Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8GE-21940-00-00 | Front Frame Comp | 1 |
| 1 | 8FA-W2197-11-00 | . Bulkhead | 1 |
| 2 | 90381-15001-00 | . . ..Bush, Solid | 2 |
| 2 | 90381-16001-00 | . . Bush, Solid | 2 |
| 1 | 8FA-W2198-11-00 | . Bulkhead 2 | 1 |
| 3 | 95827-08060-00 | . .Bolt, Flange | 3 |
| 1 | 95827-08065-00 | . .Bolt, Flange | 1 |
| 4 | 95607-08200-00 | . Nut, Self-Locking | 4 |
| 1 | 8FA-2128A-00-00 | . Bracket, Regulator | 1 |
| 1 | 8FG-21947-00-00 | . .Bracket, Steering 1 | 1 |
| 4 | 95607-10200-00 | . Nut, U Flange | 4 |
| 8EP-12440-00-00 | . Heat Exchanger Assy | ||
| 1 | 8FA-12551-00-00 | . .Hose 7 | 1 |
| 1 | 90467-28046-00 | . .Clip | 1 |
| 1 | 90450-35001-00 | . Hose Clamp Assy | 1 |
| 1 | 93306-20650-00 | . Bearing | 1 |
| 1 | 99009-62500-00 | . Circlip | 1 |
| 1 | 95607-08200-00 | . Nut, Self-Locking | 1 |
| 63 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 63 |
| 1 | 8ES-2131D-00-00 | . .Plate, Cover | 1 |
| 6 | 90267-48016-00 | . Rivet, Blind (4.8X16.4 Yellow | 6 |
| 1 | 8GE-21950-00-00 | Rear Frame Comp | 1 |
| 1 | 8FS-W2199-00-00 | . Reineforcement, Frame Rear 1 | 1 |
| 2 | 8FS-21943-00-00 | . Bracket, Main Track 1 | 2 |
| 2 | 8CR-2194N-00-00 | . .Bracket, Fuel Tank 1 | 2 |
| 1 | 8FA-2194X-00-00 | . .Bracket 1 | 1 |
| 1 | 8FA-2195X-00-00 | . .Bracket 2 | 1 |
| 1 | 8ES-2194H-00-00 | . .Protector, Muffler | 1 |
| 1 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow QTY:139 | 1 |
| 1 | 8FS-21916-00-00 | . Panel, Sub Frame 5 | 1 |
| 1 | 8FS-21963-00-00 | . .Patch 3 | 1 |
| 1 | 8FS-21964-00-00 | . .Patch 4 | 1 |
| 1 | 8FS-1241A-00-00 | . .Heat Exchanger Assy 4 | 1 |
| 1 | 90210-06006-00 | . . Washer, Seal | 1 |
| 1 | 98507-06008-00 | . .Screw, Pan Head | 1 |
| 2 | 8FK-21953-00-00 | . ..Bracket, Main Track 2 | 2 |
| 1 | 8FS-21926-00-00 | . .Reinforcement, Footrest 1 | 1 |
| 1 | 8FS-21936-00-00 | . .Reinforcement, Footrest 2 | 1 |
| 1 | 90465-08125-00 | . Clamp | 1 |
| 1 | 8FS-21961-00-00 | . Patch 1 | 1 |
| 1 | 8FS-21962-00-00 | . Patch 2 | 1 |
| 8GE-W2195-00-00 | Frame Connection Kit | ||
| 2 | 8FN-21939-00-00 | . .Bracket, Chain Housing | 2 |
| 1 | 8FU-2196M-00-00 | . .Bracket, 5 | 1 |
| 1 | 8FU-2197M-00-00 | . .Bracket, 6 | 1 |
| 1 | 8FU-2198G-00-00 | . .Cover 2 | 1 |
| 1 | 8FA-21999-00-00 | . .Clamp, Wire Harness | 1 |
| 70 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 70 |
| 4 | 90267-48018-00 | . Rivet, Blind (4.8X18.6 Black) | 4 |
| 1 | 8FS-21944-00-00 | Bracket, Rr. Track Suspension | 1 |
| 1 | 8FS-21954-00-00 | Bracket, Rr. Track Suspension | 1 |
| 95304-10800-00 | Nut, Crown | ||
| 4 | 90201-104A7-00 | Washer, Plate | 4 |
| 10 | 90267-47197-00 | Rivet, Blind (4.7X19.5 Silver) | 10 |
| 1 | 8FU-21960-00-00 | Footrest Comp. 1 | 1 |
| 1 | 8FU-21970-00-00 | Footrest Comp. 2 | 1 |
| 1 | 8ES-2193E-00-00 | Bracket, Oil Tank 1 | 1 |
| 2 | 95827-08014-00 | Bolt, Flange | 2 |
| 1 | 8EK-21920-01-00 | Housing, Reinf Sub-Assy (L.H) | 1 |
| 1 | 8FU-2198F-00-00 | Cover 1 | 1 |
| 1 | 8FU-2198J-00-00 | Cover 3 | 1 |
| 1 | 8FU-2195E-01-00 | Plate, Steering Bracket 1 | 1 |
| 1 | 8FU-2195F-01-00 | Plate, Steering Bracket 2 | 1 |
| 8FK-2196A-00-00 | Frame Under 1 | ||
| 8EP-2196E-00-00 | Frame, Under 2 | ||
| 1 | 8FA-21972-00-00 | Bracket, Guard Fitting | 1 |
| 6 | 8FA-2196F-00-00 | Bracket 3 | 6 |
| 8 | 90267-48083-00 | Rivet, Blind (4.8X15.2 Silver) | 8 |
| 12 | 90267-48169-00 | .Rivet, Blind (4.8X14.1 Black) | 12 |
| 14 | 90267-48018-00 | Rivet, Blind (4.8X18.6 Black) | 14 |
| 4 | 90267-47200-00 | Rivet, Blind (4.7X19.5 Black) | 4 |
| 1 | 8FA-77512-00-00 | Bumper, Front 2 | 1 |
| 4 | 95827-06012-00 | Bolt, Flange | 4 |
| 1 | 8FA-21949-00-00 | Bracket, Front | 1 |
| 1 | 8FA-21959-00-00 | Bracket, Front Bumper | 1 |
| 2 | 8FA-77125-00-00 | Stay 1 | 2 |
| 6 | 95827-08016-00 | Bolt, Flange | 6 |
| 2 | 95827-08020-00 | Bolt, Flange | 2 |
| 4 | 90267-48095-00 | Rivet, Blind (4.8X12.6 Silver) | 4 |
| 4 | 90267-47195-00 | Rivet, Blind (4.7X16.4 Yellow) | 4 |
| 8FA-2197E-01-00 | Protector, Frame Fr | ||
| 5 | 90109-065F3-00 | Bolt | 5 |
| 5 | 90183-06053-00 | Nut, Spring | 5 |
| 4 | 8FA-21998-00-00 | Spacer | 4 |
| 1 | 8FG-23892-00-00 | Shield, Heat | 1 |
| 13 | 90267-48059-00 | Rivet, Blind (4.8X12.3) | 13 |
| 1 | 8FP-22865-00-00 | Cover, Front | 1 |
| 2 | 90150-06015-00 | Screw, Round Head | 2 |
| 1 | 8ES-2179D-00-00 | Plete, Epa Offroad 2 | 1 |
| 1 | 8FA-21973-00-00 | Hook | 1 |
| 1 | 8CR-77319-00-00 | Damper 1 | 1 |
| 3 | 90267-47195-00 | Rivet, Blind (4.7X16.4 Yellow) | 3 |
| 1 | 8FS-21939-00-00 | . Bracket, Chain Housing | 1 |
