Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 204611940 | SEAT LATCH | 2 |
| 4 | 204100120 | TAPPING PAN SCREW M14 X 2 | 4 |
| 204611805 | LATCH | ||
| 204100081 | SCREW #8 X 1-1/4? | ||
| 4 | 202000159 | SCREW-STUD TAPP. 3/8 SS | 4 |
| 204612150 | Front Seat Ass’y, Port Side Includes 6 to 11 / Red | ||
| 204612726 | Front Seat Ass’y, Port Side Includes 6 to 11 / Blue | ||
| 204612153 | Front Seat Ass’y, Starboard Includes 6 to 11 / Red | ||
| 204612731 | Front Seat Ass’y, Starboard Includes 6 to 11 / Blue | ||
| 204612613 | Retaining Strap Ass'y Includes 7 to 9 | ||
| 2 | 204000083 | SNAP BASE | 2 |
| 2 | 204611609 | SNAP COVER | 2 |
| 2 | 204100054 | SCREW 8 X 3/4? | 2 |
| 2 | 211200019 | FLAT WASHER | 2 |
| 204612151 | Front Seat Backrest Ass’y, Port Side Includes 12 to 14 / Red | ||
| 204612729 | Front Seat Backrest Ass’y, Port Side Includes 12 to 14 / Blue | ||
| 204612152 | Front Seat Backrest Ass’y, Starboard Includes 12 to 14 / Red | ||
| 204612730 | Front Seat Backrest Ass’y, Starboard Includes 12 to 14 / Blue | ||
| 1 | 234461608 | External Serrated Lock Washer 6 mm | 1 |
| 204100060 | Hex. Jam Nut | ||
| 4 | 204610288 | Seat Support | 4 |
| 8 | 293150043 | Pop Rivet 3/16" | 8 |
| 4 | 234052400 | Flat Washer 5 mm, Stainless | 4 |
| 2 | 204100139 | WASHER-FENDER/S.S. | 2 |
| 211100026 | HEX. NUT 1/4 | ||
| 204612164 | Rear Backrest Ass’y, Starboard Includes 20 to 21 / Red | ||
| 204612733 | Rear Backrest Ass’y, Starboard Includes 20 to 21 / Blue | ||
| 204612154 | Rear Backrest Ass’y, Port Side Includes 20 to 21 / Red | ||
| 204612735 | Rear Backrest Ass’y, Port Side Includes 20 to 21 / Blue | ||
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 6 | 204610288 | Seat Support | 6 |
| 12 | 293150043 | Pop Rivet 3/16" | 12 |
| 204612753 | Front Seat Ass’y, Port Side Includes 25 to 30 / Red | ||
| 204612758 | Front Seat Ass’y, Port Side Includes 25 to 30 / Blue | ||
| 204612756 | Rear Seat Ass’y, Starboard Includes 25 to 30 / Red | ||
| 204612759 | Rear Seat Ass’y, Starboard Includes 25 to 30 / Blue | ||
| 204612613 | Retaining Strap Ass'y Includes 26 to 28 | ||
| 204612158 | Arm Rest, Starboard | ||
| 204612159 | Arm Rest, Port Side | ||
| 2 | 204610288 | Seat Support | 2 |
| 4 | 293150043 | Pop Rivet 3/16" | 4 |
| 4 | 293730021 | Dart | 4 |
| 204612165 | Sunpad Door Ass’y, Port Side Red | ||
| 204612742 | Sunpad Door Ass’y, Port Side Blue | ||
| 204612684 | Retainer Plate | ||
| 8 | 293150011 | Pop Rivet 3/16" | 8 |
| 204612166 | Sunpad Door Ass’y, Starboard Red | ||
| 204612744 | Sunpad Door Ass’y, Starboard Blue | ||
| 204612685 | Loop | ||
| 2 | 204100049 | PHILLIPS TAPPING SCREW #8 X 1 | 2 |
| 204100057 | FINITION WASHER | ||
| 4 | 204612769 | SUNDECK HINGE | 4 |
| 8 | 204100134 | TAPPING SCREW 1/4-20 X 3/4 | 8 |
| 8 | 204100137 | TAPPING SCREW 1/4-20 X 1/2 | 8 |
| 16 | 234061600 | Stainless Flat Washer M6 | 16 |
| 204612768 | Sundeck Latch Ass'y Includes 52 to 60 | ||
| 204070577 | Latch Ass’y Includes 53 to 57 | ||
| 1 | 269700076 | Latch Cover | 1 |
| 1 | 269000015 | Latch Base | 1 |
| 1 | 269700077 | Latch Lever | 1 |
| 1 | 269700017 | Latch Spring | 1 |
| 204612642 | Strap | ||
| 1 | 293150039 | Pop Rivet 3/16" | 1 |
| 2 | 234052600 | Flat Washer 5 mm, Stainless | 2 |
| 1 | 269700015 | SHIM | 1 |
| 2 | 204100141 | HEX. BOLT TAPPING | 2 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
| 2 | 204071700 | Shock Bracket | 2 |
| 4 | 204100073 | SCREW-PAN HD.#10 X 5/8 SS | 4 |
| 204071673 | Shock Bracket | ||
| 6 | 293150039 | Pop Rivet 3/16" | 6 |
| 204071874 | GAS SHOCK | ||
| 1 | 204612641 | SLIDE LATCH | 1 |
| 1 | 204612664 | LATCH SHIM | 1 |
| 4 | 204100082 | TAPPING SCREW | 4 |
| 1 | 204070060 | KEEPER | 1 |
| 2 | 293150039 | Pop Rivet 3/16" | 2 |
| XXXX | Not Available As Spare Part - Staple 1/4" (Stainless) |
