Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 708301016 | Cargo Box Inner LH | 1 |
| 1 | 708301017 | Cargo Box Inner RH | 1 |
| 8 | 250100113 | Panel Nut, M6 X 1.0 | 8 |
| 2 | 250300016 | Ball Head Stud | 2 |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 | 2 |
| 6 | 207662044 | Hex. Flange Screw M6 X 20 | 6 |
| 2 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 2 |
| 2 | 250100113 | Panel Nut, M6 X 1.0 | 2 |
| 2 | 224061201 | Flat Washer | 2 |
| 1 | 708301798 | Storage Bin Ass'y Rear Includes 100 to 100a | 1 |
| 1 | 219704406 | Était/Was 414843500 Velcro #8MVA PSA 1" Not Shown | 1 |
| 1 | 250300039 | Ball Head Stud | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 230663084 | Hex. Flange Screw M6 X 130 | 1 |
| 1 | 233261494 | Hex. Flange Elastic Nut M6 | 1 |
| 2 | 207661244 | Hex. Flange Screw M6 X 12 | 2 |
| 1 | 708301640 | Latch Ass'y LH | 1 |
| 1 | 708301641 | Latch Ass'y RH | 1 |
| 2 | 708300514 | Latch Protector | 2 |
| 1 | 708301642 | Center Latch | 1 |
| 8 | 250000881 | Torx Truss M8 X 16 | 8 |
| 2 | 250200164 | Flat washer M6 | 2 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 4 | 708300006 | Hinge | 4 |
| 16 | 250000881 | Torx Truss M8 X 16 | 16 |
| 8 | 708300129 | Back Plate Support | 8 |
| 2 | 708300394 | Spacer | 2 |
| 2 | 207664544 | Hex. Flange Screw M6 X 45 | 2 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 2 | 708300011 | Gaz Shock | 2 |
| 1 | 708300383 | Gaz Shock | 1 |
| 1 | 708300384 | Spacer | 1 |
| 1 | 250000843 | Torx Truss Screw M6 X 30 | 1 |
| 1 | 232361493 | Domed Nut M6 | 1 |
| 1 | 708302620 | Main Control (WO lock cylinder) | 1 |
| 4 | 250000349 | Torx Truss Screw M6 X 10 | 4 |
| 1 | 293830188 | Seal, 1PC = 3M | 1 |
| 1 | 708301106 | Vegas White Pearl, Rear Trunk Cover | 1 |
| 1 | 708300678 | Inner Cover | 1 |
| 6 | 250000720 | Torx Screw K50 X 16 | 6 |
| 1 | 708301111 | Vegas White Pearl, LH Trunk Cover | 1 |
| 1 | 708301023 | Cover Interior LH | 1 |
| 1 | 708301112 | Vegas White Pearl, RH Trunk Cover | 1 |
| 1 | 518327441 | Lateral Console Foam | 1 |
| 1 | 708301022 | Cover Interior RH | 1 |
| 2 | 705002423 | Amber, Lateral Reflector Australia | 2 |
| 2 | 705003412 | Red, Lateral Reflector North America | 2 |
| 1 | 708302277 | Fender Rear | 1 |
| 3 | 250000349 | Torx Truss Screw M6 X 10 | 3 |
| 4 | 250000881 | Torx Truss M8 X 16 | 4 |
| 2 | 250000720 | Torx Screw K50 X 16 | 2 |
| 1 | 708300177 | License Plate Light Support | 1 |
| 1 | 708301564 | Vegas White Pearl, Rear Pannel | 1 |
| 4 | 250100113 | Panel Nut, M6 X 1.0 | 4 |
| 4 | 705003207 | Plastic Washer | 4 |
| 1 | 708300022 | LH Passenger Handle | 1 |
| 1 | 708300024 | RH Passenger Handle | 1 |
| 1 | 708300209 | LH Handle Pannel | 1 |
| 1 | 708300405 | Cap | 1 |
| 1 | 708300027 | RH Handle Pannel | 1 |
| 4 | 250000804 | Torx Screw M6 X 12 | 4 |
| 1 | 708300049 | Crontrol Cap | 1 |
| 1 | 708300028 | Under Tail Rear Wheel Cover | 1 |
| 4 | 293150089 | Tuflok Plastic Rivet | 4 |
| 1 | 708300708 | Vegas White Pearl, LH Arm Cover | 1 |
| 1 | 708300709 | Vegas White Pearl, RH Arm Cover | 1 |
| 1 | 708300716 | Vegas White Pearl, LH Antenna Cap | 1 |
| 1 | 708301555 | Sound Box LH | 1 |
| 1 | 708301556 | Sound Box RH | 1 |
| 1 | 708302609 | LH Grille Sup. | 1 |
| 1 | 708302567 | LH Rear Grille Not Shown | 1 |
| 1 | 708302610 | Central LH Rear Grille | 1 |
| 1 | 293720115 | Grommet Not Shown | 1 |
| 1 | 708302611 | RH Grille Sup. Not Shown | 1 |
| 1 | 708302568 | RH Rear Grille Not Shown | 1 |
| 1 | 708302612 | Central RH Rear Grille Not Shown | 1 |
| 1 | 708000614 | Deep Black, LH Arm Rest | 1 |
| 1 | 708000615 | Deep Black, RH Arm Rest | 1 |
| 10 | 250000720 | Torx Screw K50 X 16 | 10 |
| 8 | 250000720 | Torx Screw K50 X 16 | 8 |
| 6 | 269501166 | Nut Housing Ass'y Includes 840 to 840a | 6 |
| 1 | 232561200 | Brass Elastic Stop Nut M6 Not Shown | 1 |
| 6 | 250000880 | Torx-Truss M/S M6 X 25 | 6 |
| 1 | 708300781 | Rear Support Ass'y Includes 860 to 860a1 | 1 |
| 4 | 269500725 | M6 Nut Housing Ass'y Not Shown | 4 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 Not Shown | 1 |
| 4 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip | 4 |
| 1 | 708300327 | LH Inner Fender | 1 |
| 1 | 708300328 | RH Inner Fender | 1 |
| 3 | 250100113 | Panel Nut, M6 X 1.0 | 3 |
| 3 | 250000350 | Torx Truss Screw M6 X 20 | 3 |
| 4 | 250000720 | Torx Screw K50 X 16 | 4 |
| 2 | 708300385 | Retainer Cable | 2 |
| 2 | 250000881 | Torx Truss M8 X 16 | 2 |
| 2 | 211200055 | Flat Washer, Stainless/Neoprene | 2 |
| 2 | 232061414 | Hex. Nut M6 | 2 |
| 1 | 708300397 | Seal | 1 |
| 1 | 705004173 | Heat Shield | 1 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 293750040 | Tie-rap Mount (square - self-adhsive) | 1 |
