Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 7546601 | NYLOK NUT | 2 |
| 8 | 7080003 | HOSE CLAMP | 8 |
| 1 | 8450040-600 | FUEL LINE, 600 CM | 1 |
| 8450083-66 | LINE-FUEL IMPULSE,66CM | ||
| ------- | Asm., Carburetor (See Footnote) (See Carburetor Pg. D8, Ref. 47) | ||
| 1 | 8450003-1525 | FUEL LINE, 1/4 ID | 1 |
| 1 | 7052075 | FITTING, TEE | 1 |
| 5240609-067 | BRKT, CARB.MT. | ||
| ------- | Screw and Washer (See Crankcase Pg. D5, Ref. 6) | ||
| 2 | 7547069 | NUTSERT,HEX | 2 |
| 2 | 3110079 | MOUNT,RUBBER,DURO 55 | 2 |
| 2 | 7552605 | WASHER | 2 |
| 2 | 7512102 | SCREW(10) | 2 |
| 2 | 7512315 | BOLT | 2 |
| 2 | 7552901 | SPRING LOCK WASHER | 2 |
| 7542403 | NUT LOCK | ||
| 3 | 7555806 | FLAT WASHER | 3 |
| 1 | 5242936-067 | MOUNT,ENGINE,TOP,BLK | 1 |
| 1 | 7555823 | WASHER | 1 |
| 5132007 | SPACER-MOTOR MNT TOP | ||
| 2 | 3110044 | ENGINE MOUNT ISOLATOR | 2 |
| 4010132 | CABLE,GND-ENGINE | ||
| 1 | 7517386 | SCREW | 1 |
| 1 | 2530009 | SMALL IN-LINE FILTER | 1 |
| 3085556 | N/A,USE COMPONENTS (EH50PLE08) (See Footnote) NOTE: The Short Block assembly contains a crankcase assembly, cylinder & cylinder head assembly and a piston & crankshaft assembly. Prior authorization is required for warranty consideration. | ||
| ------- | Gasket, Exhaust (See Cylinder Pg. D4, Ref. 20) | ||
| 1 | 1260889-029 | MANIFOLD,BLK. (Before 9-11-98) | 1 |
| 1260978-029 | WELD-MANIFOLD,BLK (After 9-11-98) | ||
| 2 | 3080530 | LOCK WASHER | 2 |
| 3080285 | NUT | ||
| 3 | 7542459 | FLANGED NUT LOCK(10) | 3 |
| 1 | 5242818-067 | MOUNT,LOW.FR.ENGINE,BLK. | 1 |
| 2 | 7515417 | SCREW | 2 |
| 2 | 7080474 | HOSE CLAMP | 2 |
| ------- | Bracket, Retainer, Seal (See Footnote) (See Clutch Cover Pg. C3, Ref. 18) | ||
| ------- | Asm., Drive Clutch, ATV-06 (See Footnote) (See Drive Clutch Pg. C1, Ref. 17) | ||
| 1 | 7512566 | BOLT | 1 |
| 1 | 7575202 | WASHER LOCK | 1 |
| 1 | 5210748 | WASHER | 1 |
| 1 | 5430261 | BUSHING | 1 |
| 1 | 5410421 | CLUTCH INTAKE BOOT | 1 |
| 1 | 7080511 | NARROW BAND CLAMP | 1 |
| 1 | 7080694 | CLAMP,HOSE,SPRING | 1 |
| ------- | Hose, Breather (See Air Box Pg. B2, Ref. 13) | ||
| 2 | 7555815 | FLAT WASHER | 2 |
| 3110046 | Discontinued | ||
| ------- | Mount, Motor, Rear (See Footnote) (See Transmission Mounting Pg. D2, Ref.11) | ||
| 1 | 7621462 | RIVET | 1 |
| 1 | 7080539 | CLAMP,NYLON,CABLE | 1 |
