Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 204471125 | Dash Ass'y | 1 |
| 202000203 | SCREW-TAPP.TRUSS HD.PH.M4.2X25 | ||
| 204000130 | Elevator Bolt | ||
| 1 | 204100089 | FLAT WASHER 9/32? | 1 |
| 211100026 | HEX. NUT 1/4 | ||
| 204471138 | RH Switch Panel | ||
| 1 | 204471250 | LH SWITCH PANEL | 1 |
| 1 | 204471236 | Cluster Gauge | 1 |
| 2 | 241142560 | Hex. Flange Screw K40 X 25 | 2 |
| 2 | 293830113 | TRIM | 2 |
| 1 | 278002144 | Gauge Bezel, Chrome | 1 |
| 1 | 204470913 | Buzzer Ass'y Includes 2 to 15 | 1 |
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 278000707 | Buzzer Nut | ||
| 1 | 278002295 | Safety Switch | 1 |
| 1 | 278000395 | Male Housing, 4 Circuits | 1 |
| 4 | 278000218 | Wire Seal | 4 |
| 4 | 278000223 | Female Terminal | 4 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 204471206 | Safety Lanyard | 1 |
| 204471178 | START/STOP SWITCH | ||
| 204470011 | VENTILATION SWITCH ASS'Y Includes 25 to 26 | ||
| 204470132 | Gasket | ||
| 204470099 | BILGE PUMP SWITCH ASS'Y Includes 27 to 28 | ||
| 1 | 204470100 | LIGHT SWITCH ASS'Y Includes 29 to 30 | 1 |
| 1 | 204470596 | SWITCH PLUG | 1 |
| 1 | 204470907 | Receptacle, 12 Volt | 1 |
| 204470908 | LATERAL LIGHT KIT | ||
| 209941960 | PHILLIPS SCREW M4.2 X 19 | ||
| 204471177 | Rear Lamp Base Ass'y Includes 35 to 38 | ||
| 3 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 3 |
| 204470792 | Rear Light Pole Models Without Tower, Includes 40 to 42 | ||
| 204470053 | Bulb | ||
| 1 | 204470350 | COLLAR | 1 |
| XXXX | Not Available As Spare Part - Stereo/CD Unit | ||
| XXXX | Not Available As Spare Part - Stereo/CD Unit Antenna | ||
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 1 | 204470981 | RADIO SUPPORT | 1 |
| 1 | 208462060 | PHILLIPS SCREW M6 X 20 | 1 |
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 204470894 | RADIO CD PLAYER COVER | 1 |
| 209632560 | Pan Head Tapping Screw M3.5x25 | ||
| XXXX | Not Available As Spare Part - Speakers, Silver | ||
| 209641360 | TAPPING PHILLIPS SCREW M4.2 X 13 | ||
| XXXX | Not Available As Spare Part - Speaker Cover Ass'y | ||
| 204470842 | Rear Light Pole Models With Tower |
