Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3280390 | Discontinued | ||
| 1 | 5412138 | MOUNT-RUBBER,INSTR. CLUSTER | 1 |
| 3 | 7511881 | SCREW | 3 |
| ------- | ASM., THROTTLE CONTROL [SEE CONTROLS - THROTTLE ASM./CABLE PG. B7, REF. 3] | ||
| 5245181-067 | HANDLEBAR,GEN 4,WIDE,BLK | ||
| 2 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 2 |
| 7555868 | WASHER, LOCK,(S.S.) | ||
| 7541933 | NUT | ||
| 4 | 7517238 | SCREW | 4 |
| ------- | ASM., MASTER CYLINDER [SEE CONTROLS - MASTER CYLINDER/BRAKE LINE PG B10 FOR DETAILS] | ||
| 5434284-382 | POD-HDLT,UPPER,SNAP,GUN METAL * | ||
| 5433903 | SWITCH SPACER, LEFT | ||
| 1 | 4010422 | HI/LO/MODE HANDLEBAR SWITCH | 1 |
| 1 | 7517625 | SCREW, SET | 1 |
| 1 | 5432952 | PLUG, HOLE | 1 |
| 2 | 5433834-070 | HANDLEBAR GRIP, 7/8 ID, GLOSS B | 2 |
| 1 | 5631146 | BLOCK-HANDLEBAR,PEGGED | 1 |
| 5631147 | BLOCK-HANDLEBAR | ||
| 1 | 5244969-067 | POD MOUNTING BRACKET, BLACK | 1 |
| 2 | 7517317 | SCREW | 2 |
| 1 | 4032079 | ADJUSTING KNOB | 1 |
| 1 | 5411120 | HEADLIGHT BOOT | 1 |
| 1 | 4032077 | COLLAR LOCK | 1 |
| 4032075 | ASM,HEADLIGHT W/ADJUST ROD-KNOB | ||
| 1 | 4010253 | 50 WATT HEADLIGHT BULB | 1 |
| 1 | 2204143 | HEADLIGHT HARNESS KIT | 1 |
| 1 | 2410268 | HEADLAMP ASSEMBLY, 50 WATT | 1 |
| 4032078 | Discontinued | ||
| 2 | 5410163 | O-RING | 2 |
| ------- | CABLE, CHOKE [SEE ENGINE MOUNTING PG. A12, REF. 36] | ||
| 1 | 7080936 | CAPLUG,#BPF-7/8 -6 BLACK | 1 |
| 4 | 7542122 | NYLOK NUT | 4 |
| 2 | 7670089 | NUT,U-TYPE | 2 |
| 7080631 | Discontinued | ||
| 7522021 | Discontinued | ||
| 5433762-070 | Discontinued | ||
| 1 | 4010390 | SWITCH-KEY 3 POS UNSEALED [Incl. Key] | 1 |
| 1 | 5433733 | IGNITION SWITCH NUT | 1 |
| 1 | 4010278 | KEYBLANK-B,6700-6800,2000-2100 NOTE: Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 4010321 | KEYBLANK-A,2700-2800,2200-2389 NOTE: Your key can be duplicated only by obtaining a key blank from Polaris and having it cut by mating it with your existing key. | 1 |
| 1 | 5433534 | KEY COVER-KEYSWITCH | 1 |
| 1 | 7080922 | CHOKE NUT, 24 MM X 1.5 MM | 1 |
| 1 | 7670127 | #8-10 PANEL CLIP SCREW | 1 |
| 1 | 4010298 | HALL EFFECT SENSOR [Incl. 38] | 1 |
| 1 | 5132382 | HALL SENSOR CAP | 1 |
| 1 | 7517658 | SCREW | 1 |
