Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 279000126 | Shock Absorber | 1 |
| 2 | 279000051 | Bushing | 2 |
| 1 | 279000055 | SHOCK LOWER HOLDER | 1 |
| 1 | 207227060 | HEX. SCREW M12 X 70, SCOTCH GRIP | 1 |
| 1 | 250200053 | FLAT WASHER M12 | 1 |
| 1 | 279000057 | Shock Upper Holder | 1 |
| 6 | 207383060 | Hex. Screw M8 X 30, Scotch Grip | 6 |
| 6 | 234080600 | Flat Washer M8, Stainless | 6 |
| 279000207 | PUMP | ||
| 279000117 | ACTUATOR | ||
| 1 | 279000162 | CONNECTOR HOSE | 1 |
| 1 | 219704425 | Tubing 6 Mm 3000Mm Long | 1 |
| 3 | 293750001 | Tie Wrap 94 mm | 3 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 293730040 | Mount Dart | 1 |
| 1 | 293650079 | Norma Clamp | 1 |
| 1 | 279000070 | LH SPRING HOLDER | 1 |
| 1 | 279000074 | RH SPRING HOLDER | 1 |
| 2 | 279000103 | BUSHING | 2 |
| 2 | 279000104 | O-RING | 2 |
| 279000105 | COUSSINET *BUSHING | ||
| 3 | 205562560 | Socket Head Screw M6 X 25, Scotch Grip | 3 |
| 3 | 234061600 | Stainless Flat Washer M6 | 3 |
| 1 | 279000128 | PAINTED SPRING | 1 |
| 1 | 279000130 | Spring Spacer | 1 |
| 1 | 279000131 | PAINTED SPRING | 1 |
| 1 | 279000121 | Lower Spring Protector | 1 |
| 1 | 279000061 | UPPER SPRING HOLDER | 1 |
| 1 | 279000134 | UPPER SPRING PROTECTOR | 1 |
| 2 | 279000106 | CLAMP | 2 |
| 4 | 207362060 | Hex. Screw M6 X 20, Scotch Grip | 4 |
| 4 | 234061600 | Stainless Flat Washer M6 | 4 |
| 1 | 270000251 | Position Sensor | 1 |
| 1 | 270000544 | O-Ring | 1 |
| 1 | 279000098 | POSITION SENSOR BRACKET | 1 |
| 1 | 279000099 | SENSOR LEVER | 1 |
| 1 | 279000107 | POSITION SENSOR COVER | 1 |
| 1 | 279000108 | O-Ring | 1 |
| 2 | 207144060 | Hex. Screw M4 X 40 | 2 |
| 4 | 234041600 | Flat Washer 4 mm, Stainless | 4 |
| 2 | 232541200 | Elastic Stop Nut M4 | 2 |
| 1 | 279000139 | THREADED ROD | 1 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
| 1 | 232561200 | Brass Elastic Stop Nut M6 | 1 |
| 279000154 | SPRING ALIGNMENT ADAPTOR | ||
| 4 | 205562560 | Socket Head Screw M6 X 25, Scotch Grip | 4 |
| 207287560 | HEX. SCREW M8 X 75, SCOTCH GRIP | ||
| 1 | 234080600 | Flat Washer M8, Stainless | 1 |
| 2 | 279000137 | BUSHING | 2 |
| 1 | 279000138 | SPACER | 1 |
| 1 | 279000157 | SPRING ALIGNMENT ARM | 1 |
| 1 | 207086060 | HEX. SCREW M8 X 60 | 1 |
| 2 | 234080600 | Flat Washer M8, Stainless | 2 |
| 1 | 279000153 | SPACER | 1 |
| 1 | 232581200 | Hex. Elastic Nut M8 Brass | 1 |
| 279000008 | CENTRAL BELLOWS | ||
| 1 | 279000010 | Retaining Plate | 1 |
| 10 | 293150123 | Pop Rivet 3/16" | 10 |
| 6 | 250200011 | Flat Washer 8 mm, Stainless | 6 |
