Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 4KB-46161-00-00 | Housing, Shaft Drive 2 | ||
| 1 | 4KB-46162-00-00 | Housing, Bearing 2 | 1 |
| 4KB-W4614-00-00 | Pinion Drive Gear Set | ||
| 4KB-46127-00-00 | Shim, Drive Pinion (1.82T) UR | ||
| 4KB-46127-60-00 | Shim, Drive Pinion (2.18T) UR | ||
| 4KB-46127-20-00 | Shim, Drive Pinion (1.94T) UR | ||
| 4KB-46127-30-00 | Shim, Drive Pinion (2.00T) UR | ||
| 4KB-46127-40-00 | Shim, Drive Pinion (2.06T) UR | ||
| 4KB-46127-50-00 | Shim, Drive Pinion (2.12T) UR | ||
| 4KB-46127-10-00 | Shim, Drive Pinion (1.88T) UR | ||
| 4KB-46117-60-00 | Shim, Ring Gear (0.80T) UR | ||
| 4KB-46117-50-00 | Shim, Ring Gear (0.75T) UR | ||
| 4KB-46117-40-00 | Shim, Ring Gear (0.70T) UR | ||
| 4KB-46117-30-00 | Shim, Ring Gear (0.65T) UR | ||
| 4KB-46117-20-00 | Shim, Ring Gear (0.60T) UR | ||
| 4KB-46117-10-00 | Shim, Ring Gear (0.55T) UR | ||
| 4KB-46117-00-00 | Shim, Ring Gear (0.50T) UR | ||
| 4KB-46117-70-00 | Shim, Ring Gear (0.85T) UR | ||
| 4KB-46117-N0-00 | Shim, Ring Gear (1.60T) UR | ||
| 4KB-46117-M0-00 | Shim, Ring Gear (1.55T) UR | ||
| 4KB-46117-80-00 | Shim, Ring Gear (0.90T) UR | ||
| 4KB-46117-90-00 | Shim, Ring Gear (0.95T) UR | ||
| 4KB-46117-A0-00 | Shim, Ring Gear (1.00T) UR | ||
| 4KB-46117-B0-00 | Shim, Ring Gear (1.05T) UR | ||
| 4KB-46117-C0-00 | Shim, Ring Gear (1.10T) UR | ||
| 4KB-46117-D0-00 | Shim, Ring Gear (1.15T) UR | ||
| 4KB-46117-E0-00 | Shim, Ring Gear (1.20T) UR | ||
| 4KB-46117-F0-00 | Shim, Ring Gear (1.25T) UR | ||
| 4KB-46117-G0-00 | Shim, Ring Gear (1.30T) UR | ||
| 4KB-46117-H0-00 | Shim, Ring Gear (1.35T) UR | ||
| 4KB-46117-J0-00 | Shim, Ring Gear (1.40T) UR | ||
| 4KB-46117-K0-00 | Shim, Ring Gear (1.45T) UR | ||
| 4KB-46117-L0-00 | Shim, Ring Gear (1.50T) UR | ||
| 4KB-46470-00-00 | Limited Slip Diff. Assembly | ||
| 1 | 90105-08759-00 | Bolt, Flange | 1 |
| 90105-08758-00 | Bolt, Washer Based | ||
| 2 | 90105-10757-00 | Bolt, Washer Based | 2 |
| 1 | 90179-60664-00 | Nut | 1 |
| 90201-086R7-00 | Washer, Plate | ||
| 1 | 93306-32202-00 | Bearing | 1 |
| 93306-07804-00 | Bearing | ||
| 1 | 93103-38178-00 | Oil Seal | 1 |
| 2 | 93105-22029-00 | Oil Seal | 2 |
| 93210-313A0-00 | O-Ring | ||
| 1 | 4KB-11186-00-00 | Cover, Cylinder Head Side 2 | 1 |
| 6 | 90105-08756-00 | Bolt, Flange | 6 |
| 90179-16663-00 | Nut | ||
| 4KB-46146-00-00 | Yoke, Joint 3 | ||
| 93306-07805-00 | Bearing | ||
| 4KB-46118-A0-00 | Washer, Thrust (1.00T) UR | ||
| 4KB-46118-90-00 | Washer, Thrust (0.95T) UR | ||
| 4KB-46118-80-00 | Washer, Thrust (0.90T) UR | ||
| 4KB-46118-70-00 | Washer, Thrust (0.85T) UR | ||
| 4KB-46118-60-00 | Washer, Thrust (0.80T) UR | ||
| 4KB-46118-50-00 | Washer, Thrust (0.75T) UR | ||
| 4KB-46118-40-00 | Washer, Thrust (0.70T) UR | ||
| 4KB-46118-30-00 | Washer, Thrust (0.65T) UR | ||
| 4KB-46118-20-00 | Washer, Thrust (0.60T) UR | ||
| 4KB-46118-10-00 | Washer, Thrust (0.55T) UR | ||
| 4KB-46118-00-00 | Washer, Thrust (0.05T) UR | ||
| 4KB-46118-B0-00 | Wassemblyer, Thrust (1.05T) UR | ||
| 4KB-46118-N0-00 | Washer, Thrust (1.60T) UR | ||
| 4KB-46118-M0-00 | Washer, Thrust (1.55T) UR | ||
| 4KB-46118-L0-00 | Washer, Thrust (1.50T) UR | ||
| 4KB-46118-K0-00 | Washer, Thrust (1.45T) UR | ||
| 4KB-46118-J0-00 | Washer, Thrust (1.40T) UR | ||
| 4KB-46118-H0-00 | Washer, Thrust (1.35T) UR | ||
| 4KB-46118-G0-00 | Washer, Thrust (1.30T) UR | ||
| 4KB-46118-F0-00 | Washer, Thrust (1.25T) UR | ||
| 4KB-46118-E0-00 | Washer, Thrust (1.20T) UR | ||
| 4KB-46118-D0-00 | Washer, Thrust (1.15T) UR | ||
| 4KB-46118-C0-00 | Washer, Thrust (1.10T) UR | ||
| 1 | 90445-072J4-00 | Hose (L1120) | 1 |
| 1 | 90467-06016-00 | Clip | 1 |
| 2 | 3HN-46108-00-00 | Cross Joint Comp. 3 | 2 |
| 2 | 93399-99926-00 | . Bearing | 2 |
| 2 | 93440-20088-00 | . Circlip | 2 |
| 1 | 2HR-46187-00-00 | . .Spider | 1 |
| 4 | 93399-99926-00 | Bearing | 4 |
| 4 | 93440-20088-00 | Circlip | 4 |
| 4KB-46173-00-00 | Shaft, Drive 2 | ||
| 2 | 93410-22039-00 | Circlip | 2 |
| 1 | 90201-225M9-00 | Washer, Plate | 1 |
| 1 | 90501-234F8-00 | Spring, Compression | 1 |
