Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 517305744 | Black, Front Hood | 1 |
| 1 | 517306362 | Hyper Silver, Front Hood | 1 |
| 4 | 250000528 | Torx Screw M5 X 20 | 4 |
| 4 | 250000079 | Panel Nut M5 X 0.8 | 4 |
| 2 | 233251494 | Elastic Flange Nut M5 | 2 |
| 2 | 250200040 | Flat Washer | 2 |
| 2 | 250000587 | Torx Screw M5 X 26 | 2 |
| 2 | 250200166 | Washer | 2 |
| 1 | 517305763 | RH Front Hood Foam | 1 |
| 1 | 517305764 | LH Front Hood Foam | 1 |
| 1 | 517306007 | Black - Hood RH | 1 |
| 1 | 517306363 | Hyper Silver, RH Hood | 1 |
| 3 | 250000725 | Screw M4 X 16 | 3 |
| 1 | 517306001 | RH Hood Foam | 1 |
| 1 | 517306008 | Black - Hood LH | 1 |
| 1 | 517306364 | Hyper Silver, LH Hood | 1 |
| 1 | 517306002 | LH Hood Foam | 1 |
| 2 | 513033813 | Gasket | 2 |
| 1 | 517306318 | Rear Console | 1 |
| 2 | 250000079 | Panel Nut M5 X 0.8 | 2 |
| 1 | 517304518 | Console Nut | 1 |
| 1 | 517306117 | Indicator Support | 1 |
| 1 | 517305875 | Deep Black, Wind Deflector | 1 |
| 1 | 517306433 | Manta Green, Wind Deflector | 1 |
| 3 | 517303756 | Grommet | 3 |
| 1 | 517305860 | Black, RH Panel Black Model | 1 |
| 1 | 517306367 | Silver, RH Panel Silver Model | 1 |
| 1 | 517305861 | Deep Black, RH Panel Trim | 1 |
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 5 | 517124300 | Washer | 5 |
| 1 | 517305109 | Rivet Plate | 1 |
| 1 | 517305773 | RH Rear Latch | 1 |
| 1 | 517305979 | RH Front Latch | 1 |
| 5 | 250000725 | Screw M4 X 16 | 5 |
| 1 | 517306311 | RH Hook | 1 |
| 1 | 517305864 | Black, LH Panel Black Model | 1 |
| 1 | 517306369 | Silver, LH Panel Silver Model | 1 |
| 1 | 517305865 | Black - Panel Trim LH | 1 |
| 8 | 293150104 | Pop Rivet 3/16" | 8 |
| 8 | 517124300 | Washer | 8 |
| 1 | 517305774 | LH Rear Latch | 1 |
| 1 | 517305980 | LH Front Latch | 1 |
| 1 | 517306312 | LH Hook | 1 |
| 1 | 517305767 | RH Central Panel Foam | 1 |
| 1 | 517306116 | RH Rear Panel Foam | 1 |
| 1 | 517305770 | LH Central Panel Foam | 1 |
| 1 | 517305766 | FOAM | 1 |
| 1 | 517306262 | Rubber Sheet | 1 |
| 1 | 517306480 | RH Rear Panel Foam | 1 |
| 1 | 517305862 | Deep Black, RH Grille | 1 |
| 2 | 250000725 | Screw M4 X 16 | 2 |
| 1 | 517305769 | LH Front Panel Foam | 1 |
| 1 | 517306479 | LH Rear Panel Foam | 1 |
| 2 | 517305985 | Rear Stud | 2 |
| 2 | 517305988 | Front Stud | 2 |
| 4 | 250000725 | Screw M4 X 16 | 4 |
| 1 | 517306309 | RH Lower Latch | 1 |
| 1 | 517306310 | LH Lower Latch | 1 |
| 1 | 293150100 | Pop Rivet 3/16" | 1 |
| 1 | 517124300 | Washer | 1 |
| 1 | 517305290 | Deep Black, LH Arm | 1 |
| 1 | 517305293 | Deep Black, RH Arm | 1 |
| 1 | 517305291 | LH Deflector, Smoked 60% | 1 |
| 1 | 517305294 | RH Deflector, Smoked 60% | 1 |
| 1 | 517305601 | Deep Black, LH Cap, SKI-DOO | 1 |
| 1 | 517306405 | Manta Green, LH Cap | 1 |
| 1 | 517305602 | Deep Black, RH Cap SKI-DOO | 1 |
| 1 | 517306406 | Manta Green, RH Cap | 1 |
| 2 | 517305296 | Clamp | 2 |
| 2 | 250000760 | Torx Screw Truss Head K50X20 T20 | 2 |
| 4 | 250000724 | Torx Screw M5 X 20 | 4 |
| 1 | 517305752 | Headlamp Includes 2400 to 2400a | 1 |
| 2 | 415130081 | Bulb | 2 |
| 1 | 517306049 | RH Hood Plate | 1 |
| 1 | 517306050 | LH Hood Plate | 1 |
| 1 | 517305871 | Deep Black, Cover Ass'y Includes 3200 to 3200a | 1 |
| 1 | 732610072 | Push Nut | 1 |
| 1 | 517306058 | Trunk Ass'y Includes 3400 to 3400a | 1 |
| 2 | 517305157 | Seal Joint | 2 |
| 1 | 517305746 | Deep Black, Headlamp Fairing Black Model | 1 |
| 1 | 517306376 | Fairing - Head-Lamp Silver Model | 1 |
| 1 | 293150089 | Tuflok Plastic Rivet | 1 |
