Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 278001089 | High Voltage Box Base | ||
| 278001265 | Cover | ||
| 278000732 | Ground Plate | ||
| 204470236 | LH Ignition Coil | ||
| 278001193 | Mounting Plate | ||
| 278000440 | GASKET | ||
| 293200030 | Gasket | ||
| 2 | 278001240 | RECTIFIER ASS'Y Includes 8 - 12. | 2 |
| 2 | 278000273 | Male Housing, 3 Circuits | 2 |
| 10 | 409007300 | Female Terminal | 10 |
| 10 | 278000218 | Wire Seal | 10 |
| 2 | 278000220 | Male Connector, 2 Circuits | 2 |
| 4 | 213200001 | Flat Washer 6 mm | 4 |
| 12 | 212000001 | Elastic Stop Nut M6 | 12 |
| 278000682 | Grommet | ||
| 2 | 278000513 | Starter Relay | 2 |
| 1 | 204470269 | RED BOOT | 1 |
| 4 | 211000035 | Self Tapping Screw M6 x 10 | 4 |
| 215462550 | Self Tapping Screw M6.3 x 25 | ||
| 4 | 293750001 | Tie Wrap 94 mm | 4 |
| 278000100 | Electric Wire Cap | ||
| 204470166 | Electric Box Harness Includes 22 - 31. | ||
| 2 | 270000137 | Female Connector, 6 Circuits | 2 |
| 2 | 278000735 | Female Lock, 6 Circuits | 2 |
| 8 | 278000631 | Male Terminal | 8 |
| 2 | 278000230 | Male Terminal | 2 |
| 2 | 278001008 | Insulated Sheath | 2 |
| 4 | 293000052 | Sealing Cap | 4 |
| 4 | 278001114 | Female Terminal | 4 |
| 4 | 278000992 | Open Barrel | 4 |
| 2 | 278001113 | Male Connector, 2 Circuits | 2 |
| 204470161 | Harness Fuse 15 Amp Includes 32 - 38. | ||
| 2 | 278000345 | Fuse Cap | 2 |
| 2 | 278000343 | Fuse, 15 Amperes | 2 |
| 2 | 278001009 | Female Terminal | 2 |
| 2 | 278001007 | Insulated Sheath | 2 |
| 2 | 278000805 | Cushion | 2 |
| 278000300 | Ring Terminal | ||
| 8 | 213200004 | Flat Washer 5 mm | 8 |
| 8 | 293150011 | Pop Rivet 3/16" | 8 |
| 204470254 | Battery Support | ||
| 211000009 | SCREW-PAN HD.PH.DIN.7985A-A2 | ||
| 204470268 | Double Faced Tape (Meter) | ||
| 278000245 | 3 WIRE SUPPORT | ||
| 4 | 293750002 | Tie Wrap 142 mm | 4 |
| 204470167 | RH Battery Cable (Red) Includes 46 - 48. | ||
| 204470168 | LH Battery Cable (Red) | ||
| 278000098 | GROMMET | ||
| 1 | 211100063 | HEX. NUT 3/8-16 | 1 |
| 278000680 | Battery Pole (Negative) | ||
| 1 | 204470199 | RH GROUND CABLE | 1 |
| 204470051 | LH Ground Cable | ||
| 4 | 278000609 | Spark Plug NGK BR8ES | 4 |
| 204470224 | Box Support | ||
| 2 | 278000965 | Temperature Sensor | 2 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 278001268 | Spark Plug Wire | 1 |
| 8 | 211200029 | FLAT WASHER, PLASTIC | 8 |
| 278000020 | PROTECTION CAP | ||
| 204470164 | Starter Cable Includes 59 - 62. | ||
| 204470091 | Spark Plug Cap | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 2 | 213200016 | Flat Washer, Emhart | 2 |
| 2 | 293150005 | Pop Rivet 3/16" | 2 |
| 12 | 213200007 | Washer 6 mm | 12 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 213400001 | WASHER-LOCK TOOTHED DIN.6797A-A2 | ||
| 2 | 213200002 | Flat Washer 8 mm | 2 |
| 215681660 | Hex. Screw M8 x 16 | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 2 | 293730018 | Mount Dart | 2 |
| 3 | 293750002 | Tie Wrap 142 mm | 3 |
| 1 | 219704353 | Protection Trim 1000mm Long | 1 |
| 4 | 213200011 | Flat Washer 8 mm | 4 |
| 4 | 213000001 | Lock-Washer 8 mm | 4 |
| 4 | 218681000 | Wing Nut M8 | 4 |
| 4 | 210000004 | Hex. Screw M6 x 20 | 4 |
| 4 | 212000001 | Elastic Stop Nut M6 | 4 |
| 278000664 | Ground Harness Includes 82 - 84. | ||
| 2 | 278000228 | FEMALE TERMINAL | 2 |
| 2 | 213200001 | Flat Washer 6 mm | 2 |
| 204250037 | Regulator Support | ||
| 4 | 211200055 | Flat Washer, Stainless/Neoprene | 4 |
| 4 | 278000559 | COLLAR SUPPORT | 4 |
| 2 | 217161600 | Washer Star 6 mm | 2 |
| 204470052 | Ground Cable | ||
| 204470226 | Battery Switch (5616) | ||
| 204470259 | SWITCH SUPPORT | ||
| 4 | 215853568 | Screw M5 x 35 | 4 |
| 204470253 | Spacer (5616) | ||
| 4 | 212000004 | Elastic Stop Nut M5 | 4 |
| 4 | 215842560 | Screw M4 x 25 | 4 |
| 4 | 217041600 | Washer 4 mm | 4 |
| 204470250 | POSITIVE SWITCH CABLE | ||
| 219704457 | ADHESIVE LOCTITE 425 20ML |
