Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 415130111 | ORANGE FRAME RENEGADE Package Adrenaline Frame Orange Crush Models | ||
| 415130113 | BLACK FRAME RENEGADE Renegade Frame Deep Black Models | ||
| 415130113 | BLACK FRAME RENEGADE Package Adrenaline Frame Deep Black Models | ||
| 415130114 | BLACK FRAME RENEGADE ENDURO Package Enduro Frame Deep Black Models | ||
| 415130172 | FRAME Package Enduro Frame Tactical Gray Models | ||
| 1 | 518325371 | MAG Engine Support | 1 |
| 1 | 518325782 | RH Deflector, Black Polypropylene | 1 |
| 1 | 518325783 | LH Deflector, Black Polypropylene | 1 |
| 4 | 293150104 | Pop Rivet 3/16" | 4 |
| 2 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 2 |
| 1 | 518325560 | Adhesive Patch | 1 |
| 1 | 518327907 | Front Radiator Ass'y | 1 |
| 5 | 293150203 | Rivet Avibulb 3/16 | 5 |
| 3 | 293150174 | Hemlock Rivet, 6.4 mm | 3 |
| 1 | 518326937 | RH Reinforcement, Running Board | 1 |
| 1 | 518326938 | LH Reinforcement, Running Board | 1 |
| 1 | 518325973 | RH Rear Base | 1 |
| 1 | 518325974 | LH Rear Base | 1 |
| 1 | 293450275 | Insert | 1 |
| 1 | 518326656 | Seal | 1 |
| 1 | 518327105 | Rear Cap | 1 |
| 2 | 293450275 | Insert | 2 |
| 1 | 518328942 | RH Stirup | 1 |
| 1 | 390909200 | Avex Rivet | 1 |
| 1 | 293450268 | Insert M5 X 0.8 | 1 |
| 1 | 518328528 | LH Stirup | 1 |
| 3 | 250000752 | Torx Screw M8 X 1.25 X 25, Scotch Grip | 3 |
| 1 | 293730042 | Full Moon Dart 5 mm | 1 |
| 4 | 293450268 | Insert M5 X 0.8 | 4 |
| 22 | 293150203 | Rivet Avibulb 3/16 | 22 |
| 4 | 390909100 | Avex Rivet | 4 |
| 8 | 293150144 | Stavex Rivet | 8 |
| 12 | 293150146 | Henrob Rivet | 12 |
| 1 | 518328947 | Module E | 1 |
| 1 | 518326328 | RH Side Member | 1 |
| 1 | 518326330 | LH Side Member | 1 |
| 1 | 518326198 | Front Member | 1 |
| 6 | 293150144 | Stavex Rivet | 6 |
| 2 | 293150120 | Hemlock Rivet 6.5 mm | 2 |
| 4 | 293150119 | Hemlock Rivet, 6.5 mm | 4 |
| 2 | 505073317 | Leg Cushion | 2 |
| 2 | 250000349 | Torx Truss Screw M6 X 10 | 2 |
| 2 | 234062410 | Flat Washer 6 mm | 2 |
| 1 | 518326954 | Rh Suspension Bracket | 1 |
| 1 | 518326955 | LH Suspension Bracket | 1 |
| 1 | 518327093 | RH Roller | 1 |
| 1 | 518327094 | LH Roller Package Adrenaline Frame Orange Crush Models | 1 |
| 1 | 518327094 | LH Roller Renegade Frame Deep Black Models | 1 |
| 1 | 518327094 | LH Roller Package Adrenaline Frame Deep Black Models | 1 |
| 1 | 518328429 | LH Roller Package Enduro Frame Deep Black Models | 1 |
| 1 | 518328429 | LH Roller Package Enduro Frame Tactical Gray Models | 1 |
| 1 | 518326641 | Rear Radiator Ass'y, 137" | 1 |
| 1 | 293150144 | Stavex Rivet | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 518327392 | Brace Ass'y Includes 200 to 200a | 1 |
| 1 | 234281474 | Conical Spring Washer M8 | 1 |
| 2 | 390407200 | Pop Rivet 3/16” | 2 |
| 1 | 518328320 | Cross Member S Module | 1 |
| 1 | 518327487 | Front Suspension Support | 1 |
| 1 | 518327565 | Front Member | 1 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 2 | 250000822 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 207662544 | Hex. Flange Screw M6 X 25 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 6 | 293150191 | Monobolt Rivet, 4.8 mm | 6 |
| 2 | 293150182 | Monobolt Rivet 6.4 | 2 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 1 | 518327460 | Driven Pulley Support Includes 500 to 500a | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 3 | 250000351 | Hex. Flange Screw M8 X 25, Nylon | 3 |
| 1 | 518326559 | Rear Member | 1 |
| 2 | 518325114 | Upper Lateral Column Support | 2 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 2 | 233261416 | Elastic Flange Nut M6 X 1.0 | 2 |
| 1 | 518326657 | Center Column Support | 1 |
| 1 | 518325481 | Black Rear Bumper 137" Renegade North America Models | 1 |
| 1 | 518326414 | Black Rear Bumper Renegade Europe Models | 1 |
| 1 | 520000965 | Black RH Cap Renegade Europe Models | 1 |
| 1 | 520000964 | Black LH Cap Renegade Europe Models | 1 |
| 2 | 520000840 | BLACK CAP Renegade North America Models | 2 |
| 3 | 293730047 | Black, Dart 8 mm | 3 |
| 2 | 293730060 | Black, Dart 10 mm Except Grand Touring | 2 |
| 1 | 518326973 | Front Tunnel Protector Includes 1700 to 1700a | 1 |
| 1 | 517124300 | Washer | 1 |
| 3 | 293150108 | Pop Rivet 3/16” | 3 |
| 860200267 | TUNNEL PROTECTOR KIT | ||
| 1 | 518327145 | Sub A Support | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 4 | 250000779 | Torx Screw M6 X 1.0 X 18, Scotch Grip | 4 |
| 6 | 224061201 | Flat Washer | 6 |
