Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 8CR-17611-00-00 | Sheave, Primary Fixed | 1 |
| 2 | 8V0-17639-00-00 | .Stopper | 2 |
| 1 | 8BV-17620-02-00 | Primary Sliding Sheave Comp | 1 |
| 1 | 90384-41242-00 | . .Bush, Bimetal Formed | 1 |
| 3 | 90387-0509D-00 | Collar | 3 |
| 3 | 90105-05644-00 | .Bolt, Flange | 3 |
| 3 | 95607-05200-00 | .Nut, U Flange | 3 |
| 8CA-17640-11-00 | Spider Complete | ||
| 6 | 8BW-17653-00-00 | .Slider | 6 |
| 3 | 91609-50032-00 | .Pin, Spring | 3 |
| 3 | 90387-0509B-00 | Collar | 3 |
| 1 | 8BV-17630-10-00 | Primary Sheave Cap Comp | 1 |
| 1 | 90380-28237-00 | . .Bush, Solid | 1 |
| 6 | 97017-06030-00 | .Bolt | 6 |
| 6 | 92907-06600-00 | .Washer, Plate | 6 |
| 6 | 90202-09227-00 | .Washer, Plate | 6 |
| 3 | 8CA-17624-10-00 | Roller, Comp UR STD VT600 | 3 |
| 3 | 8CA-17624-01-00 | Roller, Comp UR STD VT500 | 3 |
| 3 | 8CA-17624-91-00 | Roller, Comp UR AP | 3 |
| 90380-09239-00 | . Bush, Solid | ||
| 6 | 90202-08204-00 | .Washer, Plate | 6 |
| 8CA-17605-01-00 | Weight Comp UR AP | ||
| 3 | 8AB-17605-01-00 | Weight Comp UR STD VT500 | 3 |
| 3 | 8CR-17605-00-00 | Weight Comp UR STD VT600 | 3 |
| 3 | 8CH-17605-00-00 | Weight Comp UR AP | 3 |
| 90380-08221-00 | . Roller Bushing | ||
| 3 | 90261-06019-00 | Rivet, Countersunk (St13.3Mm) UR AP | 3 |
| 3 | 90261-06015-00 | Rivet, Countersunk (St10.3Mm) UR | 3 |
| 3 | 90261-06015-00 | Rivet, Countersunk (St10.3Mm) UR AP | 3 |
| 3 | 90261-06017-00 | Rivet, Countersunk (St11.3Mm) UR AP | 3 |
| 3 | 90261-06028-00 | Rivet, Countersunk (Al10.3Mm) UR AP | 3 |
| 3 | 90261-06028-00 | Rivet, Countersunk (Al10.3Mm) UR | 3 |
| 3 | 90261-06033-00 | Rivet, Countersunk (St17.2Mm) UR | 3 |
| 3 | 90261-06034-00 | Rivet, Countersunk (St13.9Mm) UR AP | 3 |
| 1 | 90501-553G6-00 | Spring, Compression UR AP (WH-Y-WH | 1 |
| 1 | 90501-527G1-00 | Spring, Compression UR AP (R-BL-R) | 1 |
| 1 | 90501-556G7-00 | Spring, Compression UR AP (Y-BL-Y) | 1 |
| 1 | 90501-606G9-00 | Spring, Compression UR AP (P-BL-P) | 1 |
| 1 | 90501-507G2-00 | Spring, Compression UR AP(G0-BL-GO) | 1 |
| 1 | 90501-556G5-00 | Spring, Compression UR AP (WH-BL-WH) | 1 |
| 1 | 90501-607G0-00 | Spring, Compression UR AP (GR-B-GR) | 1 |
| 1 | 90501-556G6-00 | Spring, Compression UR AP (BLUE) | 1 |
| 1 | 90501-604G0-00 | Spring, Compression UR AP (P-Y-P) | 1 |
| 90501-524G5-00 | Spring, Compression UR AP (GO-Y-GO) | ||
| 1 | 90501-524G4-00 | Spring, Compression UR AP (R-Y-R) | 1 |
| 1 | 90501-553G0-00 | Spring, Compression UR AP (BL-Y-BL) | 1 |
| 1 | 90501-605G7-00 | Spring, Compression UR AP (GR-Y-GR) | 1 |
| 1 | 90501-521J6-00 | Spring, Compression UR AP (GO-PGO) | 1 |
| 1 | 90501-550J8-00 | Spring, Compression UR AP (WH-P-WH) | 1 |
| 1 | 90501-582J1-00 | Spring, Compression UR AP (Y-P-Y) | 1 |
| 1 | 90501-582J1-00 | Spring, Compression UR STD (EUR | 1 |
| 1 | 90501-602J0-00 | Spring, Compression UR AP (PINK) | 1 |
| 1 | 90501-481J1-00 | Spring, Compression UR AP (SL- BL-SL) | 1 |
| 1 | 90501-581J7-00 | Spring, Compression UR AP (YELLOW) | 1 |
| 1 | 90501-586J0-00 | Spring, Compression UR AP (Y-SL-Y) | 1 |
| 1 | 90501-525J8-00 | Spring, Compression UR AP (BL-P-BL) | 1 |
| 1 | 90501-585J3-00 | Spring, Compression UR AP (GR-P-GR) | 1 |
| 1 | 90501-605J5-00 | Spring, Compression UR AP (OR-P-OR) | 1 |
| 1 | 90501-555J9-00 | Spring, Compression UR STD(USA) ( WH-P-WH) | 1 |
| 1 | 90501-555J9-00 | Spring, Compression UR AP (WH-SL-WH) | 1 |
| 1 | 90501-526J9-00 | Spring, Compression UR AP (R-P-R) | 1 |
| 1 | 90501-487G8-00 | Spring, Compression UR AP (GOLD | 1 |
| 1 | 90501-507G7-00 | Spring, Compression UR AP (R-GR-R) | 1 |
| 1 | 90501-526G4-00 | Spring, Compression UR AP (BL-G-BL) | 1 |
| 1 | 90501-557G5-00 | Spring, Compression UR AP (Y-GO-Y) | 1 |
| 1 | 90501-557G6-00 | Spring, Compression UR AP (WH-GO-WH) | 1 |
| 1 | 90501-607G4-00 | Spring, Compression UR AP (GR-GO-GR) | 1 |
| 1 | 90501-607G3-00 | Spring, Compression UR AP (P-GO-P) | 1 |
| 89L-17641-01-00 | V-Belt | ||
| 1 | 8V0-17647-00-00 | .Bolt (L=156.5Mm) | 1 |
| 1 | 92907-16100-00 | .Washer | 1 |
