Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 06450-GAG-003 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 1 | 06450-178-932 | SHOE SET, BRAKE (JB) Use from Frame SN 6112061 | 1 |
| 1 | 06450-096-405 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 1 | 451A2-096-305 | SHOE KIT, BRAKE Use from Frame SN 6112061 | 1 |
| 42701-045-670AU | RIM, R. WHEEL *NH35* (CLOUD SILVER) | ||
| 42701-045-670ZC | RIM, R. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42701-045-671ZA | RIM, R. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42702-045-670AU | RIM, L. WHEEL *NH35* (CLOUD SILVER) | ||
| 42702-045-670ZC | RIM, L. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 42702-045-671ZA | RIM, L. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 43100-130-650AU | PANEL, RR. BRAKE *NH35* (CLOUD SILVER) | ||
| 45131-400-000 | CAM, FR. BRAKE | ||
| 45131-400-010 | CAM, FR. BRAKE | ||
| 45131-400-020 | CAM, FR. BRAKE | ||
| 43145-MM9-000 | INDICATOR, RR. BRAKE | ||
| 43145-130-650 | INDICATOR, RR. BRAKE | ||
| 44301-045-010 | AXLE, FR. WHEEL | ||
| 1 | 44311-045-670 | COLLAR, FR. WHEEL SIDE | 1 |
| 44600-045-672AU | HUB, FR. WHEEL *NH35* (CLOUD SILVER) | ||
| 44600-045-673ZB | HUB, FR. WHEEL *NH35M* (CLOUD SILVER METALLIC) | ||
| 44620-045-020 | COLLAR, FR. AXLE DISTANCE | ||
| 1 | 44711-120-671 | TIRE (3.50-8) (2PR) (BS) Use up to Frame SN 6210000 | 1 |
| 42711-130-672 | TIRE, WHEEL (3.50-8) (NITTO) Use from Frame SN 6210001 | ||
| 08400-12010 | TUBE (300/350-8) | ||
| 42712-GC3-003 | TUBE, TIRE (3.00-8) | ||
| 42712-GC3-004 | TUBE, TIRE (3.00-8) (IRC) | ||
| 44712-120-003 | TUBE, TIRE (3.50-8) (BS) | ||
| 44712-120-006 | TUBE, TIRE (3.50-8) (NITTO) | ||
| 44712-045-670 | TUBE, TIRE (3.50-8) | ||
| 44712-120-154 | TUBE, TIRE (3.50-8) (INOUE) | ||
| 45120-096-652 | SHOE, BRAKE (ASK) (SEE KIT P/N--END OF BLOCK) (NA USE ALT:451A2-096-305) | ||
| 2 | 45133-028-000 | SPRING, BRAKE SHOE | 2 |
| 45410-130-650 | ARM, FR. BRAKE | ||
| 1 | 45436-001-000 | NUT, FR. BRAKE ARM SETTING | 1 |
| 4 | 90194-567-010 | BOLT, WHEEL RIM | 4 |
| 1 | 90353-045-000 | NUT, SELF-LOCK (12MM) | 1 |
| 1 | 90525-001-000 | WASHER, RR. BRAKE ARM | 1 |
| 1 | 91252-001-020 | OIL SEAL (21X35X7) | 1 |
| 1 | 91252-001-023 | OIL SEAL (21X35X5.5) | 1 |
| 1 | 92000-06028 | BOLT, HEX. (6X28) | 1 |
| 1 | 92101-06028-0A | BOLT, HEX. (6X28) | 1 |
| 4 | 94030-08000 | NUT, HEX. (8MM) | 4 |
| 1 | 94101-12000 | WASHER, PLAIN (12MM) | 1 |
| 8 | 94111-08000 | WASHER, SPRING (8MM) | 8 |
| 1 | 94520-32000 | CIRCLIP (INNER) (32MM) | 1 |
| 95300-08016 | BOLT, HEX. (8X16) | ||
| 95300-08016-00 | BOLT, HEX. (8X16) | ||
| 1 | 96100-62010 | BEARING, RADIAL BALL (6201) | 1 |
| 1 | 96100-62010-00 | BEARING, RADIAL BALL (6201) | 1 |
| 1 | 96140-62010 | BEARING, RADIAL BALL (6201U) | 1 |
| 1 | 96140-62010-00 | BEARING, RADIAL BALL (6201U) | 1 |
