Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06910-HP0-A00 | BEARING SET, NEEDLE | 1 |
| 3 | 12342-MEG-300 | RUBBER, OVER HEAD COVER | 3 |
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 1 | 12361-300-000 | CAP, VALVE ADJ. | 1 |
| 1 | 12361-371-980 | CAP, VALVE ADJ. | 1 |
| 1 | 40200-HP5-600 | SHAFT, RR. PROPELLER | 1 |
| 1 | 40215-HN0-671 | SPRING, PROPELLER SHAFT | 1 |
| 1 | 40300-HP5-600 | JOINT ASSY., YOKE | 1 |
| 1 | 40321-HP5-600 | BOOT, YOKE JOINT | 1 |
| 1 | 40322-HN8-000 | BAND A, YOKE JOINT BOOT | 1 |
| 1 | 40323-HN8-000 | BAND B, YOKE JOINT BOOT | 1 |
| 1 | 41300-HP5-600 | GEAR ASSY., RR. FINAL | 1 |
| 1 | 41311-HP5-600 | CASE SUB-ASSY., FINAL GEAR | 1 |
| 1 | 41320-HP5-600 | COVER SUB-ASSY., FINAL GEAR | 1 |
| 1 | 41405-HA7-670 | RING, STOPPER | 1 |
| 1 | 41421-HP5-600 | GEAR, RR. PINION (20T) | 1 |
| 1 | 41431-HP5-600 | GEAR, RR. RING (41T) | 1 |
| 1 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 |
| 1 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 |
| 1 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 |
| 1 | 41540-HA0-000 | SPACER A, RING GEAR (1.82) | 1 |
| 1 | 41541-HA0-000 | SPACER B, RING GEAR (1.88) | 1 |
| 1 | 41542-HA0-000 | SPACER C, RING GEAR (1.94) | 1 |
| 1 | 41543-HA0-000 | SPACER D, RING GEAR (2.00) | 1 |
| 1 | 41544-HA0-000 | SPACER E, RING GEAR (2.06) | 1 |
| 1 | 41545-HA0-000 | SPACER F, RING GEAR (2.12) | 1 |
| 1 | 41546-HA0-000 | SPACER G, RING GEAR (2.18) | 1 |
| 1 | 41547-HA0-000 | SPACER H, RING GEAR (2.24) | 1 |
| 1 | 41548-HA0-000 | SPACER I, RING GEAR (2.30) | 1 |
| 2 | 41660-HP5-600 | SHIM A, RING GEAR (1.26) | 2 |
| 2 | 41661-HP5-600 | SHIM B, RING GEAR (1.32) | 2 |
| 2 | 41662-HP5-600 | SHIM C, RING GEAR (1.38) | 2 |
| 2 | 41663-HP5-600 | SHIM D, RING GEAR (1.44) | 2 |
| 2 | 41664-HP5-600 | SHIM E, RING GEAR (1.50) | 2 |
| 2 | 41665-HP5-600 | SHIM F, RING GEAR (1.56) | 2 |
| 2 | 41666-HP5-600 | SHIM G, RING GEAR (1.62) | 2 |
| 2 | 41667-HP5-600 | SHIM H, RING GEAR (1.68) | 2 |
| 2 | 41668-HP5-600 | SHIM I, RING GEAR (1.74) | 2 |
| 2 | 41669-HP5-600 | SHIM J, RING GEAR (1.80) | 2 |
| 2 | 41670-HP5-600 | SHIM K, RING GEAR (1.86) | 2 |
| 1 | 42310-HP5-600 | AXLE, RR. | 1 |
| 1 | 42317-HP5-600 | COLLAR C, RR. AXLE | 1 |
| 1 | 50355-HP5-600 | GUARD, FINAL | 1 |
| 2 | 90109-371-000 | BOLT, SEALING (8MM) | 2 |
| 3 | 90127-SM4-951 | BOLT, SENSOR LOCK (8X14) | 3 |
| 3 | 95701-08014-08 | BOLT, FLANGE (8X14) | 3 |
| 6 | 90133-HP5-600 | BOLT, FLANGE (8X27) | 6 |
| 2 | 90134-HP5-600 | BOLT, FLANGE (10X35) | 2 |
| 8 | 90135-HA7-770 | BOLT, STUD (10X22) | 8 |
| 1 | 90242-MB0-000 | NUT, LOCK (64MM) | 1 |
| 8 | 90305-HC0-770 | NUT, SELF-LOCK (10MM) | 8 |
| 2 | 90307-HM5-930 | NUT, RR. AXLE | 2 |
| 2 | 90308-HM5-930 | NUT A, RR. AXLE | 2 |
| 2 | 90471-580-000 | GASKET (8MM) | 2 |
| 2 | 90481-HC4-000 | WASHER, TAPER | 2 |
| 1 | 90501-HB3-000 | WASHER (32X86X1.5) | 1 |
| 1 | 90501-HP5-600 | WASHER (32X67X1.5) | 1 |
| 1 | 91005-PL9-008 | BEARING, BALL (6009) (NTN) | 1 |
| 1 | 91051-HP5-601 | BEARING SET, RADIAL BALL (45X58X14) | 1 |
| 1 | 91061-HP0-A01 | BEARING, NEEDLE (15X25X17) | 1 |
| 1 | 91251-HP5-601 | OIL SEAL (39X70X11) | 1 |
| 1 | 91255-HP5-601 | OIL SEAL (44X63X8) | 1 |
| 1 | 91271-HC4-004 | OIL SEAL (42X51X7) | 1 |
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 2 | 91305-KE1-000 | O-RING (19.4X2.3) | 2 |
| 1 | 91320-HM7-702 | O-RING (75X3.2) (NOK) | 1 |
| 1 | 91354-HC4-901 | O-RING (31.6X2.2) | 1 |
| 1 | 95002-35000 | CLIP, TUBE (C6.5) | 1 |
| 1 | 95005-35001-30M | BULK HOSE, VACUUM (3.5X1000) (3.5X980) | 1 |
| 1 | 96100-60073-00 | BEARING, RADIAL BALL (6007) | 1 |
