Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11101-41F00 | HEAD ASSY, CYLINDER FRONT MODEL K1/K2/K3/K4 | ||
| 11101-41FA0 | HEAD ASSY, CYLINDER FRONT MODEL K5; Includes Item(s) 2 | ||
| 2 | 09206-11004 | PIN | 2 |
| 4 | 11115-38A71 | GUIDE, VALVE (OS 0.3) OPT | 4 |
| 2 | 09103-06101 | BOLT,6X50 (6X50) | 2 |
| 2 | 09103-06102 | BOLT (6X55) MODEL K1/K2/K3/K4 | 2 |
| 1 | 09103-06102 | BOLT (6X55) MODEL K5 | 1 |
| 1 | 07130-06803 | BOLT (6X80) MODEL K5 | 1 |
| 1 | 11123-38A00 | GASKET,HEAD COVER | 1 |
| 1 | 11141-41F00 | GASKET,CYLINDER HEAD FRONT | 1 |
| 2 | 09103-08370 | BOLT (L:250) | 2 |
| 2 | 09103-10133 | BOLT (10X155) | 2 |
| 2 | 09103-10134 | BOLT (10X165) | 2 |
| 2 | 09160-08130 | WASHER (8.5X24X1.6) | 2 |
| 4 | 09160-10060 | WASHER (10.5X22X2.3) MODEL K1/K2 | 4 |
| 4 | 09160-10039 | WASHER (10.5X22X2.3) MODEL K3/K4/K5 | 4 |
| 1 | 09108-08144 | STUD BOLT (L:40) MODEL K1/K2 | 1 |
| 01421-08403 | STUD BOLT (L:40) MODEL K3/K4 | ||
| 2 | 01550-06253 | BOLT (L:25) | 2 |
| 5 | 01550-06303 | BOLT (L:30) | 5 |
| 1 | 01550-06403 | BOLT (L:40) | 1 |
| 2 | 01550-06403 | BOLT (L:40) MODEL K1/K2/K3/K4 | 2 |
| 2 | 04211-13189 | KNOCK PIN | 2 |
| 1 | 07120-06303 | BOLT (L:30) | 1 |
| 1 | 08316-10083 | NUT MODEL K1/K2/K3/K4 | 1 |
| 11171-41F00 | CAP, CYLINDER HEAD COVER FL MODEL K1/K2/K3/K4 | ||
| 11171-41FA0 | CAP,CYL HEAD COVER FR LH MODEL K5 | ||
| 11172-41F00 | CAP, CYLINDER HEAD COVER FR | ||
| 1 | 11175-38A11 | CAP, INSPECTION INTAKE | 1 |
| 1 | 11176-38A11 | CAP, INSPECTION EXHAUST | 1 |
| 2 | 11177-38A00 | GASKET,INSPECTION CAP | 2 |
| 2 | 11179-10F10 | SPACER, HEAD COVER CAP | 2 |
| 1 | 09108-06102 | BOLT, INSPECTION CAP STUD | 1 |
| 2 | 09160-06084 | WASHER, HEAD COVER CAP UPPER | 2 |
| 2 | 09160-09016 | WASHER, HEAD COVER CAP LOWER | 2 |
| 1 | 09241-30004 | PLUG, CYLINDER HEAD | 1 |
| 2 | 09320-09016 | CUSHION | 2 |
| 2 | 09320-13015 | CUSHION, HEAD COVER BOLT | 2 |
| 3 | 01547-06203 | BOLT, INSPECTION CAP | 3 |
| 2 | 01547-06507 | BOLT, HEAD COVER CAP | 2 |
| 1 | 08313-20063 | NUT, INSPECTION CAP MODEL K1/K2/K3/K4 | 1 |
| 09159-06093 | NUT, INSPECTION CAP MODEL K5 | ||
| 1 | 09482-00354 | SPARK PLUG, DPR7EA-9 (NGK) | 1 |
| 1 | 09482-00355 | SPARK PLUG, X22EPR-U9 (ND) | 1 |
| 1 | 09482-00330 | SPARK PLUG, DPR9EA-9 (NGK) OPT | 1 |
| 1 | 09482-00331 | SPARK PLUG, X27EPR-U9 (ND) OPT | 1 |
| 1 | 09482-00334 | SPARK PLUG, DPR8EA-9 (NGK) OPT | 1 |
| 1 | 09482-00335 | SPARK PLUG, X24EPR-U9 (ND) OPT | 1 |
| 11181-45C10 | UNION, CYLINDER HEAD OUTLET MODEL K1/K2/K3/K4 | ||
| 1 | 11181-41F00 | UNION, CYLINDER HEAD OUTLET MODEL K5 | 1 |
| 1 | 11182-38A00 | O RING, OUTLET UNION | 1 |
| 1 | 01550-06203 | BOLT MODEL K1/K2/K3/K4 | 1 |
| 1 | 07130-06203 | BOLT MODEL K5 | 1 |
| 2 | 09301-08007 | BUSH, HEAD COVER BOLT | 2 |
| 1 | 17891-41F00 | UNION, CYLINDER HEAD JOINT MODEL K1/K2/K3/K4 | 1 |
| 1 | 17891-41F10 | UNION, CYLINDER HEAD JOINT MODEL K5 | 1 |
| 1 | 07130-06123 | BOLT, JOINT UNION | 1 |
| 1 | 09280-16005 | O RING | 1 |
| 1 | 17854-41F00 | HOSE, HEAD JOINT MODEL K1 | 1 |
| 1 | 17854-41F01 | HOSE, HEAD JOINT MODEL K2/K3/K4/K5 | 1 |
| 2 | 09402-28511 | CLAMP, JOINT | 2 |
| 1 | 13650-57F00 | SENSOR, WATER TEMP MODEL K5 | 1 |
| 1 | 09168-12017 | GASKET MODEL K5 | 1 |
