Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204610391 | Front Backrest Ass'y Includes 1 - 2. | ||
| 204610392 | Backrest Cover (Colorado Pearl) | ||
| 269000388 | SEAT SUPPORT | ||
| 6 | 293150043 | Pop Rivet 3/16" | 6 |
| 204611190 | Center Front Seat Ass'y Includes 5 - 12. | ||
| 204611191 | Front Seat Cover (Metallic Quartz) | ||
| 204610184 | Staple Cover, Meter | ||
| 293000060 | Passenger Strap | ||
| 2 | 241140060 | Screw K40 X 10 | 2 |
| 2 | 234042600 | Flat Washer 4 mm, Stainless | 2 |
| 204610178 | Front Seat Latch | ||
| 3 | 205441660 | Socket Head Screw M4 X 16 | 3 |
| 204610207 | Seat Stud | ||
| 14 | 234062600 | Flat Washer M6, Stainless | 14 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 293830043 | Rubber Stopper | ||
| 2 | 293150013 | Pop Rivet 3/16" | 2 |
| 204610963 | Strap | ||
| 204611192 | LH Front Seat Ass'y Includes 21 - 22. | ||
| 204611193 | LH Seat Cover (Metallic Quartz) | ||
| 6 | 204610100 | SEAT BRACKET | 6 |
| 6 | 293730006 | Black, Dart | 6 |
| 204611194 | RH Front Seat Ass'y Includes 26 - 27. | ||
| 204611195 | RH Seat Cover (Metallic Quartz) | ||
| 204611697 | Rear Backrest Ass'y Includes 28 - 33. | ||
| 204610884 | Bump Cover (Colorado Pearl) | ||
| 204610697 | Backrest Cover (Metalic Quartz) | ||
| 204610698 | RH Backrest Cover (Metalic Quartz) | ||
| 204610699 | LH Backrest Cover (Metalic Quartz) | ||
| 204901063 | Sea-Doo Logo | ||
| 207364060 | Hex. Screw M6 X 40, Scotch Grip | ||
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 293150065 | RIVET | ||
| 204611228 | Rear Seat Ass'y Includes 38 - 44. | ||
| 204610888 | Rear Seat Cover (Colorado Pearl) | ||
| 204611200 | Rear Seat Pillow Ass'y Includes 40 - 41. | ||
| 204611201 | Rear Seat Pillow Cover | ||
| 204610517 | Rear Seat Strap (Colorado Pearl) | ||
| 4 | 207161660 | Hex. Screw M6 X 16 | 4 |
| 4 | 207364560 | Hex. Screw M6 x 45, Scotch Grip | 4 |
| 4 | 204100006 | Washer | 4 |
| 4 | 293730021 | Dart | 4 |
| 204610882 | RH Rear Seat Arm-Rest Ass'y Includes 48 - 49. | ||
| 204610891 | RH Rear Seat Arm (Colorado Pearl) | ||
| 8 | 234061600 | Stainless Flat Washer M6 | 8 |
| 204130015 | Threaded Rod M5, Scotch Grip | ||
| 206254069 | Socket Set Screw M5 X 40, Scotch Grip | ||
| 2 | 232551600 | Hex. Elastic Nut M5 | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 204610883 | LH Rear Seat Arm-Rest Ass'y Includes 55 - 56. CHALLENGER 1800 (5702). . | ||
| 204610892 | LH Rear Seat Arm-Rest Cover CHALLENGER 1800 (5702). . | ||
| 204611207 | RH Elbow Padding Ass'y Includes 57 - 61. | ||
| 204611208 | RH Elbow Padding Cover (Metalic Quartz | ||
| 204610121 | Neoprene Foam | ||
| 3 | 293730006 | Black, Dart | 3 |
| 3 | 234062600 | Flat Washer M6, Stainless | 3 |
| 204611209 | LH Elbow Padding Ass'y Includes 62 - 66. | ||
| 204611210 | LH Elbow Padding Cover (Metalic Quartz) | ||
| 204610123 | Neoprene Foam | ||
| 2 | 293730006 | Black, Dart | 2 |
| 204610420 | Rear Spoiler Ass'y Includes 67 - 69. | ||
| 204610421 | Spoiler Cover | ||
| 5 | 207362560 | Hex. Screw M6 X 25, Scotch Grip | 5 |
| 5 | 234002600 | Flat Washer 10 mm, Stainless | 5 |
| 204611231 | Platform Ass'y Includes 72 - 75. CHALLENGER 1800 (5702). . | ||
| 204610717 | Platform Cover (Metalic Quartz) | ||
| 204610194 | Strap | ||
| 204901061 | Challenger Logo | ||
| 204611298 | Velcro 25 Mm X 940 Mm | ||
| 204611299 | Velcro 25 Mm X 635 Mm | ||
| 10 | 293150088 | Pop Rivet 3/16" | 10 |
| 7 | 293150011 | Pop Rivet 3/16" | 7 |
