Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8ET-21940-20-00 | Front Frame Comp | 1 |
| 1 | 8FA-W2197-13-00 | . .Bulkhead | 1 |
| 2 | 90381-15001-00 | . . ..Bush, Solid | 2 |
| 2 | 90381-16004-00 | . . ..Bush, Solid | 2 |
| 1 | 8FA-2191E-19-00 | . .Bulkhead 2 | 1 |
| 3 | 95827-08060-00 | . .Bolt, Flange | 3 |
| 1 | 95827-08065-00 | . .Bolt, Flange | 1 |
| 4 | 95607-08200-00 | . Nut, Self-Locking | 4 |
| 1 | 8FA-2128A-01-00 | . .Bracket, Regulator | 1 |
| 1 | 8FG-21947-00-00 | . .Bracket, Steering 1 | 1 |
| 4 | 95607-10200-00 | . Nut, U Flange | 4 |
| 1 | 8FR-2193A-01-00 | . .Protector | 1 |
| 1 | 8HF-12440-00-00 | . .Heat Exchanger Assy | 1 |
| 1 | 8FA-12551-00-00 | . .Hose 7 | 1 |
| 1 | 90467-28046-00 | . .Clip | 1 |
| 1 | 90450-35001-00 | . Hose Clamp Assy | 1 |
| 1 | 95607-08200-00 | . Nut, Self-Locking | 1 |
| 42 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 42 |
| 1 | 8ES-2131D-00-00 | . .Plate, Cover | 1 |
| 11 | 90267-48176-00 | . .Rivet, Blind (4.8X17 Yellow) | 11 |
| 16 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 16 |
| 1 | 8ET-21950-21-00 | Rear Frame Comp | 1 |
| 1 | 8FA-W2199-10-00 | . .Reineforcement, Frame Rear 1 | 1 |
| 2 | 8ET-21943-01-00 | . .Bracket, Main Track 1 | 2 |
| 1 | 8ET-21944-00-00 | . .Bracket,Rr.Track Suspention | 1 |
| 1 | 8ET-21954-00-00 | . .Bracket,Rr.Track Suspention | 1 |
| 2 | 8CR-2194N-00-00 | . .Bracket, Fuel Tank 1 | 2 |
| 1 | 8ET-2194X-00-00 | . .Bracket 1 | 1 |
| 1 | 8ET-2195X-00-00 | . .Bracket 2 | 1 |
| 1 | 8ES-2194H-00-00 | . .Protector, Muffler | 1 |
| 96 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 96 |
| 1 | 8ET-21916-01-00 | . .Panel, Sub Frame 5 | 1 |
| 1 | 8ET-21963-00-00 | . .Patch 3 | 1 |
| 1 | 8ET-21964-00-00 | . .Patch 4 | 1 |
| 1 | 8ET-1241A-02-00 | . .Heat Exchanger Assy 4 | 1 |
| 1 | 90210-06006-00 | . . Washer, Seal | 1 |
| 1 | 95812-06016-00 | . . Bolt, Flange | 1 |
| 16 | 90267-47197-00 | . Rivet, Blind (4.7X19.5 Silver | 16 |
| 2 | 90267-48095-00 | . Rivet, Blind (4.8X12.6 Silver | 2 |
| 6 | 95814-10020-00 | . .Bolt, Flange | 6 |
| 6 | 90201-10064-00 | . .Washer, Plate | 6 |
| 2 | 8ET-21953-00-00 | . .Bracket, Main Track 2 | 2 |
| 1 | 8ET-21926-00-00 | . .Reinforcement, Footrest 1 | 1 |
| 1 | 8ET-21936-00-00 | . .Reinforcement, Footrest 2 | 1 |
| 1 | 8ET-21946-00-00 | . .Bracket, Seat Fitting | 1 |
| 1 | 8ET-21956-00-00 | . .Bracket, Seat Fitting 1 | 1 |
| 2 | 8ET-21988-00-00 | . .Patch 8 | 2 |
| 1 | 8ET-21989-00-00 | . .Patch 9 | 1 |
| 1 | 8ET-21997-00-00 | . .Patch 10 | 1 |
| 2 | 8ET-2196G-00-00 | . .Bracket 4 | 2 |
| 2 | 90267-48016-00 | . Rivet, Blind (4.8X16.4 Yellow | 2 |
| 4 | 90267-48176-00 | . .Rivet, Blind (4.8X17 Yellow) | 4 |
| 14 | 90267-48023-00 | . Rivet, Blind (4.8X12.1 Yellow | 14 |
| 28 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 28 |
| 1 | 8FK-W2195-21-00 | Frame Connection Kit | 1 |
| 2 | 8CR-21939-01-00 | . .Bracket, Chain Housing | 2 |
| 1 | 8FU-2196M-00-00 | . .Bracket, 5 | 1 |
| 1 | 8FU-2197M-00-00 | . .Bracket, 6 | 1 |
| 1 | 8FP-2198G-01-00 | . .Cover 2 | 1 |
| 1 | 8FA-21999-00-00 | . .Clamp, Wire Harness | 1 |
| 44 | 90267-47195-00 | . Rivet, Blind (4.7X16.4 Yellow | 44 |
| 6 | 90267-47197-00 | . Rivet, Blind (4.7X19.5 Silver | 6 |
| 4 | 90267-48018-00 | . Rivet, Blind (4.8X18.6 Black) | 4 |
| 10 | 90267-48177-00 | . .Rivet, Blind (4.8X14 Yellow) | 10 |
| 4 | 90267-47186-00 | . .Rivet, Blind (4.7X16.4 Black | 4 |
| 1 | 8FU-21960-01-00 | Footrest Comp. 1 | 1 |
| 1 | 8FU-21970-01-00 | Footrest Comp. 2 | 1 |
| 1 | 8EK-21920-01-00 | Housing, Reinf Sub-Assy (L.H) | 1 |
| 1 | 8ES-2196A-01-00 | Frame Under 1 | 1 |
| 1 | 8FA-2196E-01-00 | Frame, Under 2 | 1 |
| 1 | 8FA-21972-01-00 | Bracket, Guard Fitting | 1 |
| 6 | 8FA-2196F-00-00 | Bracket 3 | 6 |
| 8 | 90267-48083-00 | Rivet, Blind (4.8X15.2 Silver) | 8 |
| 12 | 90267-48169-00 | .Rivet, Blind (4.8X14.1 Black) | 12 |
| 14 | 90267-48018-00 | Rivet, Blind (4.8X18.6 Black) | 14 |
| 4 | 90267-47200-00 | Rivet, Blind (4.7X19.5 Black) | 4 |
| 2 | 95822-08020-00 | Bolt, Flange | 2 |
| 4 | 90267-48095-00 | Rivet, Blind (4.8X12.6 Silver) | 4 |
| 2 | 90267-48023-00 | Rivet, Blind (4.8X12.1 Yellow) | 2 |
| 4 | 90267-47195-00 | Rivet, Blind (4.7X16.4 Yellow) | 4 |
| 1 | 8FR-2197E-00-00 | Protector, Frame Fr | 1 |
| 2 | 92012-06012-00 | Bolt, Button Head | 2 |
| 4 | 8FA-21998-00-00 | Spacer | 4 |
| 1 | 8FG-23892-00-00 | Shield, Heat | 1 |
| 15 | 90267-48059-00 | Rivet, Blind (4.8X12.3) | 15 |
| 1 | 8ET-23892-00-00 | Shield, Heat | 1 |
| 2 | 90267-47004-00 | Rivet, Blind (4.7X13.1 Yellow) | 2 |
| 1 | 8DM-27431-02-00 | Footrest, Rear 1 | 1 |
| 8DM-27441-02-00 | Footrest, Rear 2 | ||
| 8 | 97702-50020-00 | Screw, Tapping | 8 |
