Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 510004775 | Front Seat Base | 1 |
| 510005064 | Front Seat Cover | ||
| 1 | 510004777 | Front Seat Foam | 1 |
| 2 | 708000125 | Rubber Stopper | 2 |
| 2 | 510004963 | SEAT CORNER, BLACK | 2 |
| XXX | Not Available As Spare Parts | ||
| 1 | 510005060 | REAR SEAT BASE ASS'Y Includes 8 to 16 | 1 |
| XXXX | Not Available As Spare Part - Cross Member | ||
| 1 | 510004423 | Foam Support | 1 |
| 6 | 293150104 | Pop Rivet 3/16" | 6 |
| 4 | 293150100 | Pop Rivet 3/16" | 4 |
| 2 | 510004535 | LINK PLATE | 2 |
| 510004536 | Spacer | ||
| 4 | 205982586 | SOCKET HEAD SCREW M8 X 25, SCOTCH GRIP | 4 |
| 1 | 510005065 | REAR SEAT COVER | 1 |
| 1 | 510004791 | Rear Seat Foam | 1 |
| 3 | 414644300 | Black, Dart | 3 |
| 1 | 510004782 | Backrest Foam | 1 |
| 1 | 510005066 | BACKREST COVER | 1 |
| 1 | 510004377 | Upper Backrest Axle | 1 |
| 2 | 510004379 | Washer | 2 |
| 2 | 510004378 | Rubber Shim | 2 |
| 1 | 510005067 | RH ARM, BLACK | 1 |
| 1 | 510005068 | LH ARM, BLAK | 1 |
| 2 | 250000283 | Torx Screw M8 X 25, Scotch Grip | 2 |
| 4 | 250000198 | TORX TRUSS SCREW M8 X 16 | 4 |
| 510004966 | SPACER | ||
| 1 | 510004964 | RH REAR CORNER SEAT | 1 |
| 1 | 510004965 | LH REAR CORNER SEAT | 1 |
| 1 | 515176766 | Seat Harness Includes 33 to 33j | 1 |
| 1 | 515175232 | Male Terminal | 1 |
| 1 | 515175231 | Female Terminal | 1 |
| 1 | 515175495 | Female Housing, 3 Circuits | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 1 | 219704407 | Tubing 10 MM 1000MM Long | 1 |
| 1 | 515175654 | Male Terminal Housing, 2 Circuits | 1 |
| 515176034 | PT Female Socket | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| XXXX | Not Available As Spare Part - Female Terminal Housing (4 Circuits) | ||
| 2 | 515175220 | Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership | 2 |
| 2 | 515175283 | Housing Support | 2 |
| 1 | 518325474 | RH Seat Anchor | 1 |
| 2 | 510005216 | SPACER | 2 |
| 1 | 518325473 | LH Seat Anchor | 1 |
| 2 | 510005095 | SEAT STUD | 2 |
| 2 | 207561044 | Flange Screw M6 X 10, Scotch Grip | 2 |
| 4 | 207562044 | Flange Screw M6 X 20, Scotch Grip | 4 |
| 510005092 | RH Handle Ass'y Includes 42 to 57 | ||
| 1 | 250000129 | Torx Screw M6 X 16 | 1 |
| 1 | 293100003 | Nut Welded, M6 | 1 |
| 1 | 510004449 | Handle Grip | 1 |
| 1 | 510005009 | RH Air Deflector | 1 |
| 1 | 515176768 | Heated Element | 1 |
| 1 | 219704426 | Was 515175506 Tubing | 1 |
| 2 | 250000113 | Screw M4 X 16, Type K-40 | 2 |
| 1 | 510005011 | HANDLE REINFORCEMENT | 1 |
| 1 | 510004405 | Moulding | 1 |
| 1 | 510005111 | LINK HANDLE | 1 |
| 250000197 | Torx Truss Screw M8 X 30 | ||
| 1 | 515175494 | Male Housing, 3 Circuits | 1 |
| 1 | 250000220 | SOCKET HEAD SCREW M8 X 45 | 1 |
| 510004565 | HANDLE CLAMP | ||
| 510005093 | LH Handle Ass'y Includes 58 to 80 | ||
| 1 | 510005010 | LH Air Deflector | 1 |
| 1 | 510005036 | Switch Housing | 1 |
| 3 | 250000146 | Truss Head Torx Screw K50 X 16 | 3 |
| 3 | 250000113 | Screw M4 X 16, Type K-40 | 3 |
| 1 | 510004413 | Rocker Switch | 1 |
| 1 | 510004414 | Switch Protector | 1 |
| 1 | 515176697 | Handle Harness | 1 |
| 1 | 516003937 | Connector Decal | 1 |
| 1 | 516003816 | Heated Handle Decal | 1 |
| 1 | 515176033 | Male Connector | 1 |
