Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 710004382 | Ground Cable | 1 |
| 1 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 1 |
| 1 | 234161601 | Lock Washer Helical M6 | 1 |
| 1 | 250000717 | Torx Head Screw M6 X 16 | 1 |
| 4 | 224061121 | Flat Washer Includes 16 to 16a | 4 |
| 1 | 232361493 | Domed Nut M6 | 1 |
| 1 | 710004377 | Positive Cable | 1 |
| 1 | 232561434 | Elastic Stop Nut M6 | 1 |
| 1 | 710004376 | Positive Cable | 1 |
| 1 | 710006729 | Battery Cable Cap | 1 |
| 1 | 710005819 | Extension Cable 02 Sensor Not shown | 1 |
| 1 | 270000141 | Clip | 1 |
| 1 | 390402300 | Pop Rivet 3/16" | 1 |
| 1 | 391301600 | Washer | 1 |
| 1 | 710004118 | Connector Bracket | 1 |
| 1 | 210262040 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 1 | 710001642 | Connector Ass'y | 1 |
| 1 | 710001642 | Connector Ass'y Includes 288 to 288b | 1 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 2 | 278000216 | Wire Seal | 2 |
| 1 | 293730040 | Mount Dart | 1 |
| 1 | 710007777 | Starter Relay | 1 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 2 | 232561434 | Elastic Stop Nut M6 | 2 |
| 1 | 207662054 | Hex. Flange Screw M6 X 20 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 1 | 710005072 | Multi-Function Handle | 1 |
| 2 | 205053588 | Socket Head Screw M5 X 35 | 2 |
| 1 | 710005153 | Ignition Switch With Keys | 1 |
| 1 | 710005153 | Ignition Switch With Keys Includes 530 to 530b | 1 |
| XXXX | Not Available As Spare Part - Key, Groove on Right Side | ||
| XXXX | Not Available As Spare Part - Key, Groove on Left Side | ||
| 1 | 710007407 | Multifunction Compact Gauge | 1 |
| 6 | 250000718 | Hex. Screw K40 X 45 | 6 |
| 6 | 517225900 | Flat Washer | 6 |
| 6 | 517168600 | Spring Includes 685 to 685a | 6 |
| 1 | 517168600 | Spring | 1 |
| 2 | 710003900 | Low Beam | 2 |
| 2 | 710003900 | Low Beam Includes 700 to 700a | 2 |
| 1 | 710000871 | Bulb, 12V 35/35W | 1 |
| 4 | 250000720 | Torx Screw K50 X 16 | 4 |
| 1 | 710001203 | Tail Light Housing Ass'y | 1 |
| 1 | 710005569 | Voltage Regulator | 1 |
| 2 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 2 |
| 1 | 710003006 | Housing | 1 |
| 1 | 410301203 | Battery YUASA YTX20L | 1 |
| 1 | 410301203 | Battery YUASA YTX20L Includes 900 to 900a | 1 |
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 1 | 710006561 | Battery Support | 1 |
| 2 | 210262050 | Hexagonal Head Screw | 2 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 4 | 234062670 | Stainless Steel Flat Washer | 4 |
| 2 | 732610072 | Push Nut | 2 |
| 1 | 710002404 | Fixation Plate | 1 |
| 1 | 705014429 | Rubber Stopper | 1 |
| 3 | 207662054 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 710001248 | DC Outlet | 1 |
| 1 | 715004008 | Top Plate | 1 |
| 1 | 710004990 | Multifonction Housing Ass'y | 1 |
| 1 | 710005908 | Screw M10 X1.25 X 20 BHCS S.Grip | 1 |
| 1 | 503192496 | Washer | 1 |
| 1 | 710004567 | Cable | 1 |
