Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 5 | 204470026 | Courtesy Light Ass'y Includes 1 - 2. | 5 |
| 1 | 204470081 | BULB | 1 |
| 20 | 293150032 | RIVET_POP 1/8 X ,487 | 20 |
| 204470559 | Radio Support | ||
| 1 | 232051600 | Hex. Nut M5 | 1 |
| 1 | 234151601 | Helical Lock Washer M5 | 1 |
| 1 | 234052600 | Flat Washer 5 mm, Stainless | 1 |
| 209642560 | PHILLIPS SCREW M4.2 X 25 | ||
| 204470611 | Facia Includes 9 - 11. | ||
| 204470268 | Double Faced Tape (Meter) | ||
| 2 | 293730014 | Black Dart | 2 |
| 204470621 | Harness Radio | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 204470378 | Speaker | ||
| 219704457 | ADHESIVE LOCTITE 425 20ML | ||
| 1 | 204470252 | Jack (12 volts) | 1 |
| 204470630 | Instrumentation Harness | ||
| 204470418 | Horn | ||
| 1 | 204470528 | Female Terminal Housing, 2 Circuits | 1 |
| 2 | 278001014 | Female Terminal | 2 |
| 2 | 278001013 | Wire Seal | 2 |
| 204470548 | Horn Cover | ||
| 204470099 | BILGE PUMP SWITCH ASS'Y Includes 24 - 25. | ||
| 204470132 | Gasket | ||
| 1 | 204470100 | LIGHT SWITCH ASS'Y Includes 26 - 27. | 1 |
| 1 | 204470101 | HORN SWITCH ASS'Y Includes 28 - 29. | 1 |
| 204470102 | COURTESY LIGHT SWITCH ASS'Y Includes 30 - 31. | ||
| 204470391 | Oil/Fuel Gauge | ||
| 204470463 | Safety Switch Includes 33 - 36. | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 2 | 278000218 | Wire Seal | 2 |
| 2 | 278000222 | Male Terminal | 2 |
| 204470561 | Speedometer Gauge | ||
| 1 | 204470464 | Safety Lanyard | 1 |
| 278000099 | Safety Switch Nut | ||
| 204470535 | Radio Cover | ||
| 2 | 293150005 | Pop Rivet 3/16" | 2 |
| 293750015 | TIE RAP MOUNT | ||
| 204470466 | Tachometer Gauge | ||
| 2 | 204470343 | LOCKING PLATE | 2 |
| 1 | 204000081 | Pop Rivet 3/16" | 1 |
| 1 | 204100027 | FLAT WASHER | 1 |
| 204470011 | VENTILATION SWITCH ASS'Y Includes 47 - 48. | ||
| 204470308 | Gasket | ||
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 204470309 | Gasket | ||
| 204470146 | Gauge Nut | ||
| 204470171 | Gauge Nut | ||
| 204470554 | Radio Compact Disk | ||
| 204470380 | Antenna | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 204470401 | Switch Panel | ||
| 1 | 204470544 | BATTERY SWITCH Includes 60 - 61. | 1 |
| 1 | 204470402 | LIGHT SWITCH Includes 62 - 63. | 1 |
| 204470403 | LIGHT SWITCH, BOARDING Includes 64 - 65. | ||
| 204470404 | LIGHT SWITCH, DOCKING Includes 66 - 67. | ||
| 1 | 204470405 | SWITCH, SMALL POOL PUMP Includes 68 - 69. | 1 |
| 204470406 | SWITCH, PASSENGER WATER PUMP Includes 70 - 71. | ||
| 204470411 | Engine Compartment Light Includes 72 - 75. | ||
| 3 | 241142560 | Hex. Flange Screw K40 X 25 | 3 |
| 1 | 204470551 | LIGHT HARNESS Includes 77 - 81. | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 2 | 409007300 | Female Terminal | 2 |
| 4 | 278000218 | Wire Seal | 4 |
| 204470412 | Engine Compartment Light |
