Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204470026 | Courtesy Light Ass'y Includes 1 - 2. | 5 |
| 2 | 204470081 | BULB | 1 |
| 3 | 293150032 | RIVET_POP 1/8 X ,487 | 20 |
| 4 | 204470683 | Radio Support | |
| 5 | 232051600 | Hex. Nut M5 | 1 |
| 6 | 234151601 | Helical Lock Washer M5 | 1 |
| 7 | 234052600 | Flat Washer 5 mm, Stainless | 1 |
| 8 | 209642560 | PHILLIPS SCREW M4.2 X 25 | |
| 9 | 204470611 | Facia Includes 9 - 11. | |
| 10 | 204070268 | Double Side Tape | |
| 11 | 293730014 | Black Dart | 2 |
| 12 | XXXX | Not Available As Spare Part - Radio Harness | |
| 13 | XXXX | Not Available As Spare Part - Tie Rap 130 mm | |
| 14 | 204470378 | Speaker | |
| 15 | 209642560 | PHILLIPS SCREW M4.2 X 25 | |
| 16 | 219704457 | ADHESIVE LOCTITE 425 20ML | |
| 17 | 204470716 | 12 Volts Connection | 1 |
| 18 | 204470630 | Instrumentation Harness | |
| 19 | 204470418 | Horn | |
| 20 | 204470528 | Female Terminal Housing, 2 Circuits | 1 |
| 21 | 278001014 | Female Terminal | 2 |
| 22 | 278001013 | Wire Seal | 2 |
| 23 | 204470548 | Horn Cover | |
| 24 | 204470099 | BILGE PUMP SWITCH ASS'Y Includes 24 - 25. | |
| 25 | 204470132 | Gasket | |
| 26 | 204470100 | LIGHT SWITCH ASS'Y Includes 26 - 27. | 1 |
| 27 | 204470132 | Gasket | |
| 28 | 204470101 | HORN SWITCH ASS'Y Includes 28 - 29. | 1 |
| 29 | 204470132 | Gasket | |
| 30 | 204470102 | COURTESY LIGHT SWITCH ASS'Y Includes 30 - 31. | |
| 31 | 204470132 | Gasket | |
| 32 | 204470391 | Oil/Fuel Gauge | |
| 33 | 204470463 | Safety Switch Includes 33 - 36. | |
| 34 | 278000217 | Female Housing, 2 Circuits | 1 |
| 35 | 278000218 | Wire Seal | 2 |
| 36 | 278000222 | Male Terminal | 2 |
| 37 | 204470561 | Speedometer Gauge | |
| 38 | 204470464 | Safety Lanyard | 1 |
| 39 | 278000099 | Safety Switch Nut | |
| 40 | 204470535 | Radio Cover | |
| 41 | 293150005 | Pop Rivet 3/16" | 2 |
| 42 | XXXX | Not Available As Spare Part - Tie Rap Mount | |
| 43 | 204470466 | Tachometer Gauge | |
| 44 | 204470343 | LOCKING PLATE | 2 |
| 45 | 204000081 | Pop Rivet 3/16" | 1 |
| 46 | XXXX | Not Available As Spare Part - Flat Washer | |
| 47 | 204470011 | VENTILATION SWITCH ASS'Y Includes 47 - 48. | |
| 48 | 204470132 | Gasket | |
| 49 | 204470308 | Gasket | |
| 50 | 293800060 | Loctite 243, 10 ml | 1 |
| 51 | 204470309 | Gasket | |
| 52 | 204470146 | Gauge Nut | |
| 53 | 204470171 | Gauge Nut | |
| 54 | 204470682 | Compact Disc Radio | |
| 55 | 204470380 | Antenna | |
| 56 | 204470343 | LOCKING PLATE | 2 |
| 57 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 58 | 278000217 | Female Housing, 2 Circuits | 1 |
| 59 | 204470401 | Switch Panel | |
| 60 | 204470544 | BATTERY SWITCH Includes 60 - 61. | 1 |
| 61 | 204470132 | Gasket | |
| 62 | 204470402 | LIGHT SWITCH Includes 62 - 63. | 1 |
| 63 | 204470132 | Gasket | |
| 64 | 204470403 | LIGHT SWITCH, BOARDING Includes 64 - 65. | |
| 65 | 204470132 | Gasket | |
| 66 | 204470404 | LIGHT SWITCH, DOCKING Includes 66 - 67. | |
| 67 | 204470132 | Gasket | |
| 68 | 204470405 | SWITCH, SMALL POOL PUMP Includes 68 - 69. | 1 |
| 69 | 204470132 | Gasket | |
| 70 | 204470406 | SWITCH, PASSENGER WATER PUMP Includes 70 - 71. | |
| 71 | 204470132 | Gasket | |
| 72 | 204470411 | Engine Compartment Light Includes 72 - 75. | |
| 73 | 278000217 | Female Housing, 2 Circuits | 1 |
| 74 | 278000222 | Male Terminal | 2 |
| 75 | 278000218 | Wire Seal | 2 |
| 76 | 241142560 | Hex. Flange Screw K40 X 25 | 3 |
| 77 | 204470551 | LIGHT HARNESS Includes 77 - 81. | 1 |
| 78 | 278000220 | Male Connector, 2 Circuits | 1 |
| 79 | 409007300 | Female Terminal | 2 |
| 80 | 278000218 | Wire Seal | 4 |
| 81 | 278000222 | Male Terminal | 2 |
| 82 | 204470412 | Engine Compartment Light |
