Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1a | 278000219 | CONNECTOR_MALE 1 CAVITY | |
| 1b | 278001012 | Male Housing, 1 Circuit | 1 |
| 1c | 278000220 | Male Connector, 2 Circuits | 1 |
| 1d | 278001113 | Male Connector, 2 Circuits | 1 |
| 1e | 278000273 | Male Housing, 3 Circuits | 1 |
| 1f | 278000395 | Male Housing, 4 Circuits | 1 |
| 1g | 278000739 | Male Connector, 4 Circuits | 1 |
| 1h | 278000891 | CONNECTOR_MALE 4 CAVITIES | 1 |
| 1i | 278000221 | MALE CONNECTOR, 6 CIRCUITS | |
| 1j | 278000736 | Male Connector, 6 Circuits | 1 |
| 2a | 278000161 | Female Housing, 1 Circuit | 1 |
| 2b | 278000217 | Female Housing, 2 Circuits | 1 |
| 2c | 278000281 | Female Terminal Housing, 3 Circuits | 1 |
| 2d | 278000394 | FEMALE HOUSING, 4 CIRCUITS | |
| 2e | 278000635 | Female Housing, 4 Circuits | 1 |
| 2f | 278000890 | CONNECTOR_FEMALE 4 CAVITIES | |
| 2g | 278000156 | FEMALE CONNECTOR, 6 CIRCUITS | |
| 2h | 270000137 | Female Connector, 6 Circuits | 1 |
| 3a | 409004300 | Male Terminal | 1 |
| 3b | 278000222 | Male Terminal | 1 |
| 3c | 278000230 | Male Terminal | 1 |
| 3d | 278000631 | Male Terminal | 1 |
| 4a | 409007300 | Female Terminal | 1 |
| 4b | 278000223 | Female Terminal | 1 |
| 4c | 278001009 | Female Terminal | 1 |
| 4d | 278000632 | Female Terminal | 1 |
| 4e | 290964068 | Female Terminal | 1 |
| 4f | 278000228 | FEMALE TERMINAL | 1 |
| 4g | 278001114 | Female Terminal | 1 |
| 4h | 278001014 | Female Terminal | 1 |
| 4i | 278000995 | FEMALE TERMINAL | |
| 5a | 278000218 | Wire Seal | 1 |
| 5b | 278000585 | Wire Seal (20 Gauge) (Purple) (Packard) | 1 |
| 5c | 278001065 | Wire Seal | 1 |
| 5d | 278000216 | Wire Seal | 1 |
| 5e | 278001013 | Wire Seal | 1 |
| 6a | 293720030 | Grommet, 1 Circuit, Blue | |
| 6b | 278000098 | GROMMET | |
| 6c | 278000682 | Grommet | |
| 6d | 293720025 | GROMMET, 2 CIRCUIT, GRAY | |
| 6e | 278000193 | GROMMET, 3 CIRCUIT, BLACK | |
| 6f | 570026800 | Grommet, 4 Circuit, Red | |
| 6g | 293720034 | Grommet | |
| 7a | 278000231 | Insulation Sheath | 1 |
| 7b | 278001008 | Insulated Sheath | 1 |
| 7c | 290964077 | Insulating Sheath (Male Terminal) | 1 |
| 8a | 278001007 | Insulated Sheath | 1 |
| 8b | 290964072 | Insulating Sheath | 1 |
| 8c | 278000770 | Insulated Sheath | 1 |
| 9a | 278000992 | Open Barrel | 1 |
| 9b | 409003200 | OPEN BARREL | |
| 9c | 278000300 | Ring Terminal | |
| 9d | 278001138 | Open Barrel, 8 mm | |
| 9e | 278001165 | Open Barrel | |
| 10 | 278000100 | Electric Wire Cap | |
| 11 | 293750001 | Tie Wrap 94 mm | 1 |
| 11 | 293750002 | Tie Wrap 142 mm | 1 |
| 11 | 294000606 | Tie Rap 180 mm | 1 |
| 11 | 293750009 | Tie-Rap 173 mm | 1 |
| 12a | 278000738 | Male Lock, 4 Circuits | 1 |
| 12b | 278000737 | MALE LOCK, 6 CIRCUITS | 1 |
| 13a | 278000636 | Female Wedge, 4 Circuits | 1 |
| 13b | 278000735 | Female Lock, 6 Circuits | 1 |
| 14 | 293000052 | Sealing Cap | 1 |
| 15 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
