Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06450-GAG-003 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 1 | 06450-178-932 | SHOE SET, BRAKE (JB) Use from Frame SN 6112061 | 1 |
| 1 | 06450-096-405 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 1 | 451A2-096-305 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 1 | 405W3-165-505 | CHAIN, DRIVE | 1 |
| 1 | 40530-120-003 | CHAIN, DRIVE (76L) (DAIDO) | 1 |
| 1 | 40530-120-005 | CHAIN, DRIVE (76L) (TAKASAGO) | 1 |
| 1 | 40530-120-015 | CHAIN, DRIVE (RK420M-76RJ) (TAKASAGO) | 1 |
| 1 | 40531-035-005 | MASTER LINK (TAKASAGO) | 1 |
| 1 | 40531-098-003 | MASTER LINK (DAIDO) | 1 |
| 1 | 40531-098-005 | MASTER LINK (TAKASAGO) | 1 |
| 1 | 40531-150-005 | MASTER LINK (TAKASAGO) | 1 |
| 2 | 40543-063-000 | ADJUSTER, R. DRIVE CHAIN | 2 |
| 2 | 95014-10010 | ADJUSTER S, R. CHAIN | 2 |
| 41201-120-010 | SPROCKET, FINAL DRIVEN (37T) | ||
| 41201-120-505 | SPROCKET, FINAL DRIVEN (37T) | ||
| 42301-041-030 | AXLE, RR. WHEEL | ||
| 42301-121-760 | AXLE, RR. WHEEL | ||
| 1 | 42312-120-000 | COLLAR, L. RR. WHEEL SIDE | 1 |
| 42601-120-000AU | HUB, RR. WHEEL *NH35* (CLOUD SILVER) | ||
| 42620-045-020 | COLLAR, RR. AXLE DISTANCE | ||
| 42620-165-405 | COLLAR, RR. AXLE DISTANCE | ||
| 42701-045-670AU | RIM, R. WHEEL *NH35* (CLOUD SILVER) | ||
| 42701-045-670ZC | RIM, R. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42701-045-671ZA | RIM, R. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42702-045-670AU | RIM, L. WHEEL *NH35* (CLOUD SILVER) | ||
| 42702-045-670ZC | RIM, L. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42702-045-671ZA | RIM, L. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 43100-130-650AU | PANEL, RR. BRAKE *NH35* (CLOUD SILVER) | ||
| 45131-400-000 | CAM, FR. BRAKE | ||
| 45131-400-010 | CAM, FR. BRAKE | ||
| 45131-400-020 | CAM, FR. BRAKE | ||
| 43145-MM9-000 | INDICATOR, RR. BRAKE | ||
| 43145-130-650 | INDICATOR, RR. BRAKE | ||
| 43410-130-650 | ARM, RR. BRAKE | ||
| 1 | 44711-120-671 | TIRE (3.50-8) (2PR) (BS) Use up to Frame SN 6210000 | 1 |
| 42711-130-672 | TIRE, WHEEL (3.50-8) (NITTO) | ||
| 08400-12010 | TUBE (300/350-8) | ||
| 42712-GC3-003 | TUBE, TIRE (3.00-8) | ||
| 42712-GC3-004 | TUBE, TIRE (3.00-8) (IRC) | ||
| 44712-120-003 | TUBE, TIRE (3.50-8) (BS) | ||
| 44712-120-006 | TUBE, TIRE (3.50-8) (NITTO) | ||
| 2 | 06450-178-932 | SHOE SET, BRAKE (JB) | 2 |
| 2 | 45120-GAG-003 | SHOE, BRAKE | 2 |
| 2 | 45120-096-651 | SHOE, BRAKE (JB) (SEE KIT P/N--END OF BLOCK) | 2 |
| 45120-096-652 | SHOE, BRAKE (ASK) (SEE KIT P/N--END OF BLOCK) (NA USE ALT:451A2-096-305) | ||
| 2 | 45133-028-000 | SPRING, BRAKE SHOE | 2 |
| 3 | 90125-120-010 | BOLT, STUD (8X45) | 3 |
| 3 | 90125-120-020 | BOLT, STUD (8X45) | 3 |
| 4 | 90194-567-010 | BOLT, WHEEL RIM | 4 |
| 3 | 90309-357-000 | NUT, HEX. (8MM) | 3 |
| 1 | 90353-045-000 | NUT, SELF-LOCK (12MM) | 1 |
| 2 | 90525-001-000 | WASHER, RR. BRAKE ARM | 2 |
| 1 | 91251-045-005 | OIL SEAL (18X32X8) | 1 |
| 1 | 92000-06035 | BOLT, HEX. (6X35) | 1 |
| 1 | 92000-06035-0A | BOLT, HEX. (6X35) | 1 |
| 1 | 92101-06035-0A | BOLT, HEX. (6X35) | 1 |
| 3 | 90310-KA3-711 | NUT, HEX. (6MM) | 3 |
| 3 | 94000-06000-0S | NUT, HEX. (6MM) | 3 |
| 3 | 94001-06000 | NUT, HEX. (6MM) | 3 |
| 3 | 94001-06000-0S | NUT, HEX. (6MM) | 3 |
| 3 | 94001-06008-0S | NUT, HEX. (6MM) | 3 |
| 3 | 94001-06200-0S | NUT, HEX. (6MM) | 3 |
| 3 | 94030-06000 | NUT, HEX. (6MM) | 3 |
| 4 | 94030-08000 | NUT, HEX. (8MM) | 4 |
| 2 | 94101-06000 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06080 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94101-06800 | WASHER, PLAIN (6MM) | 2 |
| 2 | 94111-06000 | WASHER, SPRING (6MM) | 2 |
| 8 | 94111-08000 | WASHER, SPRING (8MM) | 8 |
| 1 | 94111-12000 | WASHER, SPRING (12MM) | 1 |
| 95300-08016 | BOLT, HEX. (8X16) | ||
| 95300-08016-00 | BOLT, HEX. (8X16) | ||
| 1 | 96100-62010 | BEARING, RADIAL BALL (6201) | 1 |
| 1 | 96100-62010-00 | BEARING, RADIAL BALL (6201) | 1 |
| 1 | 96140-62010 | BEARING, RADIAL BALL (6201U) | 1 |
| 1 | 96140-62010-00 | BEARING, RADIAL BALL (6201U) | 1 |
