Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11055-0372 | BRACKET | 1 |
| 1 | 11061-0270 | GASKET,FR COVER | 1 |
| 1 | 13116-0026 | ROD-PUSH | 1 |
| 1 | 13216-0025 | GEAR-COMP,8T | 1 |
| 1 | 13216-0026 | GEAR-COMP,35T | 1 |
| 1 | 13236-0171 | LEVER-COMP | 1 |
| 1 | 13271-0539 | PLATE,CAM | 1 |
| 1 | 13310-0018 | SHAFT-ASSY,ENG SIDE | 1 |
| 1 | 13310-0019 | SHAFT-ASSY,GEAR ASSY | 1 |
| 1 | 14057-0006 | CASE-COMP-GEAR | 1 |
| 1 | 14091-0677 | COVER,RH | 1 |
| 1 | 14091-0998 | COVER | 1 |
| 1 | 14092-0128 | COVER,FR | 1 |
| 3 | 41080-1482 | DISC,FRICTION | 3 |
| 2 | 41080-1483 | DISC,PRESSURE | 2 |
| 2 | 41080-1484 | DISC,SEPARATER | 2 |
| 1 | 43016-0053 | CYLINDER-MASTER | 1 |
| 1 | 43019-0002 | CUP-BRAKE | 1 |
| 1 | 43039-0006 | PISTON-BRAKE | 1 |
| 1 | 43056-0005 | BREATHER-BRAKE | 1 |
| 1 | 43057-1001 | CAP-BREATHER | 1 |
| 1 | 49006-0008 | BOOT | 1 |
| 1 | 49006-0010 | BOOT | 1 |
| 1 | 49006-0021 | BOOT | 1 |
| 1 | 49006-0072 | BOOT | 1 |
| 2 | 49006-0084 | BOOT,BJ | 2 |
| 2 | 49006-0085 | BOOT,DOJ | 2 |
| 1 | 59266-0018 | JOINT-BALL,LH | 1 |
| 1 | 59266-0019 | JOINT-BALL,RH | 1 |
| 2 | 92009-1166 | SCREW,TAPPING,6X16 | 2 |
| 1 | 92033-0055 | RING-SNAP | 1 |
| 2 | 92037-1104 | CLAMP,HOSE | 2 |
| 2 | 92043-1567 | PIN,8X14 | 2 |
| 2 | 92043-1617 | PIN,3X35 | 2 |
| 92045-0077 | BEARING-BALL,#6005 | ||
| 92045-0078 | BEARING-BALL,55X90X18 | ||
| 92045-0099 | BEARING-BALL,BX30-1C3 | ||
| 92045-0111 | BEARING-BALL,60/28 | ||
| 1 | 92045-1213 | BEARING-BALL,6210CM | 1 |
| 1 | 92046-0024 | BEARING-NEEDLE,AH502802 | 1 |
| 1 | 92049-0028 | SEAL-OIL,HTGY 24X45X9.5 | 1 |
| 2 | 92049-0089 | SEAL-OIL,28X60X7 | 2 |
| 1 | 92049-1537 | SEAL-OIL,TC17X28X6 | 1 |
| 1 | 92055-0121 | RING-O,190.2X4.2 | 1 |
| 1 | 92055-0122 | RING-O | 1 |
| 1 | 92055-0146 | RING-O | 1 |
| 1 | 92055-0147 | RING-O | 1 |
| 2 | 92055-1633 | RING-O,18X24X3 | 2 |
| 2 | 92055-1693 | RING-O,30X35X2.5 | 2 |
| 1 | 92066-0085 | PLUG,DRAIN,10X12 | 1 |
| 1 | 92066-1303 | PLUG | 1 |
| 2 | 92072-1237 | BAND,L=250 | 2 |
| 6 | 92140-1064 | BALL,D/O#12 | 6 |
| 1 | 92145-0583 | SPRING | 1 |
| 2 | 92145-1301 | SPRING,RR BRAKE | 2 |
| 1 | 92145-1304 | SPRING,PROPELLER SHAFT | 1 |
| 6 | 92151-1909 | BOLT,10X35 | 6 |
| 2 | 92153-0311 | BOLT,12X35 | 2 |
| 2 | 92153-1727 | BOLT,FLANGED,8X40 | 2 |
| 1 | 92153-1729 | BOLT,FLANGED-SMALL,6X16 | 1 |
| 1 | 92172-0371 | SCREW,SET,75X10 | 1 |
| 1 | 92180-0243 | SHIM,50.2X60X1.2 | 1 |
| 1 | 92180-0244 | SHIM,50.2X60X1.0 | 1 |
| 1 | 92180-0245 | SHIM,50.2X60X0.8 | 1 |
| 1 | 92180-0246 | SHIM,50.2X60X0.5 | 1 |
| 1 | 92180-0247 | SHIM,50.2X60X0.2 | 1 |
| 1 | 92180-0248 | SHIM,50.2X60X0.15 | 1 |
| 1 | 92180-1417 | SHIM,55X64X0.15 | 1 |
| 1 | 92180-1418 | SHIM,55X64X0.20 | 1 |
| 1 | 92180-1419 | SHIM,55X64X0.50 | 1 |
| 1 | 92180-1420 | SHIM,55X64X0.80 | 1 |
| 1 | 92180-1421 | SHIM,55X64X1.00 | 1 |
| 1 | 92180-1422 | SHIM,55X64X1.20 | 1 |
| 1 | 92180-1423 | SHIM,60X72X0.15 | 1 |
| 1 | 92180-1424 | SHIM,60X72X0.20 | 1 |
| 1 | 92180-1425 | SHIM,60X72X0.50 | 1 |
| 1 | 92180-1426 | SHIM,60X72X0.80 | 1 |
| 1 | 92180-1427 | SHIM,60X72X1.00 | 1 |
| 1 | 92180-1428 | SHIM,60X72X1.20 | 1 |
| 1 | 92192-0558 | TUBE,7X12X1113 | 1 |
| 8 | 130CD0860 | BOLT-FLANGED | 8 |
| 2 | 220AA0408 | SCREW-PAN-CROS,4X8 | 2 |
| 1 | 480J2500 | CIRCLIP-TYPE-C,25MM | 1 |
| 1 | 481J5200 | CIRCLIP-TYPE-C,52MM | 1 |
| 1 | 555A0428 | PIN-SPRING | 1 |
| 1 | 670B2010 | O RING,10MM | 1 |
| 1 | 92210-1294 | NUT,30MM | 1 |
