Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 204620079 | Windscreen | 2 |
| 204620281 | HINGE ASS'Y | ||
| 10 | 293150039 | Pop Rivet 3/16" | 10 |
| 204620087 | RETAINING PLATE | ||
| 204620124 | DEFLECTOR | ||
| 2 | 204620106 | REAR STOPPER | 2 |
| 2 | 204620070 | LATCH | 2 |
| 2 | 204620080 | FOAM, WINDSCREEN | 2 |
| 4 | 207151260 | HEX. SCREW M6 X 12 | 4 |
| 2 | 232551600 | Hex. Elastic Nut M5 | 2 |
| 4 | 204620115 | Nut Housing | 4 |
| 4 | 232551600 | Hex. Elastic Nut M5 | 4 |
| 4 | 204620295 | RUBBER STOPPER | 4 |
| 2 | 207151260 | HEX. SCREW M6 X 12 | 2 |
| 4 | 234052600 | Flat Washer 5 mm, Stainless | 4 |
| 2 | 204620194 | RETAINER CABLE | 2 |
| 4 | 204620126 | ROLLED PIN 1.5 X 10 MM | 4 |
| 1 | 413708300 | Glue Tube, Loctite 454, 20 G | 1 |
| 204620127 | CABLE ATTACHEMENT | ||
| 204620018 | HINGE SPRING | ||
| 6 | 207152060 | Hex. Screw M5 X 20 | 6 |
| 6 | 234052600 | Flat Washer 5 mm, Stainless | 6 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 208662560 | PHILLIPS SCREW M6 X 25 | ||
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 204620280 | WINDSCREEN INSERT | 2 |
| 2 | 269500416 | Storage Tray | 2 |
| 1 | 293250037 | GASKET | 1 |
| 1 | 269500606 | Extinguisher Housing | 1 |
| 1 | 269500603 | Extinguisher Cap | 1 |
| 2 | 293150032 | RIVET_POP 1/8 X ,487 | 2 |
| 2 | 234032600 | Flat Washer M3, Stainless | 2 |
| 204630008 | ICEBOX FOAM | ||
| 204630050 | Socket Wrench | ||
| XXXX | Not Available As Spare Part - Steel Bar | ||
| 204070995 | RH Mirror Ass'y Includes 37 to 54 | ||
| 205087560 | Socket Head Screw M8 X 75 | ||
| 2 | 232581600 | Hex. Elastic Nut M8 | 2 |
| 293550010 | Synthetic Grease, 400 G | ||
| XXXX | Not Available As Spare Part - Mirror Housing Support | ||
| 3 | 241141660 | Hex. Flange Screw K40 X 16 | 3 |
| XXXX | Not Available As Spare Part - Mirror Frame | ||
| 269500079 | MIRROR BALL JOINT | ||
| 1 | 269500453 | Mirror Spring | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 269500454 | MIRROR | 1 |
| 230060060 | Hex. Screw M6 X 100 | ||
| 2 | 207069060 | HEX. SCREW M6 X 90 | 2 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 204070997 | Adaptor, Black | ||
| 1 | 232061600 | Hex. Nut M6 | 1 |
| XXXX | Not Available As Spare Part - Adaptor #1 (Black) | ||
| XXXX | Not Available As Spare Part - Adaptor #2 (Black) | ||
| 293250035 | RH Gasket | ||
| 4 | 232061600 | Hex. Nut M6 | 4 |
| 4 | 234061600 | Stainless Flat Washer M6 | 4 |
| 291000679 | RH Reinforcement Plate | ||
| 204620063 | LATCH KIT | ||
| 204130080 | RIVET_PLASTIC | ||
| 2 | 204070304 | LATCH PLATE | 2 |
| 219704463 | Était Was 413705800 Loctite 414 , 29.5 c.c | ||
| 204070394 | LATCH GUIDE | ||
| 293830043 | Rubber Stopper | ||
| 2 | 293150014 | Pop Rivet 3/16" | 2 |
| 2 | 234051600 | Flat Washer M5, Stainless | 2 |
