Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 13200-37E20 | CARBURETOR ASSY MODEL W | ||
| 13200-37E30 | CARBURETOR ASSY MODEL X | ||
| 13200-37E40 | CARBURETOR ASSY MODEL Y; Includes Item(s) 1 - 23 | ||
| 1 | 13681-43D30 | CAP, CARBURETOR | 1 |
| 13260-43D30 | CAP SET, TOP | ||
| 13573-43D30 | SPRING, THROTTLE VALVE | ||
| 1 | 13424-43D30 | COLLAR, THROTTLE VALVE | 1 |
| 1 | 13581-43D30 | HOLDER, CABLE | 1 |
| 1 | 13394-28E00 | .CLIP, NEEDLE | 1 |
| 13551-37E00 | VALVE, THROTTLE MODEL W | ||
| 13551-36E00 | VALVE, THROTTLE MODEL X/Y | ||
| 1 | 09491-32011 | JET, MAIN (162) MODEL W | 1 |
| 1 | 09491-31013 | JET, MAIN (158) MODEL X/Y | 1 |
| 1 | 09492-45032 | JET, PILOT (45) MODEL W/X | 1 |
| 1 | 09492-42019 | JET, PILOT (42) MODEL Y | 1 |
| 1 | 13696-44E00 | GASKET, FLOAT CHAMBER | 1 |
| 1 | 13370-43D30 | VALVE SET, FLOAT | 1 |
| 13240-28E00 | FLOAT SET | ||
| 1 | 13247-28E00 | .BOLT, DRAIN | 1 |
| 1 | 13246-28E00 | O RING | 1 |
| 4 | 02112-34163 | SCREW | 4 |
| 2 | 13693-36E00 | PLATE | 2 |
| 1 | 13270-43D30 | SCREW SET, STOP | 1 |
| 1 | 13280-43D30 | SCREW SET, AIR | 1 |
| 1 | 13410-43D30 | STARTER VALVE MODEL W/X | 1 |
| 13410-36E40 | STARTER VALVE MODEL Y | ||
| 4 | 13686-36E00 | .HOSE, (4X7X620) UP/RH L:620(r)580 UP/LH L:620(r)550 RH L:620(r)400 LH L:620(r)360 | 4 |
| 5 | 09401-06101 | CLIP | 5 |
| 1 | 09351-35653-600 | HOSE (3.5X6.5X600) L:600(r)330 | 1 |
| 13383-37EK0 | NEEDLE, JET (N1EI) MODEL W | ||
| 13383-37EH0 | NEEDLE, JET (N1EG) MODEL X | ||
| 1 | 13383-37EQ0 | NEEDLE, JET (N3WK) MODEL Y; Includes Item(s) 24 - 30 | 1 |
| 09492-60018 | JET, POWER (60) MODEL W | ||
| 1 | 09492-55019 | JET, POWER (55) MODEL X/Y | 1 |
| 13247-44E00 | SCREW, DRAIN | ||
| 13256-44E00 | O RING | ||
| 1 | 13160-37E00 | SOLENOID ASSY MODEL W/X | 1 |
| 1 | 13160-37E01 | SOLENOID ASSY MODEL Y | 1 |
| 1 | 13453-37E00 | O RING | 1 |
| 13451-37E00 | CLAMP | ||
| 13452-37E00 | SCREW | ||
| 1 | 09404-06429 | CLAMP, AIR VENT (L:60) MODEL W | 1 |
| 1 | 09404-06432 | CLAMP, AIR VENT (L:60) MODEL X/Y | 1 |
| 13383-37EC0 | NEEDLE, JET (N0ZG) OPT,MODEL W/X | ||
| 13383-37ED0 | NEEDLE, JET (N0ZH) OPT,MODEL W/X | ||
| 13383-37EE0 | NEEDLE, JET (N0ZI) OPT,MODEL W/X | ||
| 13383-37EF0 | NEEDLE, JET (N0ZJ) OPT,MODEL W | ||
| 13383-37EG0 | NEEDLE, JET (N0ZK) OPT,MODEL W | ||
| 13383-37EA0 | NEEDLE, JET (NOZE) OPT,MODEL X | ||
| 13383-37EB0 | NEEDLE, JET (NOZF) OPT,MODEL X | ||
| 13383-37EH0 | NEEDLE, JET (N1EG) OPT,MODEL W/X | ||
| 13383-37EJ0 | NEEDLE, JET (N1EH) OPT,MODEL W/X | ||
| 13383-37EK0 | NEEDLE, JET (N1EI) OPT,MODEL W/X | ||
| 13383-37EL0 | NEEDLE, JET (N1EJ) OPT,MODEL W | ||
| 13383-37EM0 | NEEDLE, JET (N1EK) OPT,MODEL W | ||
| 13383-37E50 | NEEDLE, JET (NIEE) OPT,MODEL X | ||
| 13383-37E60 | NEEDLE, JET (NIEF) OPT,MODEL X | ||
| 13383-37EN0 | NEEDLE, JET (N3WW) OPT,MODEL Y | ||
| 13383-37EP0 | NEEDLE, JET (N3WJ) OPT,MODEL Y | ||
| 1 | 13383-37EQ0 | NEEDLE, JET (N3WK) OPT,MODEL Y | 1 |
| 13383-37ER0 | NEEDLE, JET (N3WL) OPT,MODEL Y | ||
| 13383-37ES0 | NEEDLE, JET (N3WM) OPT,MODEL Y | ||
| 13383-36EA0 | NEEDLE, JET (N3YW) OPT,MODEL Y | ||
| 13383-36EB0 | NEEDLE, JET (N3YJ) OPT,MODEL Y | ||
| 13383-36EC0 | NEEDLE, JET (N3YK) OPT,MODEL Y | ||
| 13383-36ED0 | NEEDLE, JET (N3YL) OPT,MODEL Y | ||
| 13383-36EE0 | NEEDLE, JET (N3YM) OPT,MODEL Y | ||
| 1 | 09491-30018 | JET, MAIN (150) OPT | 1 |
| 1 | 09491-30019 | JET, MAIN (152) OPT | 1 |
| 1 | 09491-31012 | JET, MAIN (155) OPT | 1 |
| 1 | 09491-31013 | JET, MAIN (158) OPT | 1 |
| 1 | 09491-32010 | JET, MAIN (160) OPT | 1 |
| 1 | 09491-32011 | JET, MAIN (162) OPT | 1 |
| 1 | 09491-33009 | JET, MAIN (165) OPT | 1 |
| 1 | 09491-33010 | JET, MAIN (168) OPT | 1 |
| 1 | 09491-34010 | JET, MAIN (170) OPT | 1 |
| 1 | 09491-34011 | JET, MAIN (172) OPT | 1 |
| 1 | 09491-35009 | JET, MAIN (175) OPT | 1 |
| 1 | 09491-35010 | JET, MAIN (178) OPT | 1 |
| 1 | 09491-36008 | JET, MAIN (180) OPT | 1 |
| 09491-37008 | JET, MAIN (185) OPT | ||
| 09491-38011 | JET, MAIN (190) OPT | ||
| 09491-39001 | JET, MAIN (195) OPT | ||
| 1 | 09491-40013 | JET, MAIN (200) OPT | 1 |
| 09491-41001 | JET, MAIN (205) OPT | ||
| 09491-42006 | JET, MAIN (210) OPT | ||
| 1 | 09492-35019 | JET, PILOT (35) OPT | 1 |
| 1 | 09492-40022 | JET, PILOT (40) OPT | 1 |
| 1 | 09492-42019 | JET, PILOT (42) OPT | 1 |
| 1 | 09492-45032 | JET, PILOT (45) OPT | 1 |
| 1 | 09492-48013 | JET, PILOT (48) OPT | 1 |
| 1 | 09492-50023 | .JET, SLOW (50) OPT | 1 |
| 1 | 09492-52011 | JET, PILOT (52) OPT | 1 |
| 1 | 09492-55017 | JET, PILOT (55) OPT | 1 |
| 1 | 09492-58001 | JET, PILOT (58) OPT | 1 |
| 09492-60016 | JET, PILOT (60) OPT | ||
| 09492-50025 | JET, POWER (50) OPT | ||
| 1 | 09492-55019 | JET, POWER (55) OPT | 1 |
| 09492-60018 | JET, POWER (60) OPT |
