Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5430937 | HOOD,WHITE,'88(400) (400) | ||
| 5430922 | HOUSING,INST.BOTTOM | ||
| 5430923 | Discontinued | ||
| 5430924 | BEZEL, INST. | ||
| 4040011 | INDICATOR-TEMP-WARN. | ||
| 4040012 | INDICATOR'LOW-OIL'WARN. (Classic) | ||
| 4040013 | INDICATOR HI-BEAM WARN. (Classic) | ||
| 4040014 | Discontinued (Classic) | ||
| 3 | 5430967 | PLUG,INDIC.HOLE (400 & 650) | 3 |
| 7512008 | SCREW,SCKT.HD.CAP | ||
| 4 | 7512283 | SCREW, SEMS | 4 |
| 7670056 | NUT, SPEED | ||
| 4 | 7670057 | SPEED NUT | 4 |
| 5430928 | COVER,AIR INTAKE (650) | ||
| 5430965 | PANEL,AIR,INTAKE (Classic & 400) | ||
| 7511840 | SCREW | ||
| 7512009 | SCREW | ||
| 2 | 5430733 | HOOD LATCH CUP | 2 |
| 4 | 7621334 | RIVET | 4 |
| 2431006 | SUBSTITUTED BY 9999999 (Incl. 20-22) | ||
| 1 | 2870448 | HEADLIGHT BULB | 1 |
| 4030028 | BULB, H/L | ||
| 4 | 4032003 | SCR-M5X.8X50MM | 4 |
| 4032002 | Discontinued | ||
| 2635005 | HINGE ASM,HD. | ||
| 2 | 7558302 | WASHER, WROUGHT | 2 |
| 2 | 7512263 | BOLT-CARRIAGE | 2 |
| 2 | 7542122 | NYLOK NUT | 2 |
| 5211117 | SCREEN, HOOD | ||
| 7511861 | SCREW | ||
| 7555756 | RIVET BURR(50) | ||
| 1 | 3280092 | SPEEDOMETER (Incl. 32-33) | 1 |
| 3280093 | TACHOMETER (Incl. 32-33) (Classic & 400) | ||
| 3280096 | TACHOMETER,3 CYL. (Incl. 32-33) (650) | ||
| 3280098 | BRACKET | ||
| 3280063 | NUT | ||
| 1 | 5430964 | WINDSHIELD, SMOKE (400 & 650) | 1 |
| 5430996 | WINDSHIELD,GOLD STRIPE (Classic) | ||
| 7073024 | Discontinued | ||
| 7072489 | DECAL,OP.CAUT,(ENG.) (400) | ||
| 7072492 | DECAL,OPER.CAUT.ENG. (650) | ||
| 7072495 | DECAL,CAUTION,(ENG.) (Classic) | ||
| 7072490 | DECAL,OP.CAUT,(FR.) (400) | ||
| 7072493 | DECAL,OPER.CAUT.(FR.) (650) | ||
| 7072496 | DECAL,CAUTION,(FR.) (Classic) | ||
| 7072488 | DECAL,DASH WARNING (400) | ||
| 7072491 | DECAL,DASH WARNING (650) | ||
| 7072494 | DECAL,DASH WARNING (Classic) | ||
| 7072460 | DECAL,HOOD,LH,LOWER (400) | ||
| 7072461 | DECAL,HOOD,RH LOWER (400) | ||
| 7072466 | DECAL,LH,INDY650 (650) | ||
| 7072467 | DECAL,RH,INDY650 (650) | ||
| 7072458 | DECAL,LH HD,CLASSIC (Classic) | ||
| 7072459 | DECAL,RH HD,CLASSIC (Classic) | ||
| 7072462 | DECAL,LH,HD.SIDE (650) | ||
| 7072463 | DECAL,RH,HD.SIDE (650) | ||
| 7072482 | DECAL,HOOD,LH,UPPER (400) | ||
| 7072483 | DECAL,HOOD,RH UPPER (400) | ||
| 5810405 | TAPE,FOIL,FOAM | ||
| 7072456 | DECAL,LH HD.TOP,CLASSIC (Classic) | ||
| 7072457 | DECAL,RH HD.TOP,CLASSIC (Classic) | ||
| 7072484 | STRIPE,TOP HD.,LH (400) | ||
| 7072485 | STRIPE,TOP HD.,RH (400) | ||
| 5430980 | EMBLEM'CLASSIC'INDY (Classic) | ||
| 5430982 | LOGO,CLASSIC INDY (Classic) | ||
| 7072464 | DECAL,POLARIS,BLACK (650) | ||
| 1 | 5222105 | PLATE,RE-INF.,(HD.) | 1 |
| 5810374 | FOAM, HOOD, LH | ||
| 5810375 | FOAM, HOOD, RH | ||
| 5810376 | FOAM, HOOD, CTR | ||
| 5810389 | FOAM, HOOD | ||
| 5810395 | TAPE,FOIL | ||
| 7511989 | BLT-10-24X3/4,MACHSCR,PHL,PAN | ||
| 1 | 7080360 | CABLE,HD.RETAINER (Classic & 400) | 1 |
| 1 | 7080368 | HOOD RETAINER CABLE (650) | 1 |
| 2460260 | HARNESS,H/L.&INST. (Classic) | ||
| 2460261 | HARNESS,H/L.&INST. (400 & 650) | ||
| 10 | 5410387 | WINDSHIELD RETAINER | 10 |
| ------- | Staple, 5/32 | ||
| 2200260 | KIT,DECAL,'88 400 (Incl. 35-40, 42) (400) | ||
| 2200261 | KIT,DECAL,'88 650 (Incl. 35-40, 45) (650) | ||
| 2200281 | KIT,DECAL,'88CLASSIC 31 | ||
| 5810407 | TAPE,FOIL,FOAM | ||
| 5810393 | TAPE,FOIL,LH | ||
| 5810394 | TAPE,FOIL,RH | ||
| 5810397 | TAPE,FOIL | ||
| 5810404 | TAPE,FOIL,LOUVER,PIPE SIDE | ||
| 5810406 | TAPE,FOIL,FOAM | ||
| 2 | 7670041 | PLASTI-LOCK RIVET | 2 |
| 7072523 | DECAL,POD,HD.-H/L. (Classic & 400) | ||
| 5810414 | PAD, W/S, LH | ||
| 5810415 | PAD, W/S | ||
| 4020035 | CLIP,WIRING | ||
| 5430929 | HOOD,BLACK,'88(650) (650) | ||
| 5430938 | HOOD, CLASSIC (Classic) |
