Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705600987 | LH Front Caliper Includes 10 to 10b | 1 |
| 1 | 705600988 | RH Front Caliper Includes 10 to 10b | 1 |
| 2 | 219800237 | Brake Pad Kit | 2 |
| 2 | 219800238 | Spring/Pin/Clip Kit | 2 |
| 4 | 207506556 | Hex Flange Screw M10 X 65 | 4 |
| 1 | 705601252 | RH Front Hose Includes 40 to 40a | 1 |
| 2 | 715900250 | Hose Clip Not Shown | 2 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 4 | 207561634 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 4 | 414920600 | Washer | 4 |
| 2 | 705601201 | Banjo Bolt/ Bleeder | 2 |
| 2 | 705601190 | Bleeder Bolt Cap | 2 |
| 1 | 705601253 | LH Front Hose Includes 65 to 65a | 1 |
| 2 | 705601631 | Front Brake Disk | 2 |
| 1 | 705601632 | Rear Brake Disk | 1 |
| 5 | 250000562 | Hex Flange Screw M10 X 25 | 5 |
| 1 | 705600989 | Rear Caliper Includes 90 to 90d | 1 |
| 1 | 219800239 | Brake Pad Kit | 1 |
| 1 | 219800240 | Spring/Pin/Clip Kit | 1 |
| 1 | 219800241 | Rear Cable Support Kit | 1 |
| 1 | 219800242 | Rear Dust Cover | 1 |
| 1 | 705601262 | Rear Caliper Support | 1 |
| 2 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 2 |
| 1 | 705601501 | Brake Line | 1 |
| 2 | 207662054 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 705601201 | Banjo Bolt/ Bleeder | 1 |
| 1 | 705601190 | Bleeder Bolt Cap | 1 |
| 2 | 414920600 | Washer | 2 |
| 1 | 705600722 | Tandem Cylinder Master | 1 |
| 2 | 205583087 | Allen Screw M8 X 30 | 2 |
| 2 | 506151245 | Washer | 2 |
| 1 | 705600468 | Piston Rod | 1 |
| 1 | 232081414 | Hex. Nut M8 | 1 |
| 1 | 705601142 | Yoke Not Shown | 1 |
| 2 | 232081414 | Hex. Nut M8 Not Shown | 2 |
| 1 | 250400058 | Pin Not Shown | 1 |
| 1 | 234081430 | Flat Washer M8 Not Shown | 1 |
| 1 | 371800700 | Cotter Pin Not Shown | 1 |
| 1 | 250400064 | Rod Clamp | 1 |
| 1 | 371800700 | Cotter Pin | 1 |
| 1 | 705600716 | Bellow | 1 |
| 1 | 509000442 | Oeticker Gear Clamp, 25.6-706R | 1 |
| 1 | 705601315 | Carbon Black, Brake Pedal | 1 |
| 1 | 705004933 | Rubber Pad | 1 |
| 2 | 210261250 | Hex. Flange Screw M6 X 12 | 2 |
| 2 | 705600458 | Bearing | 2 |
| 1 | 705601275 | Bushing | 1 |
| 2 | 293300191 | O-Ring | 2 |
| 2 | 503183800 | Washer | 2 |
| 1 | 705601346 | Tab Lock | 1 |
| 1 | 250000717 | Torx Head Screw M6 X 16 | 1 |
| 1 | 708000759 | Rubber Stopper | 1 |
| 5 | 705601513 | Rigid Tube Support | 5 |
| 1 | 705601157 | Tandem Rigid Tube | 1 |
| 1 | 705601158 | Tandem Rigid Tube | 1 |
| 2 | 507032551 | Banjo Bolt | 2 |
| 1 | 705601159 | Rear Brake Rigid Tube | 1 |
| 1 | 705600855 | Rocker Arm | 1 |
| 1 | 705600541 | Bushing | 1 |
| 1 | 207206534 | Hex. Screw M10 X 65, Scotch Grip | 1 |
| 1 | 705601526 | Master Cylinder Reservoir Ass'y Includes 500 to 500e | 1 |
| 1 | 219800350 | Diaphragm Cover Ass'y | 1 |
| 2 | 705601073 | Oil Level Sensor | 2 |
| 1 | 705601294 | Spindle Lock | 1 |
| 2 | 211100002 | Push Nut | 2 |
| 2 | 710002033 | Connector Holder | 2 |
| 1 | 219704415 | Hose 4.32Mm 3000Mm Long Not Shown | 1 |
| 219704417 | HOSE 8MM 3000MM LONG | ||
| 1 | 705601486 | Bracket | 1 |
| 4 | 293650047 | Crimp Clamp, 15.3-706R | 4 |
| 1 | 705600502 | Bleeder Screw | 1 |
| 1 | 707001058 | Parking Brake Cable | 1 |
| 1 | 415052400 | Bracket | 1 |
| 1 | 515175507 | Open Clamp | 1 |
| 1 | 210262050 | Hexagonal Head Screw | 1 |
| 1 | 705600959 | Connecting Rod | 1 |
| 2 | 250400064 | Rod Clamp | 2 |
| 2 | 371800700 | Cotter Pin | 2 |
| 1 | 705600768 | Front Pulley Cable Includes 800 to 800a | 1 |
| 1 | 233201464 | Hex. Flange Elastic M10 x 1.5 | 1 |
| 1 | 293900087 | Bushing | 1 |
| 1 | 207604054 | Hex. Flange Screw M10 X 40 | 1 |
