Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204160050 | Stainless Steel Impeller | ||
| 204120127 | Pump Support | ||
| 2 | 271000516 | Impeller Boot | 2 |
| 271000291 | IMPELLER SHAFT | ||
| 4 | 293900001 | Venturi Bushing | 4 |
| 204120094 | RH Shoe | ||
| 204120095 | LH Shoe | ||
| 204120084 | RH MOBIL GRATE | ||
| 204120087 | LH Mobil Grate | ||
| 204160051 | Impeller Housing Ass'y Includes 8 - 9. | ||
| 2 | 271000290 | Wear Ring | 2 |
| 8 | 271000399 | Nut Housing | 8 |
| 4 | 293350017 | Needle Bearing | 4 |
| 293350019 | BEARING THRUST | ||
| 2 | 293300011 | O-Ring | 2 |
| 2 | 211500001 | Pipe Plug Socket Head 1/8-27 Npt | 2 |
| 271000670 | IMPELLER COVER | ||
| 6 | 210000009 | Hex. Screw M5 x 20 | 6 |
| 2 | 293250084 | Watertight Seal | 2 |
| 293350020 | THRUST WASHER | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 8 | 271000693 | Stud | 8 |
| 8 | 213200003 | Washer 10 mm | 8 |
| 16 | 213000003 | Lock Washer 10 mm | 16 |
| 212100007 | NUT-HEXAGONAL DIN.934A2 | ||
| 271000624 | Venturi | ||
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 2 | 293200025 | Double Lip Seal | 2 |
| 1 | 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | 1 |
| 8 | 216364060 | Screw M6 x 40 | 8 |
| 204120110 | Steering Nozzle (Black) R.H | ||
| 204120111 | Steering Nozzle (Black) L.H | ||
| 4 | 271000122 | Steering Nozzle Sleeve | 4 |
| 8 | 213200002 | Flat Washer 8 mm | 8 |
| 8 | 213000001 | Lock-Washer 8 mm | 8 |
| 215687560 | Hex. Screw M8 x 75 | ||
| 2 | 271000517 | Impeller Ring | 2 |
| 8 | 216363060 | Screw M6 x 30 | 8 |
| 6 | 213200004 | Flat Washer 5 mm | 6 |
| 1 | 293800053 | Sealant Right Stuff 26015, 7 oz | 1 |
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 271000704 | SPRING | ||
| 1 | 219704455 | Was 293800018 Loctite 592, 50 ml | 1 |
| 1 | 219704458 | Was 293800041 Loctite Primer 7649 | 1 |
| 271000898 | Pusher | ||
| 204120083 | Grate Support, Starboard | ||
| 1 | 204120086 | GRATE SUPPORT, PORT SIDE | 1 |
| 4 | 204390001 | PLASTIC BUSHING | 4 |
| 4 | 211000099 | SOCKET SCREW M6 X 8 | 4 |
| 12 | 212000001 | Elastic Stop Nut M6 | 12 |
| 4 | 217383600 | Lock Washer 8 mm | 4 |
| 12 | 213200007 | Washer 6 mm | 12 |
| 1 | 277000439 | HEX. NUT 5/16-24 | 1 |
| 8 | 217002600 | Flat Washer | 8 |
| 1 | 211100034 | HEX. NUT 5/16-24 | 1 |
| 4 | 211000047 | SCREW-SPECIAL M8 | 4 |
| 204120076 | Link Rod | ||
| 4 | 211200019 | FLAT WASHER | 4 |
| 2 | 212000005 | NUT-STOP ELASTIC MS-17830 | 2 |
| 1 | 204120074 | BALL JOINT | 1 |
| 204120075 | BALL JOINT | ||
| 204120128 | Shim 1.3 mm | ||
| 204120129 | Shim 0.3 mm | ||
| 5 | 204120067 | Shim 0.9 mm | 5 |
| 272000019 | DRIVE SHAFT PLUG |
