Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2681329 | CUSHION,SEAT,'88(650) (Incl. 2-7) (650) | ||
| 2681324 | COVER,SEAT,'88(400) (400) | ||
| 2681327 | COVER,SEAT,'88CLASSIC (Classic) | ||
| 2681330 | COVER,SEAT (650) | ||
| 5430425 | HOUSING,TAILLIGHT | ||
| 2 | 4030015 | BULB TAILLIGHT/TACH/SPEEDO (10) | 2 |
| 4030019 | BULB, BRAKELIGHT | ||
| 5430423 | Discontinued | ||
| 7511840 | SCREW | ||
| 5 | 7542122 | NYLOK NUT | 5 |
| 2 | 7558221 | WASHER(10) | 2 |
| 5430575 | GROMMET-GAS TANK | ||
| 2681325 | COVER,TANK,'88(400) (400) | ||
| 2681328 | COVER,TANK,'88CLASSIC (Classic) | ||
| 2681331 | COVER,TANK,'88(650) (650) | ||
| 2681290 | BUCKLE&STRAP | ||
| 1 | 5810142 | GAS CAP GASKET | 1 |
| 1 | 2511149 | GAS CAP WITH GAUGE | 1 |
| 1 | 7042020 | SPRING, TANK | 1 |
| 5221722 | STRAP,GASTANK,BLK. | ||
| 5420126 | Discontinued | ||
| 2511150 | TANK,GAS | ||
| 1 | 7052037 | FUEL PICKUP WITH FILTER, 105 MI | 1 |
| 1 | 7052023 | FITTING, OUTLET | 1 |
| 2200190 | N/A,USE COMPONENTS | ||
| 5430579 | VENT-TANK | ||
| 2 | 5810063 | PAD-GAS TANK | 2 |
| 34 | 7621457 | RIVET | 34 |
| 7080288 | PLUG | ||
| 5 | 7621402 | POP RIVET | 5 |
| 2200250 | FOOTREST ASM,LH (400 & 650) | ||
| 2200254 | FOOTREST ASM,RH (400 & 650) | ||
| 2200269 | FOOTREST ASM, LH (Classic) | ||
| 2200270 | FOOTREST ASM, RH (Classic) | ||
| 1 | 7621452 | RIVET | 1 |
| 14 | 7621330 | POP RIVET | 14 |
| 4020035 | CLIP,WIRING | ||
| 5210728 | HINGE | ||
| 4 | 7558212 | WASHER,13/64X1/2X18GA,FL-Y (10) | 4 |
| 52 | 7621429 | RIVET | 52 |
| 2 | 5220817 | BELT RETAINER CLIP | 2 |
| 5230118 | SUBSTITUTED BY 5240965 (400 & 650) | ||
| 5230119 | GUARD,CLUTCH(400 CL.) (Classic) | ||
| 1 | 7080216 | CLUTCH GUARD PIN (400 & 650) | 1 |
| 1 | 7080361 | CLUTCH GUARD PIN (Classic) | 1 |
| 1011664 | SUBSTITUTED BY 1011804 (400 & 650) | ||
| 1011676 | TUNNEL ASM.(400SKS) (400 SKS Only w/1011694) | ||
| 1011691 | TUNNEL, GOLD (Classic) | ||
| 1011695 | TUNNEL ASM.(650SKS) (650 SKS Only w/1011694) | ||
| 10 | 7661620 | RIVET (650) | 10 |
| 5 | 7621323 | POP RIVET(50) | 5 |
| 3 | 7670021 | NUT, SPEED | 3 |
| 7080227 | SNAP-MALE | ||
| 7072153 | DECAL, WARNING | ||
| 5224334 | BUMPER,REAR,BLK. | ||
| 5224349 | BUMPER, (SKS) (400 SKS & 650 SKS Only) | ||
| 7072132 | DECAL, TRACK | ||
| 5220478 | PANEL,TUNNEL,BACK (400 & 650) | ||
| 5220927 | PANEL,BACK,GOLD (Classic) | ||
| 1011694 | PANEL,CLOSE-OFF,REAR (400 SKS & 650 SKS Only) | ||
| 1 | 5410392 | SNOW FLAP (Classic) | 1 |
| 1 | 5410394 | SNOW FLAP (400 & 650) | 1 |
| 5 | 7621418 | RIVET(50) | 5 |
| 5220945 | PLATE, WEAR (Classic) | ||
| 5222061 | WEARPLATE,TUNNEL (400 & 650) | ||
| 7661818 | RIVET,SEMI-TUBE,(10) * (400 & 650) | ||
| 7661821 | RIVET,(50) (Classic) | ||
| 7072414 | DECAL (400 SKS & 650 SKS Only) | ||
| 2 | 2670070 | REFLECTOR, RED | 2 |
| 2 | 7512103 | BOLT | 2 |
| 5510130 | STRIP-WEAR (650) | ||
| 6 | 7621222 | RIVET(10) | 6 |
| 5220634 | PLATE,TUNNEL,LH | ||
| 5220635 | PLATE,TUNNEL,RH | ||
| 5810201 | FOAM, FILLER | ||
| 7072078 | DECAL(47.5'')TUNNEL | ||
| 3 | 7512193 | CARRIAGE BOLT | 3 |
| 5220406 | BRACKET, HINGE (400 & 650) | ||
| 5220932 | BRACKET, HINGE (Classic) | ||
| 1011601 | SUPPORT, MUFFLER | ||
| 5221932 | BRACKET, GASTANK | ||
| 1011613 | BULKHEAD, (400) (400) | ||
| 1011614 | BULKHEAD,(600/650) (650) | ||
| 1011690 | BULKHEAD (Classic) | ||
| 4 | 7558301 | FLAT WASHER | 4 |
| 5430930 | Discontinued | ||
| 4 | 7511848 | SCREW | 4 |
| 4 | 7512240 | BOLT | 4 |
| 5211109 | SPACER,R.BUMPER | ||
| 4 | 7542451 | NYLOK NUT (400 SKS/650 SKS Only) | 4 |
| 7515482 | Discontinued (400 SKS/650 SKS Only) | ||
| 1011666 | BRKT,R.SUSP,LH MTG. | ||
| 1011667 | BRKT,R.SUSP,RH MTG. | ||
| 5220542 | BRKT. | ||
| 5220973 | BRKT, TOOL BOX | ||
| 5332405 | TUBE,DRAIN BATTERY (Classic) | ||
| 7661823 | RIVET (Classic) | ||
| 7661821 | RIVET,(50) (Susp. Pads) (Classic) | ||
| 7670031 | PALNUT(10) (Classic) | ||
| 1 | 8450003 | FUEL LINE, 1/4 ID | 1 |
| 2681323 | CUSHION,SEAT,'88(400) (Incl. 2-7) (400) | ||
| 2681326 | CUSHION,SEAT,'88CLASSIC (Incl. 2-7) (Classic) |
