Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 24121-18A03 | COUNTERSHAFT (NT:12) | ||
| 24221-02C00 | GEAR, 2ND DRIVE (NT:14) MODEL V | ||
| 24221-02C01 | GEAR, 2ND DRIVE (NT:14) MODEL W/X/Y/K1 | ||
| 24231-02C00 | GEAR, 3RD DRIVE (NT:17) MODEL V | ||
| 24231-02C01 | GEAR, 3RD DRIVE (NT:17) MODEL W/X/Y/K1 | ||
| 24241-02C00 | GEAR, 4TH DRIVE (NT:20) MODEL V | ||
| 24241-02C01 | GEAR, 4TH DRIVE (NT:20) MODEL W/X/Y/K1 | ||
| 1 | 08211-22281 | WASHER MODEL V | 1 |
| 1 | 09181-22139 | WASHER (22X28X1.0) MODEL W/X/Y/K1 | 1 |
| 1 | 09380-22006 | CIRCLIP | 1 |
| 24251-18B00 | GEAR, 5TH DRIVE (NT:20) MODEL V | ||
| 24251-18B01 | GEAR, 5TH DRIVE (NT:20) MODEL W/X/Y/K1 | ||
| 09167-22013 | WASHER (22.1X27X0.5) | ||
| 1 | 09262-22018 | BEARING, RH (22X50X14) | 1 |
| 24741-18A00 | RETAINER | ||
| 2 | 02112-06123 | SCREW | 2 |
| 1 | 09263-17026 | BEARING, LH (17X30X14) | 1 |
| 1 | 24742-18A00 | RETAINER | 1 |
| 1 | 02112-06123 | SCREW | 1 |
| 24131-35B10 | DRIVESHAFT | ||
| 24311-02C00 | GEAR, 1ST DRIVEN (NT:38) MODEL V | ||
| 24311-02C01 | GEAR, 1ST DRIVEN (NT:38) MODEL W/X/Y/K1 | ||
| 1 | 24332-24500 | BUSH | 1 |
| 2 | 09167-25016 | LOCK WASHER | 2 |
| 2 | 09380-25003 | SNAP RING | 2 |
| 24321-02C00 | GEAR, 2ND DRIVEN (NT:30) | ||
| 1 | 09300-25020 | BUSH | 1 |
| 1 | 08211-25351 | WASHER | 1 |
| 1 | 09380-25003 | SNAP RING | 1 |
| 24331-02C00 | GEAR, 3RD DRIVEN (NT:27) MODEL V | ||
| 24331-02C01 | GEAR, 3RD DRIVEN (NT:28) MODEL W/X/Y/K1 | ||
| 1 | 09169-25001 | LOCK WASHER | 1 |
| 1 | 09167-25016 | LOCK WASHER | 1 |
| 1 | 09167-25013 | WASHER,LOCK (25.1X41X1.5) | 1 |
| 24341-02C00 | GEAR, 4TH DRIVEN (NT:24) MODEL V | ||
| 24341-02C01 | GEAR, 4TH DRIVEN (NT:24) MODEL W/X/Y/K1 | ||
| 24351-18B00 | GEAR, 5TH DRIVEN (NT:19) MODEL V | ||
| 24351-18B01 | GEAR, 5TH DRIVEN (NT:19) MODEL W/X/Y/K1 | ||
| 24571-18A02 | GEAR, REVERSE DRIVEN (NT:34) | ||
| 24333-18A00 | BUSH,REVERSE DRIVEN GEAR | ||
| 24581-18A00 | DOG | ||
| 1 | 09167-25017 | WASHER (25.1X40X1.5) | 1 |
| 1 | 09262-20059 | BEARING, RH (20X42X12) | 1 |
| 1 | 09262-30081 | BEARING (30X62X16) MODEL V/W/X | 1 |
| 1 | 09262-30084 | BEARING (30X62X16) MODEL Y/K1 | 1 |
| 24551-35B10 | SHAFT, REVERSE IDLER | ||
| 24561-18A02 | GEAR, REVERSE IDLER (NT:29) | ||
| 09300-20034 | BUSH, REVERSE IDLE GEAR | ||
| 1 | 08211-20301 | THRUST WASHER MODEL V | 1 |
| 1 | 09181-20195 | THRUST WASHER (20X30X1.0) MODEL W/X/Y/K1 | 1 |
| 1 | 24751-35B10 | RETAINER | 1 |
| 1 | 09283-38017 | OIL SEAL (38X52X8) | 1 |
| 1 | 09280-70009 | O RING (D:2.5,ID:71.9) | 1 |
| 2 | 01550-08203 | BOLT | 2 |
| 1 | 09100-08259 | BOLT (8X20) | 1 |
| 1 | 09100-08260 | BOLT (8X30) | 1 |
| 2 | 09160-08043 | WASHER (8.5X18X1) | 2 |
| 1 | 27511-35B00 | SPROCKET, ENGINE (NT:11) | 1 |
| 1 | 09280-21008 | O RING (D:2.5,ID:21) | 1 |
| 1 | 27531-35B10 | SPACER (L:25.1) | 1 |
| 1 | 09140-18008 | NUT | 1 |
| 1 | 09167-22012 | LOCK WASHER | 1 |
| 1 | 27600-34A40-084 | CHAIN, DRIVE (RK520SMO-Z9) | 1 |
| 1 | 27641-35B00 | PLATE, FRONT CHAIN GUIDE | 1 |
| 26460-18A11 | GEAR, ODOMETER DRIVE MODEL Y/K1 P28 | ||
| 26471-24200 | GEAR, ODOMETER DRIVEN MODEL Y/K1 P28 | ||
| 26481-24200 | SLEEVE, ODOMETER MODEL Y/K1 P28 | ||
| 26482-02C00 | CAP, ODOMETER MODEL Y/K1 P28 | ||
| 26483-02C00 | GASKET, SLEEVE CAP MODEL Y/K1 P28 | ||
| 1 | 09135-06002 | BOLT, SLEEVE MODEL Y/K1 P28 | 1 |
| 1 | 09168-06004 | GASKET, SLEEVE BOLT MODEL Y/K1 P28 (6.2X11X1.2) | 1 |
| 1 | 09280-10001 | O RING (D:1.3,ID:9.6) MODEL Y/K1 P28 | 1 |
| 1 | 08211-17241 | WASHER MODEL Y/K1 P28 | 1 |
