Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11851-HB5-000 | PLATE, CYLINDER HEAD HANGER | ||
| 12200-HB3-000 | CYLINDER HEAD | ||
| 12204-HB3-300 | GUIDE, VALVE | ||
| 12204-HB3-305 | GUIDE, VALVE (OS) | ||
| 12211-HB3-000 | HOLDER, CAM | ||
| 1 | 12251-HB3-003 | GASKET, CYLINDER HEAD | 1 |
| 12252-HB3-305 | GASKET, CYLINDER HEAD (OS 0.75-1.00) (Optional). | ||
| 12310-HB3-000 | COVER, CYLINDER | ||
| 12311-HB3-000 | COVER, TAPPET ADJUSTING HOLE | ||
| 12315-HB3-000 | COVER, BREATHER | ||
| 12320-HB5-010 | LIFTER, VALVE | ||
| 12325-HB3-003 | CAM, VALVE LIFTER | ||
| 12327-HB5-000 | STAY, CABLE HOLDER | ||
| 12352-HB5-000 | SPRING, CAM DECOMPRESSION | ||
| 12391-HB3-000 | GASKET, HEAD COVER | ||
| 12391-HB3-003 | GASKET, HEAD COVER | ||
| 12391-HB3-004 | GASKET, HEAD COVER | ||
| 12391-HB3-013 | GASKET, HEAD COVER | ||
| 12396-HB3-003 | GASKET, BREATHER COVER | ||
| 14450-HB3-010 | SHAFT, ROCKER ARM IN. | ||
| 14460-HB3-010 | SHAFT, ROCKER ARM EX. | ||
| 16210-HB5-000 | INSULATOR, CARBURETOR | ||
| 28291-HB5-003 | CABLE, DECOMPRESSION | ||
| 32925-HB5-000 | CLIP, IGNITION WIRE | ||
| 2 | 95700-06055-00 | BOLT, FLANGE (6X55) | 2 |
| 2 | 95701-06055-00 | BOLT, FLANGE (6X55) | 2 |
| 1 | 90084-HB3-000 | CAP (14MM) | 1 |
| 1 | 90084-HB5-000 | CAP (14MM) | 1 |
| 1 | 90084-MN8-010 | CAP (14MM) | 1 |
| 2 | 90301-MA6-003 | NUT, FLANGE CAP (6MM) | 2 |
| 3 | 90441-706-000 | WASHER, SEALING (6MM) | 3 |
| 4 | 90465-MC4-000 | WASHER (8MM) | 4 |
| 1 | 90602-KA4-741 | CIRCLIP (OUTER) (6MM) | 1 |
| 91203-HB3-004 | OIL SEAL (8X15X6) | ||
| 2 | 91301-200-000 | O-RING (10X1.6) | 2 |
| 2 | 91301-812-000 | O-RING (10MM) | 2 |
| 2 | 91302-PJ4-000 | O-RING (9.8MM) | 2 |
| 2 | 91302-PJ4-004 | O-RING (9.6X1.9) (ARAI) | 2 |
| 2 | 91303-HB3-003 | O-RING (9.8X1.9) | 2 |
| 2 | 91303-729-720 | O-RING (9.8X1.9) | 2 |
| 2 | 91303-729-721 | O-RING (9.8MM) | 2 |
| 2 | 91305-PE2-003 | O-RING (9.8X1.9) | 2 |
| 1 | 91303-377-000 | O-RING (13.8X2.5) | 1 |
| 1 | 91304-HB3-003 | O-RING (33.5X3.0) | 1 |
| 2 | 91313-MA6-005 | O-RING (4.8X1.9) (NOK) | 2 |
| 2 | 92712-06028-0B | BOLT, STUD (6X28) | 2 |
| 1 | 92900-06020-0B | BOLT 2, STUD (6X20) | 1 |
| 92900-06020-3B | BOLT 2, STUD (6X20) | ||
| 1 | 94050-06000 | NUT, FLANGE (6MM) | 1 |
| 4 | 94050-08000 | NUT, FLANGE (8MM) | 4 |
| 2 | 94101-06000 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06080 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06800 | WASHER, PLAIN (6MM) | 2 |
| 4 | 94301-10140 | PIN A, DOWEL (10X14) | 4 |
| 1 | 95700-06040-07 | BOLT, FLANGE (6X40) | 1 |
| 1 | 95701-06040-07 | BOLT, FLANGE (6X40) | 1 |
| 1 | 95700-06070-00 | BOLT, FLANGE (6X70) | 1 |
| 1 | 95700-06070-07 | BOLT, FLANGE (6X70) | 1 |
| 1 | 95701-06070-00 | BOLT, FLANGE (6X70) | 1 |
| 1 | 95701-06070-07 | BOLT, FLANGE (6X70) | 1 |
| 95700-06080-07 | BOLT, FLANGE (6X80) | ||
| 95701-06080-07 | BOLT, FLANGE (6X80) | ||
| 2 | 95701-06022-08 | BOLT, FLANGE (6X22) | 2 |
| 2 | 95800-06022-08 | BOLT, FLANGE (6X22) | 2 |
| 2 | 95801-06022-08 | BOLT, FLANGE (6X22) | 2 |
| 1 | 96000-06014-00 | BOLT, FLANGE (6X14) | 1 |
| 1 | 96001-06014-00 | BOLT, FLANGE (6X14) | 1 |
| 2 | 96000-06014-07 | BOLT, FLANGE (6X14) | 2 |
| 2 | 96001-06014-07 | BOLT, FLANGE (6X14) | 2 |
| 2 | 96000-06018-00 | BOLT, FLANGE (6X18) | 2 |
| 2 | 96001-06018-00 | BOLT, FLANGE (6X18) | 2 |
| 3 | 96300-08020-07 | BOLT, FLANGE (8X20) | 3 |
| 3 | 96400-08020-07 | BOLT, FLANGE (8X20) | 3 |
| 2 | 96300-06014-00 | BOLT, FLANGE (6X14) | 2 |
| 2 | 96500-06014-00 | BOLT, FLANGE (6X14) | 2 |
| 1 | 98069-38716 | SPARK PLUG (DR8ES-L) (NGK) | 1 |
| 1 | 98069-38719 | SPARK PLUG (DR8ES-L) (NGK) | 1 |
| 1 | 98069-58726 | SPARK PLUG (X24ESR-U) (DENSO) | 1 |
