 | 90201-320S3-00 | WASHER, PLATE | 1 |
| 1 | 90105-100A7-00 | BOLT, FLANGE | 1 |
| 1 | 92907-10100-00 | WASHER, SPRING | 1 |
| 2 | 93210-25071-00 | O-RING | 2 |
| 1 | 90387-2508C-00 | COLLAR | 1 |
| 90387-2511J-00 | COLLAR | ||
| 1 | 97007-08014-00 | BOLT | 1 |
| 1 | 90210-08017-00 | WASHER, SEAL | 1 |
| 1 | 8CW-1761A-00-00 | SHAFT, 1 | 1 |
| 8DM-17692-00-00 | SPROCKET, DRIVE (18T) | ||
| 1 | 90501-06022-00 | SPRING, COMPRESSION | 1 |
| 1 | 8CW-17143-00-00 | GEAR, REVERSE PINION 1 (18T) | 1 |
| 2 | 93317-21578-00 | BEARING | 2 |
| 2 | 90201-16245-00 | WASHER, PLATE | 2 |
| 1 | 90105-060A6-00 | BOLT, FLANGE | 1 |
| 1 | 90210-06006-00 | WASHER, SEAL | 1 |
| 1 | 8CW-47571-00-00 | JOURNAL 1 | 1 |
| 1 | 8CW-17243-00-00 | GEAR, REVERSE WHEEL 1 (50T) | 1 |
| 1 | 8CW-17492-00-00 | DOG, TRANSMISSION SHIFT | 1 |
| 5 | 90501-066J5-00 | SPRING, COMPRESSION | 5 |
| 1 | 93440-39175-00 | CIRCLIP | 1 |
| 90501-326J6-00 | SPRING, COMPRESSION | ||
| 1 | 8CW-47564-00-00 | COLLAR | 1 |
| 2 | 8CW-18511-00-00 | FORK, SHIFT 1 | 2 |
| 8CW-18197-00-00 | SHAFT | ||
| 2 | 91609-50022-00 | PIN, SPRING | 2 |
| 1 | 93210-12131-00 | O-RING | 1 |
| 1 | 8CW-47591-00-00 | PLATE | 1 |
| 2 | 90105-060A6-00 | BOLT, FLANGE | 2 |
| 8CW-18112-01-00 | ARM, SHIFT | ||
| 1 | 8CW-18161-01-00 | GUIDE, PLATE STOPPER | 1 |
| 1 | 99009-12400-00 | CIRCLIP | 1 |
| 1 | 95607-06200-00 | NUT, SELF U-FLANGE | 1 |
| 1 | 95827-06035-00 | BOLT, FLANGE | 1 |
| 90387-06605-00 | COLLAR | ||
| 1 | 8CW-18152-10-00 | LEVER, SHIFT 4 | 1 |
| 1 | 91701-06035-00 | PIN, CLEVIS | 1 |
| 1 | 90468-12007-00 | CLIP | 1 |
| 2 | 92907-06200-00 | WASHER | 2 |
| 1 | 8CW-1811A-00-00 | PLATE, SHIFT ARM | 1 |
| 8CW-18153-00-00 | GUIDE, SHIFT RETURN SPRING | ||
| 1 | 90506-14343-00 | SPRING, TENSION | 1 |
| 1 | 8CL-18174-00-00 | KNOB, SHIFT LEVER | 1 |
| 1 | 91609-40022-00 | PIN, SPRING | 1 |
| 1 | J51-82817-00-00 | SWITCH | 1 |
| 98907-04016-00 | SCREW, BIND | ||
| 1 | 95607-04100-00 | NUT, U | 1 |
| 95827-06025-00 | BOLT, FLANGE | ||
| 1 | 95827-06040-00 | BOLT, FLANGE | 1 |
| 1 | 8CW-18198-00-00 | LEVER | 1 |
| 1 | 90387-0608T-00 | COLLAR | 1 |
| 2 | 90201-06071-00 | WASHER, PLATE | 2 |
| 90105-06601-00 | BOLT, WASHER BASED | ||
| 1 | J45-23845-00-00 | JOINT, UNIVERSAL 2 | 1 |
| 2 | 88T-18157-00-00 | JOINT 2 | 2 |
| 1 | 90201-06778-00 | WASHER, PLATE | 1 |
| 3 | 95607-06200-00 | NUT, SELF U-FLANGE | 3 |
| 1 | 8CW-18156-00-00 | JOINT 1 | 1 |
| 1 | 91701-06022-00 | PIN, CLEVIS | 1 |
| 1 | 88T-18116-01-00 | JOINT, ROD 1 | 1 |
| 1 | 26H-18115-00-00 | ROD, SHIFT | 1 |
| 2 | 95304-06600-00 | NUT | 2 |
| 2 | 90170-06289-00 | NUT | 2 |
