Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 2707-083 | Complete Chassis Assembly | 1 |
| 1 | 2707-383 | Tunnel Assembly (inc. 2-13) | 1 |
| 1 | 1707-952 | Tunnel, Front - Assembly (inc. 3-4) | 1 |
| 1 | 1607-332 | Bracket, Mounting - Suspension - Right | 1 |
| 1 | 1607-333 | Bracket, Mounting - Suspension - Left | 1 |
| 1 | 8060-686 | Rivet - Zinc | 1 |
| 6 | 1623-206 | Rivet | 6 |
| 8 | 8422-502 | Nut, Lock | 8 |
| 1 | 1707-644 | Bracket, Mounting - Rear Spar - Right | 1 |
| 1 | 1707-645 | Bracket, Mounting - Rear Spar - Left | 1 |
| 8 | 8476-512 | Screw, Machine | 8 |
| 2 | 1623-257 | Rivet | 2 |
| 1 | 8060-682 | Rivet | 1 |
| 1 | 1607-395 | Tunnel, Rear | 1 |
| 1 | 8060-484 | Rivet | 1 |
| 1 | 1607-104 | End Cap, Tunnel | 1 |
| 1 | 1623-984 | Clamp, Routing | 1 |
| 1 | 0608-631 | Plate, Retaining | 1 |
| 2 | 8060-688 | Rivet - Zinc | 2 |
| 2 | 8476-820 | Screw, Machine | 2 |
| 1 | 6606-664 | Support, Gas Tank - Right | 1 |
| 1 | 6606-665 | Support, Gas Tank - Left | 1 |
| 1 | 1707-454 | Support, Footrest - Right | 1 |
| 1 | 1707-455 | Support, Footrest - Left | 1 |
| 2 | 8427-802 | Nut, Lock | 2 |
| 0744-064 | Kit, Tool | ||
| 4 | 8468-535 | Screw, Machine | 4 |
| 9 | 1623-637 | Clip, U-Nut | 9 |
| 1 | 0607-996 | Footrest - Right | 1 |
| 1 | 0607-997 | Footrest - Left | 1 |
| 4 | 8470-516 | Screw, Machine | 4 |
| 1 | 1607-109 | Protector, Chain Case | 1 |
| 9 | 8061-708 | Rivet | 9 |
| 1 | 0607-351 | Protector, Brake Disc | 1 |
| 1607-371 | Shield, Brake Disc | ||
| 2 | 8408-613 | Screw, Cap | 2 |
| 1 | 8470-520 | Screw, Machine | 1 |
| 1 | 1623-130 | Rivet | 1 |
| 2 | 1607-092 | Roll, Tunnel - Right | 2 |
| 1 | 0630-316 | Protector, Harness - Taillight Extension | 1 |
| 1 | 1623-241 | Rivet | 1 |
| 1 | 1607-162 | Gusset, Running Board - Right | 1 |
| 1 | 1607-163 | Gusset, Running Board - Left | 1 |
| 1 | 1607-040 | Gusset, Tunnel Roll - Right | 1 |
| 1 | 1607-041 | Gusset, Tunnel Roll - Left | 1 |
| 2 | 0621-990 | Decal, Reflector - Red | 2 |
| 2 | 0621-708 | Decal, Tunnel - "7000" | 2 |
| 1 | 0630-328 | Bracket, Mounting - Taillight | 1 |
| 2 | 8470-512 | Screw, Machine | 2 |
| 1 | 0609-898 | Taillight, LED | 1 |
| 1 | 6606-394 | Snowflap | 1 |
| 1 | 5611-852 | Decal, Warning - Towing (French) (French) | 1 |
| 1 | 5611-853 | Decal, Warning - Towing (English) (English) | 1 |
| 6 | 8061-706 | Rivet | 6 |
| 1 | 2707-441 | BUMPER,REAR-137"/141" PTD ORANGE | 1 |
| 2 | 8476-620 | Screw, Machine | 2 |
| 2 | 8427-602 | Nut, Hex | 2 |
| 1 | 6606-615 | Bag, Belt | 1 |
| 1 | 6606-814 | Pad, Fuel Tank - Right | 1 |
| 1 | 6606-815 | Pad, Fuel Tank - Left | 1 |
| 2 | 1607-455 | Protector, Tunnel | 2 |
| 1 | 6606-816 | Pad, Fuel Tank - Center | 1 |
