Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 to 19, CDN, USA | ||
| XXXX | Not Available As Spare Part - Drive Pulley Ass'y Includes 1 to 19, Europe | ||
| 1 | 415128975 | INNER FLANGE | 1 |
| 1 | 417126692 | SLIDING FLANGE | 1 |
| 415128602 | SPRING COVER | ||
| 415129219 | Unit Includes 5 to 8, CDN, USA | ||
| 3 | 415129294 | UNIT ASS'Y Includes 5 to 8, Europe | 3 |
| 417118100 | CENTRIFUGE BLOCK CDN, USA | ||
| XXX | Not Available As Spare Parts Europe | ||
| 1 | 417120400 | ADJUSTMENT WEIGH CDN, USA | 1 |
| 3 | 417114400 | ADJUSTMENT WEIGH CDN, USA | 3 |
| 1 | 417114500 | CAPSULE CDN, USA | 1 |
| 420245370 | WASHER | ||
| 3 | 415128606 | SOCKET HEAD SCREW M6 X 35 | 3 |
| 415129220 | Spring, Violet-Yellow-Green | ||
| 1 | 417126694 | SPRING SEAT | 1 |
| 415128609 | Cap | ||
| 1 | 415128610 | WASHER | 1 |
| 1 | 417118300 | NUT | 1 |
| 1 | 417222833 | Ring Gear | 1 |
| 6 | 236281684 | Hex. Screw M8 X 16 | 6 |
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 516001726 | Security Label | ||
| 1 | 392002800 | WASHER-LOCK HELICAL SPRING | 1 |
| 1 | 417113800 | BOLT | 1 |
| 417127024 | FIXED FLANGED ASS'Y Includes 22 to 32 | ||
| 3 | 206262599 | Socket Set Screw | 3 |
| 3 | 233061414 | Hex. Flange Nut M6 | 3 |
| 417127026 | Sliding Flange Ass'y | ||
| 417126373 | REAR CAM SLIDER SHOE, RED | ||
| 3 | 417126374 | Front Cam Slider Shoe, Black | 3 |
| 417126901 | BUSHING | ||
| 417126902 | BUSHING | ||
| 1 | 413408300 | Loctite, Black Max, 3 ml | 1 |
| 371911200 | CIRCLIP | ||
| 1 | 417126878 | CIRCLIP | 1 |
| 1 | 417126445 | CAM ASS'Y | 1 |
| 1 | 417126381 | GUARD | 1 |
| 1 | 504099600 | STOPPER WASHER | 1 |
| 1 | 417127061 | Spring | 1 |
| 417126733 | SPACER | ||
| 417126734 | HALF KEY | ||
| 1 | 504112300 | SHIM | 1 |
| 1 | 417126322 | SWIVEL ABUTMENT | 1 |
| 3 | 417300252 | Spacer | 3 |
| 1 | 417300265 | Spacer | 1 |
| 1 | 417300252 | Spacer | 1 |
| 3 | 504112000 | Shim | 3 |
| 417300238 | PROTECTOR | ||
| 1 | 517302322 | Strength Washer | 1 |
| 1 | 207087544 | HEX. SCREW M8 X 75 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 1 | 415060600 | Drive Belt | 1 |
| 1 | 516002674 | EMERGENCY STARTING LABEL | 1 |
| 1 | 417300269 | BELT GUARD | 1 |
| 1 | 417300301 | SIDE PROTECTOR ASS'Y Includes 53 to 54 | 1 |
| 417300246 | Foam | ||
| 1 | 516002670 | WARNING DECAL, SECURITY BELT GUARD | 1 |
| 417300216 | BELT GUARD BRACKET | ||
| 3 | 390909200 | Avex Rivet | 3 |
| 4 | 293150103 | Pop Rivet 3/16" | 4 |
