Каталог / Snowmobile / Ski-Doo / 2018 / RENEGADE 850 E-TEC / Frame Renegade - 850 E-Tec - Package X

Список запчастей

№	Артикул	Название	Кол-во
1	415130177	Black Tunnel Module 137	1
1	518328455	FOOTREST REINFORCEMENT	1
1	518328456	FOOTREST REINFORCEMENT	1
1	518329622	RH Suspension Bracket	1
1	518329621	LH Suspension Bracket	1
1	518329048	RH Reinforcement Footrest	1
1	518329049	LH Footrest Reinforcement	1
2	518329480	Member Fixation Plate	2
1	518328451	RH Roller	1
1	518328452	LH Roller	1
	293450232	Insert M6 X 1.0
2	250300027	Clinch Stud M6 X 20	2
1	518328990	Rear Cap	1
1	518328460	RH Footrest	1
1	518328463	LH Footrest	1
36	293150203	Rivet Avibulb 3/16	36
4	293150144	Stavex Rivet	4
8	293150096	Hemlock Rivet, 6.5 mm	8
10	293150119	Hemlock Rivet, 6.5 mm	10
10	293150174	Hemlock Rivet, 6.4 mm	10
2	293150147	Hemlock Rivet	2
1	518330131	Radiator Ass'y 137	1
2	293730052	Black, Plug	2
2	506151252	Washer	2
2	250000942	Hex Screw M8 X 30	2
2	234081410	Flat Washer 8 mm	2
2	233281414	Hex. Flange Elastic Nut M8	2
1	518330163	Riveted Module E Includes 100 to 100j	1
1	518329999	RH Member Ass'y Includes 100a to 100b	1
1	505073317	Leg Cushion	1
1	518329960	LH Member Ass'y	1
1	518329844	Bottom Plate	1
14	293150203	Rivet Avibulb 3/16	14
1	293450268	Insert M5 X 0.8	1
2	207662046	Hex. Flange Screw M6 X 20	2
2	233261414	Hex. Flange Elastic Nut M6 x 1.0	2
3	293150147	Hemlock Rivet	3
2	293150174	Hemlock Rivet, 6.4 mm	2
2	293150120	Hemlock Rivet 6.5 mm	2
2	207662044	Hex. Flange Screw M6 X 20	2
4	207661644	Hex. Flange Screw M6 X 16	4
1	207562034	Hex. Flange Screw M6 X 20, Scotch Grip	1
1	518328693	Brace Ass'y Includes 300 to 300a	1
1	512060295	Rubber Mount	1
2	250001048	Hex. Flange Screw M8 X 30	2
2	207683544	Hex. Flange Screw M8 X 35	2
1	518329966	S Module	1
2	250000822	Hex. Flange Screw M6 X 16	2
1	207663544	Hex. Flange Screw M6 X 35	1
1	233261414	Hex. Flange Elastic Nut M6 x 1.0	1
6	293150147	Hemlock Rivet	6
	518329077	Black, LH Member
	518329078	Black - RH Member
4	250000887	Pan Head Torx Screw M8 X 12	4
2	250300629	Stud M5 X 20	2
2	518329974	Upper Colomn Support	2
1	233261416	Elastic Flange Nut M6 X 1.0	1
1	207662544	Hex. Flange Screw M6 X 25	1
1	518328746	Rear Bumper Includes 1300 to 1300a	1
2	520001612	Cap	2
3	293730047	Black, Dart 8 mm	3
2	293730060	Black, Dart 10 mm	2
1	518329982	Front Protector	1
3	293150108	Pop Rivet 3/16”	3
2	518329980	Rear Protector Track 15 x 137 x 1.6 Ice Cobra	2
3	293830005	Rubber Bumper Track 15 x 137 x 1.6 Ice Cobra	3
1	518329981	Front Support Protector Track 15 x 137 x 1.6 Ice Cobra	1
5	250000577	Torx Truss Screw K40 X 12 Track 15 x 137 x 1.6 Ice Cobra	5
2	518329979	Rear Protector Track 15 x 137 x 1.6 Ice Cobra	2
1	520001545	Support Track 15 x 137 x 1.6 Ice Cobra	1
2	250000577	Torx Truss Screw K40 X 12 Track 15 x 137 x 1.6 Ice Cobra	2
2	293150108	Pop Rivet 3/16” Track 15 x 137 x 1.6 Ice Cobra	2
2	518329979	Rear Protector Track 15 x 137 x 1.25 Ice Ripper	2
1	520001545	Support Track 15 x 137 x 1.25 Ice Ripper	1
2	250000577	Torx Truss Screw K40 X 12 Track 15 x 137 x 1.25 Ice Ripper	2
2	293150108	Pop Rivet 3/16” Track 15 x 137 x 1.25 Ice Ripper	2
1	518330358	Black Toe-hold	1
1	518329134	Toe Hold	1
1	250000793	Hex. Flange Screw M6 X 25	1
1	207562054	Hex. Flange Screw S.Grip M6 X 20	1
2	210262550	Hex. Flange Forming Screw M6 X 25	2
