Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204611531 | RETAINING CLIP | 1 |
| 18 | 204613998 | SEAT SUPPORT | 18 |
| 38 | 293150043 | Pop Rivet 3/16" | 38 |
| 38 | 234061600 | Stainless Flat Washer M6 | 38 |
| 14 | 293150011 | Pop Rivet 3/16" | 14 |
| 6 | 204100054 | SCREW 8 X 3/4? | 6 |
| 4 | 204611940 | SEAT LATCH | 4 |
| 8 | 204100039 | SCREW 1/4?-20 X 2? | 8 |
| 204611805 | LATCH | ||
| 14 | 204100219 | SCREW-PAN HD.#10-32 X 1-1/4 SS | 14 |
| 204614576 | Spotter's Seat Cushion Ass'y | ||
| 1 | 202000159 | SCREW-STUD TAPP. 3/8 SS | 1 |
| 204614578 | Spotter's Seat Side Backrest | ||
| 204614580 | Spotter's Seat Storage Backrest | ||
| 7 | 293150043 | Pop Rivet 3/16" | 7 |
| 1 | 204072218 | GAS SHOCK | 1 |
| 2 | 204073074 | Shock Bracket | 2 |
| 4 | 293150011 | Pop Rivet 3/16" | 4 |
| 204613980 | Hinge | ||
| 7 | 293150011 | Pop Rivet 3/16" | 7 |
| 204614547 | Rear Cushion, Port Side | ||
| 204614550 | Rear Center Cushion Includes 22 to 24 | ||
| 204614513 | MAGNETIC CATCH ASS'Y | ||
| 4 | 204100054 | SCREW 8 X 3/4? | 4 |
| 1 | 204614709 | SEAT SUPPORT ASS'Y | 1 |
| 4 | 208564060 | PHILLIPS SCREW M6 X 40 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 4 | 232561600 | Hex. Elastic Stop Nut M6 | 4 |
| 204614551 | Rear Cushion, Starboard | ||
| 204614552 | Rear Side Cushion, Port Side | ||
| 204614553 | Rear Side Cushion, Starboard Includes 30b to 32 | ||
| 7 | 204100054 | SCREW 8 X 3/4? | 7 |
| 204614554 | Rear Side Backrest, Port Side | ||
| 204614555 | Rear Corner Backrest, Port Side | ||
| 204614557 | Rear Side Flat Backrest, Starboard Includes 35 to 36 | ||
| 5 | 234062600 | Flat Washer M6, Stainless | 5 |
| 204614558 | Rear Center Backrest Includes 37 to 40 | ||
| 3 | 234461608 | External Serrated Lock Washer 6 mm | 3 |
| 204100060 | Hex. Jam Nut | ||
| 3 | 234062600 | Flat Washer M6, Stainless | 3 |
| 204614559 | Rear Corner Backrest, Starboard | ||
| 204614560 | Rear Side Backrest, Port Side | ||
| 204614574 | Sundeck Cushion, Port Side | ||
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 8 | 211200025 | Lock Washer 1/4” | 8 |
| 211100026 | HEX. NUT 1/4 | ||
| 204130008 | Plastic Cap, White | ||
| 204614575 | Sundeck Center Cushion Includes 48 to 50 | ||
| 2 | 204100054 | SCREW 8 X 3/4? | 2 |
| 1 | 204614762 | HOLDER | 1 |
| 204614760 | RUBBER HOLDER | ||
| 1 | 204100122 | SCREW-PAN HD. 10-24 UNC X .50 SS | 1 |
| 1 | 204100236 | SCREW-HEX.HD.MACHINE #10 X 1 | 1 |
| 1 | 211200033 | FLAT WASHER | 1 |
| 204614573 | Sundeck Cushion, Starboard | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
