Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204610001 | Front Backrest Ass'y Includes 1 - 3. | ||
| 204610029 | Front Backrest Cover (Dark Green) | ||
| 204610030 | Front Backrest Foam (1/2") | ||
| 269000388 | SEAT SUPPORT | ||
| 12 | 293150043 | Pop Rivet 3/16" | 12 |
| 269000380 | Threaded Rod M5 | ||
| 1 | 293800015 | Lubrifiant - Deoxit, 250 ml | 1 |
| 204610006 | Rear Backrest Ass'y Includes 8 - 11. | ||
| 204610035 | Rear Bump Cover (Dark Green) left 204610381 | ||
| 204610036 | Rear (Center) Backrest Cover (White) | ||
| 204610037 | Rear Backrest Cover (White/Serigraphy) | ||
| 4 | 210000015 | Hexagonal Screw M6 x 30 | 4 |
| 13 | 213200007 | Washer 6 mm | 13 |
| 204610007 | Rear Seat Ass'y Includes 14 - 17. | ||
| 204610039 | Rear Seat Cover (Dark Green) | ||
| 269000231 | Rear Seat Pillow Cover | ||
| 269000232 | Rear Seat Pillow Foam | ||
| 4 | 210000005 | Hex. Screw M6 x 25 | 4 |
| 4 | 293730014 | Black Dart | 4 |
| 204610008 | RH Rear Seat Arm-Rest Ass'y Includes 20 - 21. | ||
| 204610048 | RH Rear Seat Arm-Rest Cover (Dark Gree | ||
| 204610009 | LH Rear Seat Arm-Rest Ass'y Includes 22 - 23. | ||
| 204610050 | LH Rear Seat Arm-Rest Cover (Dark Green) | ||
| 204610010 | Rear Spoiler Ass'y Includes 24 - 27. | ||
| 204610052 | Rear Spoiler Cover (Dark Green) | ||
| 204610053 | Foam Spoiler | ||
| 204610184 | Staple Cover, Meter | ||
| 5 | 210000006 | Hex. Screw M6 x 30 | 5 |
| 204610011 | Sun Deck Pillow Ass'y Includes 29 - 32. | ||
| XXXX | Not Available As Spare Part - Sun Deck Upper Cover | ||
| 204610193 | Sun Deck Lower Cover | ||
| 204610194 | Strap | ||
| 14 | 293730006 | Black, Dart | 14 |
| 204610012 | RH Elbow Padding Ass'y Includes 34 - 36. | ||
| 204610120 | RH Elbow Padding Cover (Dark Green) | ||
| 204610121 | Neoprene Foam | ||
| 204610013 | LH Elbow Padding Ass'y Includes 37 - 39. | ||
| 204610122 | LH Elbow Padding Cover (Dark Green) | ||
| 204610123 | Neoprene Foam | ||
| 204610002 | Center Front Seat Ass'y Includes 40 - 48. | ||
| 204610032 | Center Front Seat Cover (White) | ||
| 204610033 | Center Front Seat Foam (1 1/4") | ||
| 204610034 | Center Front Seat Foam (1/4") | ||
| 293000060 | Passenger Strap | ||
| 5 | 211000028 | Screw K40 x 10 | 5 |
| 2 | 217042600 | Flat Washer 4 mm | 2 |
| 204610178 | Front Seat Latch | ||
| 204610207 | Seat Stud | ||
| 293830043 | Rubber Stopper | ||
| 2 | 293150013 | Pop Rivet 3/16" | 2 |
| 8 | 211000028 | Screw K40 x 10 | 8 |
| 204610003 | LH Front Seat Ass'y Includes 55 - 58. | ||
| 204610040 | LH Front Seat Cover (White) | ||
| 204610041 | LH Front Seat Foam (1 1/4") | ||
| 204610042 | LH Front Seat Foam (1/4") | ||
| 6 | 204610100 | SEAT BRACKET | 6 |
| 204610004 | RH Front Seat Ass'y Includes 60 - 63. | ||
| 204610044 | RH Front Seat Cover (White) |
