Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 95302-05700-00 | . . . . Nut #1, 3 | 1 |
| 89A-14276-00-00 | . . . . Lever #1, 3 | ||
| 1 | 89A-14286-00-00 | . . . . Spring #1, 3 | 1 |
| 89A-14905-00-00 | . . . . Lever, Starter #1, 3 | ||
| 8EK-14251-00-00 | . . . Nipple #1, 3 | ||
| 4 | 98501-04014-00 | . . .Screw, Pan Head | 4 |
| 1 | 12R-14191-00-00 | . . Plug, Drain | 1 |
| 1 | 239-14172-10-00 | . . ..Pilot Jet, Air (1.0) | 1 |
| 302-14173-00-00 | . . ..Cover, Plunger Cap | ||
| 8EK-14171-00-00 | . . ..Plunger, Starter | ||
| 1 | 1AW-14135-00-00 | . . ..Spring, Plunger | 1 |
| 1FN-14174-00-00 | . . ..Cap, Plunger | ||
| 1 | 1AE-14147-00-00 | . . ..O-Ring | 1 |
| 8CH-14995-00-00 | . . ..Bracket #2 | ||
| 1 | 98502-04010-00 | . . .Screw, Pan Head #2 | 1 |
| 1 | 8CC-14122-00-00 | . . ..Screw, Throttle #2 | 1 |
| 1 | 2J2-14133-00-00 | . . ..Spring, Throttle Stop #2 | 1 |
| 1 | 89A-14265-00-00 | . . ..Collar #2 | 1 |
| 1 | 22F-14117-00-00 | . . Washer, Plug Screw #2 | 1 |
| 1UF-14952-00-00 | . . ..Washer #2 | ||
| 1 | 89A-14594-00-00 | . . ..Nut #2 | 1 |
| 1 | 89A-24529-00-00 | . . ..Spring #2 | 1 |
| 1 | 87S-8259A-00-00 | . . Switch, Carburetor #2 | 1 |
| 98702-05008-00 | . . ..Screw, Flat Head #2 | ||
| 8EK-14348-00-00 | . . . . Pipe 1 #1, 3 | ||
| 8EK-14349-00-00 | . . . . Pipe #1, 3 | ||
| 8CH-14348-00-00 | . . . . Pipe 1 #1, 3 | ||
| 8F2-14197-00-00 | . . .Pipe #2 | ||
| 3 | 89A-14198-00-00 | . .Gasket | 3 |
| 6 | 97605-04110-00 | . .Screw, Pan Head With Washer | 6 |
| 98702-04014-00 | . Screw, Flat Head | ||
| 1AE-14135-00-00 | . .Spring, Plunger | ||
| 3H1-14227-00-00 | . .Washer | ||
| 89A-14264-00-00 | . .Collar | ||
| 1 | 8EX-14589-00-00 | . .Spring | 1 |
| 89A-14118-00-00 | . .Cap | ||
| 2 | 97602-04116-00 | . Screw, Pan Head With Washer | 2 |
| 89A-14208-00-00 | . .Lever Comp. 1 | ||
| 3 | 11H-14991-00-00 | . Screw | 3 |
| 12 | 98502-05012-00 | . Screw, Pan Head | 12 |
| 6 | 35H-14139-00-00 | . Clip, Pipe | 6 |
| 8CH-14978-00-00 | . .Shaft, Starter Lever | ||
| 4 | 90467-10035-00 | . Clip | 4 |
| 8CH-14987-10-00 | . .Hose | ||
| 1 | 97602-05110-00 | . Screw, Pan Head With Washer | 1 |
| 3FV-14962-00-00 | . .Washer | ||
| 89A-14588-00-00 | . .Lever | ||
| 1 | 22F-14117-00-00 | . Washer, Plug Screw | 1 |
| 22F-14115-00-00 | . .Plug, Screw | ||
| 1 | 5FL-85885-00-00 | . .Throttle Sensor Assy | 1 |
| 2 | 8CC-14216-10-00 | . .Screw | 2 |
| 8DN-82309-00-00 | . .Wire, Sub Lead | ||
| 1 | 4N0-14251-00-00 | . .Nipple | 1 |
| 8EK-14251-00-00 | . Nipple | ||
| 89A-24452-00-00 | . .Cover | ||
| 1 | 8EK-14100-10-00 | Carburetor Assy | 1 |
| 1 | 8EK-14101-10-00 | . .Carburetor Assy 1 | 1 |
| 1 | 8EK-14102-10-00 | . .Carburetor Assy 2 | 1 |
| 8EK-14103-10-00 | . .Carburetor Assy 3 | ||
| 1 | 89A-14292-00-00 | . . ..Lever A #2 | 1 |
| 1 | 89A-14243-00-00 | . . ..Plate | 1 |
| 1 | 89A-14137-00-00 | . . ..Clip | 1 |
| 1 | 89A-14199-00-00 | . . ..Gasket | 1 |
| 8CC-14216-00-00 | . . ..Screw | ||
| 1 | 89A-14188-00-00 | . . ..Connector | 1 |
| 2 | 3MA-14918-00-00 | . . ..Ring | 2 |
| 2 | 3GF-14126-00-00 | . . ..Gasket | 2 |
| 1 | 620-14198-00-00 | . . ..Gasket | 1 |
| 1 | 3MA-14937-00-00 | . . ..Clip | 1 |
| 1 | 3MA-14159-00-00 | . . .Clip | 1 |
| 2 | 8AB-14227-00-00 | . . ..Washer (T=0.4Mm) | 2 |
| 1 | 8EK-14112-15-00 | . . ..Valve, Throttle 1 | 1 |
| 1 | 3H1-14147-00-00 | . . .O-Ring | 1 |
| 1 | 3H1-14962-00-00 | . . .Washer | 1 |
| 1 | 5K7-14134-00-00 | . . .Spring, Air Adjusting | 1 |
| 1 | 89A-14565-00-00 | . . ..Screw, Pilot Adjusting | 1 |
| 1 | 3H1-14142-55-00 | . . Jet, Pilot (#55) AP | 1 |
| 1 | 3H1-14142-52-00 | . . Jet, Pilot (#52.5) AP | 1 |
| 1 | 3H1-14142-47-00 | . . Jet, Pilot (#47.5) AP | 1 |
| 1 | 3H1-14142-45-00 | . . Jet, Pilot (#45) STD | 1 |
| 1 | 3H1-14142-50-00 | . . Jet, Pilot (#50) AP | 1 |
| 1 | 89A-14996-00-00 | . . ..Pipe | 1 |
| 1T1-14116-A4-00 | . . ..Needle | ||
| 89A-14141-48-00 | . . ..Nozzle, Main | ||
| 1 | 1LX-14153-00-00 | . . ..Washer, Main Jet | 1 |
| 1 | 89A-14194-00-00 | . . ..Ring | 1 |
| 1 | 3G2-1423A-82-00 | . . ..Jet, Main (#157.5) AP | 1 |
| 1 | 3G2-1423E-60-00 | . . ..Jet, Main (#151.3) AP | 1 |
| 1 | 3G2-1423E-61-00 | . . Jet, Main (#153.8) AP | 1 |
| 1 | 3G2-1423E-59-00 | . . Jet, Main (#148.8) AP | 1 |
| 1 | 3G2-1423E-58-00 | . . ..Jet, Main (#146.3) AP | 1 |
| 1 | 3G2-1423E-62-00 | . . ..Jet, Main (#156.3) STD | 1 |
| 3G2-1423E-63-00 | . . ..Jet, Main (#158.8) AP | ||
| 1 | 3G2-1423E-56-00 | . . Jet, Main (#141.3) AP | 1 |
| 1 | 3G2-1423A-80-00 | . . ..Jet, Main (#147.5) AP | 1 |
| 1 | 3G2-1423E-55-00 | . . Jet, Main (#138.8) AP | 1 |
| 1 | 3G2-14231-30-00 | . . ..Jet, Main (#150) AP | 1 |
| 1 | 3G2-1423E-57-00 | . . Jet, Main (#143.8) AP | 1 |
| 1 | 3G2-1423A-81-00 | . . ..Jet, Main (#152.5) AP | 1 |
| 1 | 3G2-14231-28-00 | . . ..Jet, Main (#140) AP | 1 |
| 1 | 3G2-14231-29-00 | . . Jet, Main (#145) AP | 1 |
| 1 | 3G2-14231-32-00 | . . .Jet, Main (#160) AP | 1 |
| 1 | 3G2-14231-31-00 | . . ..Jet, Main (#155) AP | 1 |
| 1 | 500-14115-00-00 | . . ..Plug, Screw | 1 |
| 1 | 558-14147-00-00 | . . O-Ring | 1 |
| 1 | 2LN-14565-00-00 | . . ..Screw | 1 |
| 8EK-14185-00-00 | . . ..Float | ||
| 1 | 537-14186-00-00 | . . Pin, Float | 1 |
| 1 | 1AE-14190-13-00 | . . ..Needle Valve Assy | 1 |
| 1 | 89A-14147-00-00 | . . ..O-Ring | 1 |
| 1 | 8F2-14147-00-00 | . . ..O-Ring | 1 |
| 1 | 1J7-14994-00-00 | . . Net, Filter | 1 |
| 1 | 89A-14216-00-00 | . . . . Screw #1, 3 | 1 |
