Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| XXX | Not Available As Spare Parts | ||
| 1 | 204471321 | FASCIA | 1 |
| 4 | 204100234 | PHILLIPS TAPPING SCREW M4.2 X 38 | 4 |
| 1 | 204471378 | Cluster Gauge | 1 |
| 2 | 241141660 | Hex. Flange Screw K40 X 16 | 2 |
| 2 | 293830113 | TRIM | 2 |
| 4 | 211000180 | PHILLIPS SCREW #8 X 1/2, PLASTITE | 4 |
| 1 | 204470913 | Buzzer Ass'y Includes 8 to 11 | 1 |
| 2 | 278000222 | Male Terminal | 2 |
| 2 | 278000218 | Wire Seal | 2 |
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 278000707 | Buzzer Nut | ||
| 1 | 278002295 | Safety Switch | 1 |
| 1 | 278000395 | Male Housing, 4 Circuits | 1 |
| 4 | 278000218 | Wire Seal | 4 |
| 4 | 278000223 | Female Terminal | 4 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 1 | 204471206 | Safety Lanyard | 1 |
| 204471178 | START/STOP SWITCH | ||
| 204470011 | VENTILATION SWITCH ASS'Y Includes 23 to 24 | ||
| 204470132 | Gasket | ||
| 204470099 | BILGE PUMP SWITCH ASS'Y Includes 25 to 26 | ||
| 1 | 204470100 | LIGHT SWITCH ASS'Y Includes 27 to 28 | 1 |
| 1 | 204470101 | HORN SWITCH ASS'Y Includes 29 to 30 | 1 |
| 204470102 | COURTESY LIGHT SWITCH ASS'Y Includes 31 to 32 | ||
| 3 | 204470026 | Courtesy Light Ass'y Includes 33 to 34 | 3 |
| 1 | 204470081 | BULB | 1 |
| 12 | 293150032 | RIVET_POP 1/8 X ,487 | 12 |
| 1 | 710001248 | DC Outlet | 1 |
| 204470372 | Front Lamp | ||
| 209642560 | PHILLIPS SCREW M4.2 X 25 | ||
| 1 | 204470072 | FRONT LAMP SUPPORT | 1 |
| 204470990 | REAR LIGHT BASE | ||
| 3 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 3 |
| 1 | 204470979 | REAR LIGHT POLE | 1 |
| 1 | 204470980 | REAR LIGHT HARNESS Includes 47 to 50 | 1 |
| 2 | 293750002 | Tie Wrap 142 mm | 2 |
| 1 | 204470108 | Fan Ass'y Includes 52 to 55 | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 2 | 278000223 | Female Terminal | 2 |
| 2 | 293150088 | Pop Rivet 3/16" | 2 |
| 2 | 234052600 | Flat Washer 5 mm, Stainless | 2 |
| 204470801 | HORN | ||
| 2 | 209943260 | Phillips Tapping Screw M4.2 X 32 | 2 |
| 1 | 278001016 | Temperature Sensor | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
