Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 94510-19C00 | BRACE, COWLING | ||
| 1 | 01107-08205 | BOLT | 1 |
| 1 | 08321-21084 | LOCK WASHER | 1 |
| 2 | 01107-06125 | BOLT | 2 |
| 2 | 08321-21064 | LOCK WASHER | 2 |
| 94520-19C00 | PLATE, METER | ||
| 4 | 02142-06125 | SCREW | 4 |
| 94420-19C00 | COVER, METER (BLACK) Includes Item(s) 9 | ||
| 2 | 94635-19C10 | MOLDING | 2 |
| 4 | 03541-05085 | SCREW | 4 |
| 1 | 94527-19C00 | MOLDING, METER | 1 |
| 94426-19C00 | CUSHION, COVER | ||
| 94610-19C00 | WINDOW | ||
| 1 | 94631-19C00 | MOLDING | 1 |
| 94637-19C00 | CAP | ||
| 4 | 09139-05022 | SCREW | 4 |
| 4 | 09161-05010 | WASHER (5.2X11.0X1.0) | 4 |
| 94460-19C00 | PLATE, CENTER | ||
| 2 | 02142-06205 | SCREW | 2 |
| 2 | 09160-06039 | WASHER | 2 |
| 2 | 09180-06167 | SPACER | 2 |
| 2 | 09320-10015 | CUSHION (10X20X10) | 2 |
| 1 | 94638-19C00 | CUSHION, SCREEN | 1 |
| 94421-19C00-22R | PANEL, CENTER (WHITE) | ||
| 1 | 02142-05127 | SCREW | 1 |
| 94401-19C20-22R | COVER ASSY, COWLING,RH FOR 07P,21X | ||
| 94401-19C20-06X | COVER ASSY, COWLING,RH FOR 38K,32X; Includes Item(s) 27 - 34 | ||
| 68180-19C00-85K | TAPE SET, RH FOR 22R | ||
| 68180-19C00-2GC | TAPE SET, RH FOR 06X | ||
| 68181-19C00-9AP | EMBLEM FOR 22R | ||
| 68181-19C00-2GB | EMBLEM FOR 06X | ||
| 68131-27A00-9AP | EMBLEM (SACS) FOR 22R | ||
| 68131-27A00-2GT | EMBLEM (SACS) FOR 06X | ||
| 94631-19C10 | MOLDING | ||
| 1 | 94635-19C00 | MOLDING | 1 |
| 94438-19C00 | JOINT | ||
| 94435-19C00-22R | LID, OIL (WHITE) | ||
| 1 | 09139-06030 | SCREW | 1 |
| 94402-19C20-22R | COVER ASSY, COWLING,LH FOR 07P,21X | ||
| 94402-19C20-06X | COVER ASSY, COWLING,LH FOR 38K,32X; Includes Item(s) 36 - 41 | ||
| 68190-19C00-85K | TAPE SET, LH FOR 22R | ||
| 68190-19C00-2GC | TAPE SET, LH FOR 06X | ||
| 2 | 09139-06029 | SCREW, FRONT | 2 |
| 2 | 09160-06036 | WASHER | 2 |
| 2 | 09139-06030 | SCREW, UPPER | 2 |
| 2 | 09161-06021 | WASHER | 2 |
| 94560-19C00 | BRACKET, UPPER,RH | ||
| 94570-19C00 | BRACKET, UPPER,LH | ||
| 4 | 09125-06055 | SCREW | 4 |
| 94573-19C00 | NUT | ||
| 4 | 09139-06029 | SCREW | 4 |
| 4 | 09160-06036 | WASHER | 4 |
| 4 | 09180-06011 | SPACER | 4 |
| 4 | 09320-09016 | CUSHION | 4 |
| 94471-19C00-019 | COVER, UNDER,RH (BLACK) | ||
| 94481-19C00-019 | COVER, UNDER,LH (BLACK) | ||
| 2 | 09139-06042 | SCREW, FRONT | 2 |
| 94531-19C00 | BRACKET, UNDER,RH | ||
| 94532-19C00 | BRACKET, UNDER,LH | ||
| 94590-19C00 | NUT | ||
| 2 | 01107-06165 | BOLT | 2 |
| 2 | 09139-05032 | SCREW (5X18) | 2 |
| 2 | 09161-05017 | WASHER | 2 |
| 2 | 94484-32B00 | NUT | 2 |
| 2 | 09139-06029 | SCREW, REAR | 2 |
| 2 | 09180-06097 | SPACER | 2 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 02142-06205 | SCREW, LOWER | 2 |
| 2 | 09180-06011 | SPACER | 2 |
| 2 | 02142-05164 | SCREW, LOWER | 2 |
| 2 | 08322-21055 | WASHER | 2 |
| 94580-19C00 | BRACKET, LOWER | ||
| 3 | 02142-05164 | SCREW | 3 |
| 3 | 09161-05017 | WASHER | 3 |
| 94475-19C00-019 | COVER, UNDER,FRONT (BLACK) | ||
| 1 | 68612-48B00 | LABEL, SCREEN | 1 |
| 68612-48B10 | LABEL, SCREEN (FRENCH) | ||
| 2 | 02142-06127 | SCREW | 2 |
| SPECIAL NOTE | REFER TO FIG.40A(H- 6) FOR |
