Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 10 | 504154102 | Black, Chain Case Ass'y Includes 10 to 10b | 1 |
| 10a | 504153560 | Plate Ass'y | 1 |
| 10b | 233261434 | Flange Elastic Nut M6 | 5 |
| 20 | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 30 | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 60 | 504082900 | Washer | 1 |
| 70 | 250000740 | Torx Screw M8 X 20, Scotch Grip | 1 |
| 80 | 233261434 | Flange Elastic Nut M6 | 2 |
| 100 | 293200168 | Oil Seal | 1 |
| 110 | 293350115 | Ball Bearing | 1 |
| 120 | 504152576 | Circlip | 1 |
| 130 | 504152628 | Shim | 1 |
| 140 | 504154188 | Sprocket 21 Teeth | 1 |
| 140 | 861805572 | Chain and Sprocket Kit 21-51 | 1 |
| 280 | 504152784 | Spring Washer M10 | 1 |
| 290 | 207503046 | Hex. Flange Screw M10 X 30, Scotch Grip | 1 |
| 1100 | 293200159 | Oil Seal | 1 |
| 1110 | 293350059 | Ball Bearing | 1 |
| 1120 | 504152582 | Circlip | 1 |
| 1130 | 504154824 | Sprocket 51 Teeth | 1 |
| 1130 | 861805572 | Chain and Sprocket Kit 21-51 | 1 |
| 1140 | 504152572 | Circlip | 1 |
| 1150 | 293300201 | O-Ring | 1 |
| 1160 | 504154019 | Magnetic Cap Includes 1160 to 1160a | 1 |
| 1160a | 504154043 | Cap | 1 |
| 1500 | 504153759 | Drive Chain, 116 Links | 1 |
| 1500 | 861805572 | Chain and Sprocket Kit 21-51 | 1 |
| 1510 | 414575600 | Hair Pin | 1 |
| 1520 | 504153760 | Adjustment Screw | 1 |
| 1540 | 250500013 | Hex. Countersunk Drain Plug | 1 |
| 1545 | 250500013 | Hex. Countersunk Drain Plug | 1 |
| 1550 | 293300202 | O-Ring | 1 |
| 1600 | 504153559 | Tensioner | 1 |
| 1610 | 504153312 | Slider Chain | 1 |
| 1650 | 293370105 | Circlip | 1 |
| 1690 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
| 1700 | 504154079 | Deep Black, Chain Case Cover Ass'y Includes 1700 to 1700c | 1 |
| 1700b | 515178223 | Clip Connector | 1 |
| 1700c | 415130141 | Braided Sleeve | 1 |
| 1710 | 293300200 | O-Ring | 1 |
| 1720 | 250001153 | Hex. Flange Screw M6X20 | 8 |
| 1740 | 504153535 | Cap Ass'y Includes 1740 to 1740c | |
| 1740a | 504152860 | Cap | 1 |
| 1740b | 414580700 | Male Connector | 1 |
| 1740c | 219704410 | Polyurethane Hose 10000Mm Long | 1 |
| 1790 | 250001015 | Hex. Flange Screw M6 X 35 | 1 |
| 2030 | 293300201 | O-Ring | 1 |
| 2040 | 504154043 | Cap | 1 |
| 2050 | 504152572 | Circlip | 1 |
| 2500 | 504153695 | Bearing Housing Ass'y Includes 2500 to 2500a | 1 |
| 2500a | 250300028 | Clinch Stud, M8 X 25 | 1 |
| 2510 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 3000 | 504154023 | Drive Axle Ass'y Includes 3000 to 3000e | 1 |
| 3000b | XXX | Not Available As Spare Parts | |
| 3000c | XXX | Not Available As Spare Parts | |
| 3000d | 504153886 | Retaining Ring | 1 |
| 3000e | 293350059 | Ball Bearing | 1 |
| 3200 | 504153785 | Track Ass'y 16" X 154" X 3" Includes 3200 to 3200b | 1 |
| 3200 | 504153791 | Track Ass'y 16" X 154" X 2.50" Includes 3200 to 3200b | 1 |
| 3200a | 415130083 | Track Guide | 1 |
| 3200b | 415130084 | Cleat | 1 |
| 4000 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
| 4020 | 504082900 | Washer | 1 |
