Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3280258 | SPEEDO,KILOMETER,3",ATV (Incl. 13,14)(A99CH33IA) | ||
| 1 | 3280326 | SPEEDOMETER ASSEMBLY, 3 IN, ATV (See Footnote) (Incl. 13,14)(A99CH33AA)(A99CH33AB) | 1 |
| 4040013 | INDICATOR HI-BEAM WARN. | ||
| 1 | 4040053 | HOT TEMPERATURE INDICATOR | 1 |
| 1 | 4040054 | INDIC NEUT./REV. | 1 |
| 3 | 7511881 | SCREW | 3 |
| 3 | 7670086 | NUT (10) | 3 |
| 1 | 2460574 | HARNESS,WIRE,INDIC,LOW. | 1 |
| ------- | Asm., Throttle Control (See Footnote) (See Controls - Throttle Asm./Cable Pg. B10, Ref. 5) | ||
| 1 | 5224607-067 | HANDLEBAR TUBE, MEDIUM GLOSS BL | 1 |
| 2460573 | Discontinued | ||
| 2460387 | HARNESS, SPEEDO | ||
| 2200774 | Discontinued (Incl. Blocks & 10,12,30) | ||
| 5630616-067 | Discontinued | ||
| 1 | 4030015 | BULB TAILLIGHT/TACH/SPEEDO (10) | 1 |
| 4 | 7515189 | SCREW | 4 |
| 3280175 | CLAMP,BACK,SPEEDO. | ||
| 1 | 3280174 | GASKET,SHOCK MT. | 1 |
| 5431812-136 | POD,H/L,UP.,RED (A99CH33AB)(A99CH33IA) | ||
| 5431812-191 | POD,H/L,UP,OLV.GRN. (A99CH33AA) | ||
| ------- | Asm., Master Cylinder (See Footnote) (See Controls - Master Cyl./Brake Line Pg. B11) | ||
| 5433198 | SPACER-PLASTIC (.88) | ||
| 1 | 4110193 | HI/LO/OFF HANDLEBAR SWITCH, LEF | 1 |
| 2 | 5431030 | HANDLEBAR GRIP, 7/8 ID, GLOSS B | 2 |
| 2010055 | SCREW | ||
| 1 | 5240586-067 | POD MOUNTING BRACKET, BLACK | 1 |
| 2 | 7517317 | SCREW | 2 |
| 1 | 4032079 | ADJUSTING KNOB | 1 |
| 1 | 5411120 | HEADLIGHT BOOT | 1 |
| 1 | 4032077 | COLLAR LOCK | 1 |
| 1 | 2870448 | HEADLIGHT BULB | 1 |
| 4032075 | ASM,HEADLIGHT W/ADJUST ROD-KNOB | ||
| 4032098 | DESC NOT_AVAILABLE | ||
| 2 | 5410163 | O-RING | 2 |
| 1 | 2200188 | CHOKE CONTROL KIT | 1 |
| 1 | 7080726 | CHOKE CABLE W/ ADJUSTER | 1 |
| 4 | 7542122 | NYLOK NUT | 4 |
| 2 | 7670089 | NUT,U-TYPE | 2 |
| 7522021 | Discontinued | ||
| 2460471 | Discontinued | ||
| 2410025 | POWERPLUG ASM,12V | ||
| 2 | 7621334 | RIVET | 2 |
| 1 | 5432314-070 | HEADLIGHT POD, LOWER, GLOSS BLA | 1 |
| 4110194 | IGNITION SWITCH (Incl. Key) | ||
| 1 | 5431964 | KEY COVER-KEYSWITCH | 1 |
| 1 | 7080229 | NUT-CHOKE SLIDE | 1 |
| 3280236 | Discontinued | ||
| 7555725 | WASHER | ||
| 7515378 | BOLT | ||
| ------- | Adaptor, Drive (See Footnote) (See Gearcase - Cases and Snorkel Pg. D3, Ref. 5) | ||
| ------- | Key, Speedometer (See Footnote) (See Gearcase - Cases and Snorkel Pg. D3, Ref. 6) | ||
| ------- | Seal (See Footnote) (See Gearcase - Cases and Snorkel Pg. D3, Ref. 7) | ||
| ------- | Bushing, Speedometer Drive (See Footnote) (See Gearcase - Internal Components Pg. D2, Ref. 34) | ||
| ------- | Shaft, Output, Front Housing (See Footnote) (See Front Housing Pg. C13, Ref. 24) | ||
| 4110141 | KEYBLANK,ATV IGN,31 SERIES | ||
| 4110148 | KEYBLANK,ATV IGN,32 SERIES (See Footnote) NOTE: Ignition key may be ordered by using the four digit number on the key. |
