Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 270500296 | Carburetor BN40-38-16 Includes 1 - 62. | |
| 2 | 270500191 | Spring | |
| 3 | XXXX | Not Available As Spare Part - Choke Valve | |
| 4 | 270500156 | SCREW | |
| 5 | XXXX | Not Available As Spare Part - Throttle Valve | |
| 6 | 270500011 | SPRING WASHER | 1 |
| 7 | 270500012 | Nut | |
| 8 | 270500222 | Sealing Ring | |
| 9 | 270500104 | O-Ring | |
| 10 | 270500165 | Pilot Jet 67.5 | |
| 11 | 270500320 | Main Jet 182 | |
| 12 | 270500091 | SPRING | 2 |
| 13 | 270500136 | Washer | |
| 14 | 270500228 | Screw | |
| 15 | 270500229 | NUT | 1 |
| 16 | 270500230 | Spring Washer | |
| 17 | 270500234 | SEALING RING | 2 |
| 18 | 270500315 | Support | |
| 19 | XXXX | Not Available As Spare Part - Choke Shaft Ass'y | |
| 20 | 270500239 | RING | 1 |
| 21 | XXXX | Not Available As Spare Part - Throttle Shaft Ass'y | |
| 22 | 270500115 | FUEL FILTER | 1 |
| 23 | 270500127 | O-RING | |
| 24 | 270500241 | Needle Valve 1.5 | 1 |
| 25 | 270500129 | CLIP | |
| 26 | 270500128 | NEEDLE VALVE LEVER | 1 |
| 27 | 270500313 | Spring | |
| 28 | 270500132 | DIAPHRAGM ASS'Y | 1 |
| 29 | 270500307 | Clip | |
| 30 | 270500131 | GASKET | 1 |
| 31 | 270500144 | O-RING | 2 |
| 32 | 270500113 | Adjuster Screw | |
| 33 | 270500020 | IDLE ADJUSTING SCREW | 1 |
| 34 | 270500019 | SPRING | |
| 35 | 270500018 | Washer | |
| 36 | 270500119 | O-RING | |
| 37 | 270500155 | Screw And Spring Washer | |
| 38 | 270500125 | PLATE | |
| 39 | 270500038 | Pin | |
| 40 | 270500124 | VALVE ASS'Y | 1 |
| 41 | 270500123 | SCREW | |
| 42 | 270500322 | Screw | |
| 43 | 270500238 | SCREW | 2 |
| 44 | 270500308 | Hose 90 mm | |
| 45 | 270500316 | Choke Lever | |
| 46 | 270500248 | SPRING | 1 |
| 47 | 270500110 | Ring | |
| 48 | 270500154 | Cap | |
| 49 | 270500309 | RING | 1 |
| 50 | 270500192 | RING | 1 |
| 51 | 270500249 | Nut | |
| 52 | 270500103 | GASKET | 1 |
| 53 | 270500105 | Body Pump Ass'y | |
| 54 | 270500106 | DIAPHRAGM | 1 |
| 55 | 270500146 | Gasket | |
| 56 | 270500108 | PUMP COVER | |
| 57 | 270500143 | SCREW | |
| 58 | 270500102 | O-RING | |
| 59 | 270500288 | Adjuster Screw | |
| 60 | 270500323 | Hose | |
| 61 | 270500317 | Throttle Lever Ass'y | |
| 62 | 270500321 | Diaphragm Ass'y | |
| 63 | 219704459 | Était Was 293800050 Loctite 577, 250 ml | 1 |
| 64 | 217383600 | Lock Washer 8 mm | 2 |
| 65 | 215987560 | Screw Allen M8 x 75 |
