Список запчастей

№	Артикул	Название	Кол-во
1	503191183	Spring Support	2
2	503190754	Retainer Cushion	2
3	205082544	Socket Head Screw M8 X 25	2
4	233281414	Hex. Flange Elastic Nut M8	2
5	503192211	Rocker	1
6	503193037	Bushing	1
7	503189282	Bushing	1
8	207005044	Hex. Screw M10 X 1.5 X 50	1
9	233601416	Elastic Locking Nut M10 X 1.5	1
10	503193274	Front Arm Ass'y Includes 10 To 11	1
11	408200700	Grease Fitting	2
12	503191390	Lower Shaft	1
13	503189324	Bushing	2
14	503192496	Washer	2
15	250000605	Hex. Screw S.Grip M10 X 55	2
16	503191391	Upper Shaft	1
17	503189324	Bushing	2
18	503189564	Washer	2
19	250000605	Hex. Screw S.Grip M10 X 55	2
20	503191396	Axle Pivot	1
21	503191397	Bolt 369mm	1
22	503189157	Washer	4
23	233281414	Hex. Flange Elastic Nut M8	1
24	503191709	Rear Arm Ass'y Includes 24 To 36
25	414644300	Black, Dart	2
26	XXXX	Not Available As Spare Part - Bushing
27	503191565	LH Cam Adjuster	1
28	503191566	RH Cam Adjuster	1
29	293370013	E-Circlip	2
30	503191555	Swivel Bushing	2
31	503191393	Welded Arm Pivot	1
32	503192330	Lower Shaft	1
33	503191640	Cushion	2
34	503189148	Washer	2
35	205523544	Socket Head Screw M12 X 35, Scotch Grip	2
36	408200700	Grease Fitting	4
37	503191451	Cushion	2
38	503191405	Upper Shaft	1
39	503190328	Washer	2
40	503191738	Black, Wheel Ass'y 155 mm	2
41	503191099	Retaining Ring	2
42	503192491	Washer	2
43	250000484	Socket Screw M12 X 35	2
44	503192377	Black RH Square Spring	1
45	503192378	Black LH Square Spring	1
46	503193026	ROD_LINK
47	503191555	Swivel Bushing	2
48	503190114	Spacer	2
49	503190113	Bar Axle (Short)	1
50	503190643	Axle Bar (Long)	1
51	230083044	Hex. Screw M8 X 130	1
52	207089044	Hex. Screw M8 X 90	1
53	503189157	Washer	2
54	233281414	Hex. Flange Elastic Nut M8	2
55	503193000	Rear Shock Ass'y	1
56	503191939	Male Pneumatic Connector	1
57	503192649	Pneumatic Hose Ass'y	1
58	414936000	Bushing	2
59	207684044	Hex. Flange Screw M8 X 40	2
60	233281414	Hex. Flange Elastic Nut M8	2
61	XXXX	Not Available As Spare Part - Center Shock Ass'y Includes 61 To 69
62	503192266	Center Shock	1
63	505073625	Adjustment Cam	1
64	503189686	Black, Spring	1
65	503193663	Protector	1
66	503191872	Spring Guide	1
67	706200881	Spring Stopper	1
68	503189117	Urethane Bushing	2
69	503189282	Bushing	1
70	207005044	Hex. Screw M10 X 1.5 X 50	1
71	233601416	Elastic Locking Nut M10 X 1.5	1
72	XXXX	Not Available As Spare Part - Synthetic Grease
73	706001349	Compressor	1
74	706000940	Check Valve	1
75	706000869	Connector	1
76	219704415	Hose 4.32Mm 3000Mm Long	1
77	503193103	Compressor Bracket	2
78	706000631	Compressor Isolator	1
79	503193484	SUPPORT
80	513033638	Protector Tube
81	219704425	Tubing 6 Mm 3000Mm Long	1
82	503193009	Air manifold Ass'y	1
83	205562044	Socket Head Screw M6 X 20, Scotch Grip	2
84	234061410	Flat Washer 6 mm	2
85	503193034	Tube	1
86	250000722	Torx Screw M6 X 20	4
87	234061410	Flat Washer 6 mm	2
88	207063544	Hex. Flange Screw M6 X 35
89	503193393	CLAMP
90	235551494	Torx Screw M5 X 14	1
91	233251434	Flange Elastic Nut M5	1
92	293150102	Rivet 3/16"	7
93	503193004	BRACKET
94	503193006	HOSE PROTECTOR
95	503193007	HOSE PROTECTOR
96	503193011	HOSE PROTECTOR PAINTED
97	515177125	Compressor Module	1
