Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4 | 879-14536-01-00 | . Gasket (879-14536-00) | 4 |
| 4 | 879-14536-00-00 | . Gasket | 4 |
| 889-14501-00-00 | Carburetor Assembly 1 | ||
| 879-14541-01-00 | . Diaphragm, Pump | ||
| 889-14502-00-00 | Carburetor Assembly 2 | ||
| 879-14542-00-00 | Body, Pump 1 | ||
| 879-14553-00-00 | Gasket | ||
| 2 | 806-14552-01-00 | . Valve, Check | 2 |
| 879-14543-00-00 | . Body, Pump 2 | ||
| 2 | 838-14546-00-00 | . Valve, Needle | 2 |
| 2 | 676-14186-00-00 | . .Pin, Float | 2 |
| 810-14556-00-00 | . Spring | ||
| 810-14547-00-00 | Arm, Float | ||
| 806-14548-00-00 | Pin, Float Arm | ||
| 2 | 98702-03008-00 | . Screw, Flat Head | 2 |
| 806-14559-00-00 | . Washer | ||
| 810-14197-02-00 | . Pipe, Airvent | ||
| 8A1-14592-00-00 | . Screw | ||
| 810-24462-01-00 | . Cap, Blind | ||
| 806-14567-01-00 | Screw | ||
| 810-14597-00-00 | . Washer | ||
| 2 | 810-14545-00-00 | . Diaphragm | 2 |
| 90501-06213-00 | . Spring, Compression | ||
| 810-14136-00-00 | Seat, Spring | ||
| 879-14544-00-00 | Body, Pump 3 | ||
| 2 | 95303-08700-00 | . .Nut | 2 |
| 884-14565-01-00 | . Screw, Stop | ||
| 866-14561-00-00 | . O-Ring | ||
| 824-14567-00-00 | Screw | ||
| 858-14567-00-00 | Screw | ||
| 866-14548-00-00 | . Pin, Float Arm | ||
| 866-14967-00-00 | Cover | ||
| 866-14551-00-00 | Body, Pump 4 | ||
| 890-14545-00-00 | Diaphragm | ||
| 90501-07341-00 | Spring, Compression | ||
| 810-14591-00-00 | Screw | ||
| 866-14540-00-00 | Cover, Fuel | ||
| 8 | 90159-05006-00 | Screw, With Washer | 8 |
| 866-14578-00-00 | Collar | ||
| 879-14528-00-00 | Arm | ||
| 866-14554-00-00 | Pin, Lever | ||
| 4 | 90201-08410-00 | . .Washer, Plate | 4 |
| 2 | 91490-12012-00 | . Pin. Cotter | 2 |
| 879-14577-00-00 | Rod | ||
| 890-14589-00-00 | . Spring | ||
| 866-14535-00-00 | Collar | ||
| 866-14579-00-00 | Spring | ||
| 888-14516-50-00 | Jet, Main #150 | ||
| 810-14558-00-00 | Washer | ||
| 845-14567-00-00 | Screw | ||
| 90501-10237-00 | Spring, Compression | ||
| 865-14522-00-00 | Screw, Adjust | ||
| 865-14515-60-00 | Jet #60 | ||
| 865-14515-58-00 | Jet #58 | ||
| 865-14537-00-00 | Gasket | ||
| 865-14527-00-00 | Plate | ||
| 90159-05005-00 | . Screw, With Washer | ||
| 879-14573-00-00 | . Lever | ||
| 806-14534-00-00 | Collar | ||
| 806-14578-00-00 | Collar | ||
| 806-14597-00-00 | Washer | ||
| 90159-05009-00 | Screw, With Washer | ||
| 865-14535-00-00 | Collar | ||
| 879-14585-00-00 | Rod, Choke | ||
| 90170-08139-00 | . Nut, Hexagon | ||
| 879-14588-00-00 | Connector | ||
| 806-14599-00-00 | Washer, Lock | ||
| 1 | 95311-05700-00 | . Nut | 1 |
| 844-14566-00-00 | Screw, Stop | ||
| 90201-04436-00 | Washer, Plate | ||
| 95301-04600-00 | . Nut | ||
| 806-14533-00-00 | Spring, Ajst Screw | ||
| 90157-04010-00 | . Screw, Pan Head | ||
| 889-14580-00-00 | Plate, Stay | ||
| 879-14581-00-00 | . Bracket | ||
| 90159-04008-00 | Screw, With Washer | ||
| 879-14571-00-00 | . Bracket, Throttle | ||
| 2 | 97313-08012-00 | . Bolt, Hexagon | 2 |
| 2 | 92990-08100-00 | . Washer, Spring | 2 |
| 857-14576-00-00 | . Adjuster, Cable | ||
| 865-14515-50-00 | Jet #50 (#50) ALTERNATE JET | ||
| 865-14515-62-00 | Jet #62 (#62) ALTERNATE JET | ||
| 888-14516-65-00 | Jet, Main #165 ALTERNATE JET | ||
| 93501-08028-00 | Ball 1/8 S4-024 | ||
| 865-14515-60-00 | Jet #60 ALTERNATE JET | ||
| 865-14515-52-00 | Jet #52 (#52) ALTERNATE JET | ||
| 888-14516-40-00 | Jet, Main #140 ALTERNATE JET | ||
| 865-14515-58-00 | Jet #58 ALTERNATE JET | ||
| 865-14515-55-00 | Jet #55 ALTERNATE JET | ||
| 888-14516-42-00 | Jet, Main #142 ALTERNATE JET | ||
| 888-14516-45-00 | Jet, Main #145 (#145) ALTERNATE JET | ||
| 888-14516-50-00 | Jet, Main #150 ALTERNATE JETSTD FOR GPX433G | ||
| 888-14516-48-00 | Jet, Main #148 (#148) ALTERNATE JET | ||
| 888-14516-52-00 | Jet, Main #152 (#152) ALTERNATE JET | ||
| 888-14516-55-00 | Jet, Main #155 (#155) ALTERNATE JET | ||
| 888-14516-58-00 | Jet, Main #158 ALTERNATE JET | ||
| 888-14516-60-00 | Jet, Main #160 (#160) ALTERNATE JET | ||
| 888-14516-62-00 | Jet, Main #162 ALTERNATE JET |
