Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8ES-21940-00-00 | FRONT FRAME COMP. | |
| 2 | 8FA-W2197-11-00 | BULKHEAD | 1 |
| 3 | 90381-15001-00 | BUSH, SOLID | 2 |
| 4 | 90381-16001-00 | BUSH, SOLID | 2 |
| 5 | 8FA-W2198-11-00 | BULKHEAD 2 | 1 |
| 6 | 90381-15001-00 | BUSH, SOLID | 2 |
| 7 | 90381-16001-00 | BUSH, SOLID | 2 |
| 8 | 95827-08060-00 | BOLT, FLANGE | 3 |
| 9 | 95827-08065-00 | BOLT, FLANGE | 1 |
| 10 | 95607-08200-00 | NUT, SELF-LOCKING | 4 |
| 11 | 8FA-2128A-00-00 | BRACKET, REGULATOR | 1 |
| 12 | 8FG-21947-00-00 | BRACKET, STEERING 1 | 1 |
| 13 | 95607-10200-00 | NUT, U FLANGE | 4 |
| 14 | 8FA-12440-00-00 | HEAT EXCHANGER ASSY | 1 |
| 15 | 8FA-12551-00-00 | HOSE 7 | 1 |
| 16 | 90467-28046-00 | CLIP | 1 |
| 17 | 90450-35001-00 | HOSE CLAMP ASSY | 1 |
| 18 | 93306-20650-00 | BEARING | 1 |
| 19 | 99009-62500-00 | CIRCLIP | 1 |
| 20 | 95607-08200-00 | NUT, SELF-LOCKING | 1 |
| 21 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW | 63 |
| 22 | 8ES-2131D-00-00 | PLATE, COVER | 1 |
| 23 | 90267-48016-00 | RIVET, BLIND (4.8X16.4 YELLOW | 6 |
| 24 | 8FJ-21950-00-00 | REAR FRAME COMP. RS90RL (8FJ3) | 1 |
| 8GF-21950-00-00 | REAR FRAME COMP. RS90NRL (8GH1) | ||
| 25 | 8FA-W2199-10-00 | REINEFORCEMENT, FRAME REAR 1 | 1 |
| 26 | 8FG-21926-00-00 | REINFORCEMENT, FOOTREST 1 RS90RL (8FJ3) | 1 |
| 8FU-21926-00-00 | REINFORCEMENT, FOOTREST 1 RS90NRL (8GH1) | 1 | |
| 27 | 8FG-21936-00-00 | REINFORCEMENT, FOOTREST 2 RS90RL (8FJ3) | 1 |
| 8FU-21936-00-00 | REINFORCEMENT, FOOTREST 2 RS90NRL (8GH1) | 1 | |
| 28 | 8ES-21943-00-00 | BRACKET, MAIN TRACK 1 RS90NRL (8GH1) | 1 |
| 8FU-21943-00-00 | BRACKET, MAIN TRACK 1 RS90RL (8FJ3) | ||
| 29 | 8ES-21953-00-00 | BRACKET, MAIN TRACK 2 RS90NRL (8GH1) | 1 |
| 8FU-21953-00-00 | BRACKET, MAIN TRACK 2 RS90RL (8FJ3) | 1 | |
| 30 | 8ES-21944-00-00 | BRACKET, RR. TRACK SUSPENSI RS90NRL (8GH1) | |
| 8FP-21944-00-00 | BRACKET, RR. TRACK SUSPENSION RS90RL (8FJ3) | 1 | |
| 31 | 8FP-21954-00-00 | BRACKET, RR. TRACK SUSPENSION | 1 |
| 32 | 95817-10022-00 | BOLT, FLANGE RS90NRL (8GH1) | 4 |
| 95814-10020-00 | BOLT, FLANGE RS90RL (8FJ3) | 4 | |
| 33 | 90201-100S0-00 | WASHER, PLATE | 4 |
| 34 | 8FU-21988-01-00 | PATCH 8 | 2 |
| 35 | 8CR-2194N-00-00 | BRACKET, FUEL TANK 1 | 2 |
| 36 | 8FA-2194X-00-00 | BRACKET 1 | 1 |
| 37 | 8FA-2195X-00-00 | BRACKET 2 | 1 |
| 38 | 8ES-2194H-00-00 | PROTECTOR, MUFFLER | 1 |
| 39 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW UR QTY:124 | 1 |
| 40 | 8FA-21963-00-00 | PATCH 3 RS90NRL (8GH1) | 1 |
| 8FU-21963-00-00 | PATCH 3 RS90RL (8FJ3) | 1 | |
| 41 | 8FA-21964-00-00 | PATCH 4 RS90NRL (8GH1) | 1 |
| 8FU-21964-00-00 | PATCH 4 RS90RL (8FJ3) | 1 | |
| 42 | 8FU-1241A-00-00 | HEAT EXCHANGER ASSY 4 | 1 |
| 43 | 90210-06006-00 | WASHER, SEAL | 1 |
| 44 | 95817-06016-00 | BOLT, FLANGE | 1 |
| 45 | 90267-48095-00 | RIVET, BLIND (4.8X12.6 SILVER | 2 |
| 46 | 8FU-21919-00-00 | BRACKET, MAIN TRACK 3 | 2 |
| 47 | 92014-10020-00 | BOLT, BUTTON HEAD | 2 |
| 48 | 8FP-21928-00-00 | REINF., SUB FRAME 1 | 1 |
| 49 | 8FP-21938-00-00 | REINF., SUB FRAME 2 | 1 |
| 50 | 8FK-W2195-00-00 | FRAME CONNECTION KIT | |
| 51 | 8CR-21939-01-00 | BRACKET, CHAIN HOUSING | 2 |
| 52 | 8FU-2196M-00-00 | BRACKET, 5 | 1 |
| 53 | 8FU-2197M-00-00 | BRACKET, 6 | 1 |
| 54 | 8FU-2198G-00-00 | COVER 2 | 1 |
| 55 | 8FA-21999-00-00 | CLAMP, WIRE HARNESS | 1 |
| 56 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW | 64 |
| 57 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 4 |
| 58 | 8FU-21960-00-00 | FOOTREST COMP. 1 | 1 |
| 59 | 8FU-21970-00-00 | FOOTREST COMP. 2 | 1 |
| 60 | 8ES-2193E-00-00 | BRACKET, OIL TANK 1 | 1 |
| 61 | 95827-08014-00 | BOLT, FLANGE | 2 |
| 62 | 8EK-21920-01-00 | HOUSING, REINF SUB-ASSY (L.H) | 1 |
| 63 | 8FU-2198F-00-00 | COVER 1 | 1 |
| 64 | 8FU-2198J-00-00 | COVER 3 | 1 |
| 65 | 8FU-2195E-01-00 | PLATE, STEERING BRACKET 1 | 1 |
| 66 | 8FU-2195F-01-00 | PLATE, STEERING BRACKET 2 | 1 |
| 67 | 8ES-2196A-00-00 | FRAME UNDER 1 | 1 |
| 68 | 8FA-2196E-00-00 | FRAME, UNDER 2 | 1 |
| 69 | 8FA-21972-00-00 | BRACKET, GUARD FITTING | 1 |
| 70 | 8FA-2196F-00-00 | BRACKET 3 | 6 |
| 71 | 90267-48083-00 | RIVET, BLIND (4.8X15.2 SILVER) | 8 |
| 72 | 90267-48169-00 | RIVET, BLIND (4.8X14.1 BLACK) | 16 |
| 73 | 90267-48018-00 | RIVET, BLIND (4.8X18.6 BLACK) | 14 |
| 74 | 90267-47200-00 | RIVET, BLIND (4.7X19.5 BLACK) | 4 |
| 75 | 8FA-77512-00-00 | BUMPER, FRONT 2 | 1 |
| 76 | 95827-06012-00 | BOLT, FLANGE | 4 |
| 77 | 8FA-21949-00-00 | BRACKET, FRONT | 1 |
| 78 | 8FA-21959-00-00 | BRACKET, FRONT BUMPER | 1 |
| 79 | 8FA-77125-00-00 | STAY 1 | 2 |
| 80 | 95827-08016-00 | BOLT, FLANGE | 6 |
| 81 | 8FA-21978-01-00 | PROTECTOR, FRAME | 2 |
| 82 | 8FA-2197N-00-00 | BRACKET 7 RS90NRL (8GH1) | 4 |
| 8FU-2197N-00-00 | BRACKET 7 RS90RL (8FJ3) | 4 | |
| 83 | 95827-08020-00 | BOLT, FLANGE | 2 |
| 84 | 90267-48095-00 | RIVET, BLIND (4.8X12.6 SILVER) | 4 |
| 85 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 28 |
| 86 | 8FA-2197E-01-00 | PROTECTOR, FRAME FR | |
| 87 | 90109-065F3-00 | BOLT | 5 |
| 88 | 90183-06053-00 | NUT, SPRING | 5 |
| 89 | 8FA-21998-00-00 | SPACER | 4 |
| 90 | 8FG-23892-00-00 | SHIELD, HEAT | 1 |
| 91 | 90267-48059-00 | RIVET, BLIND (4.8X12.3) | 13 |
| 92 | 8FP-22865-00-00 | COVER, FRONT | 1 |
| 93 | 90150-06015-00 | SCREW, ROUND HEAD | 2 |
| 94 | 8ES-2179D-00-00 | PLETE, EPA OFFROAD 2 | 1 |
| 95 | 8FU-474AA-00-00 | GRAPHIC, 1 | 1 |
| 96 | 8FA-21973-00-00 | HOOK | 1 |
| 97 | 8CR-77319-00-00 | DAMPER 1 | 1 |
| 98 | 90267-47195-00 | RIVET, BLIND (4.7X16.4 YELLOW) | 3 |
